3.3. Kinds of Quadrilaterals

A trapezium is a quadrilateral with a pair of parallel sides.

These are trapeziums

These are not trapeziums

(Note: The arrow marks indicate parallel lines).

A trapezium, also known as a trapezoid in some regions, is a type of quadrilateral defined by having at least one pair of parallel sides. The parallel sides are usually referred to as the 'bases' of the trapezium. In contrast, the other two sides are known as the 'legs'. By studying the figures provided, one can identify trapeziums by looking for these characteristics. Additionally, isosceles trapeziums have legs of equal length.

Imagine a set of railroad tracks; they run parallel to each other, just like the sides of a trapezium. When you think of fields of crops or landscapes, you might spot trapezium shapes formed by farms where one edge is straight and the other slightly angled.

Kite is a special type of a quadrilateral. The sides with the same markings in each figure are equal. For example, AB = AD and BC = CD.

These are kites

These are not kites.

A kite is a type of quadrilateral that has two pairs of adjacent sides that are equal in length. This means that if AB and AD are equal in length and BC and CD are also equal, then the shape can be identified as a kite. An important feature of kites is that they often have one axis of symmetry, which means if you fold a kite along its symmetry line, both sides will match perfectly.

Think of flying a kite; if you have a kite that has two long sides and two shorter sides, it forms the shape of a kite in the sky. This design helps it catch the wind effectively, demonstrating how the features of a kite affect its function.

A parallelogram is a quadrilateral. As the name suggests, it has something to do with parallel lines.

These are parallelograms

These are not parallelograms.

A parallelogram is defined by its opposite sides being both parallel and equal in length. This means, if you take a parallelogram and extend its opposite sides, they would never meet and are always the same distance from each other. In addition to these characteristics, the opposite angles in a parallelogram are also equal. This contributes to a stable shape in many structures.

You can think of a parallelogram as a rectangle that has been pushed sideways. For example, a table that has slanted edges (like a diamond shape) formed by its corners can be visualized as a parallelogram.

There are four sides and four angles in a parallelogram. Some of these are equal. There are some terms associated with these elements that you need to remember.

Given a parallelogram ABCD. AB and DC are opposite sides. AD and BC form another pair of opposite sides. ∠A and ∠C are a pair of opposite angles; another pair of opposite angles would be ∠B and ∠D.

In a parallelogram, there are four sides (AB, BC, CD, DA) and four angles (∠A, ∠B, ∠C, ∠D). The opposite sides, such as AB and CD, are equal in length, and the same goes for AD and BC. The properties of angles in a parallelogram are also crucial; for example, opposite angles (like ∠A and ∠C) are equal, which reinforces the balance and structure of the shape.

Consider a flag. When you think of a parallelogram, picture the design on a flag waving in the breeze. The sides represent the edges of the flag, and the angles represent where the flag connects to the flagpole, maintaining symmetry and balance.

We studied a property of parallelograms concerning the (opposite) sides. What can we say about the angles?

In parallelograms, opposite angles are equal, meaning that if you know one angle, you automatically know its opposite. Additionally, adjacent angles are supplementary, which means that the sum of the measures of adjacent angles (like ∠A and ∠B) will equal 180 degrees. This property is fundamental, as it helps in solving various geometry problems involving parallelograms.

Think of corners of a rectangular room. If one corner is measured at 90 degrees, the angle directly opposite it (at the other end) will also be 90 degrees. If you measure two adjacent corners, together they will make a straight line, adding up to 180 degrees.

The diagonals of a parallelogram, in general, are not of equal length. However, the diagonals of a parallelogram have an interesting property.

In a parallelogram, while the diagonals are not necessarily of equal length, they have the property of bisecting each other. This means if you draw the diagonals, they will cut each other in half at a certain point. This ability to bisect is a unique characteristic that helps define the shape of the quadrilateral.

Imagine a trampoline mat held taut at its corners. If you were to draw lines between opposite corners, those lines would cross in the middle, splitting each other equally, much like how the diagonals of a parallelogram bisect at their midpoint.

--
