11. SURF ACE AREAS AND VOLUMES

We have already studied the surface areas of cube, cuboid and cylinder. We will now study the surface area of cone.

So far, we have been generating solids by stacking up congruent figures. Incidentally, such figures are called prisms. Now let us look at another kind of solid which is not a prism (These kinds of solids are called pyramids). Let us see how we can generate them.

This chunk introduces the concept of a cone, specifically a right circular cone. It is stated that we previously discussed the surface areas of other shapes and now focus on cones. A cone is not formed by stacking but through rotation, which differentiates it from prisms. This sets the stage for understanding the properties of cones.

Imagine making a birthday party hat, which is shaped like a cone. When you cut and paste paper into this shape, you create a cone—this is similar to how cones are formed in geometry.

Activity: Cut out a right-angled triangle ABC right-angled at B. Paste a long thick string along one of the perpendicular sides say AB of the triangle. Hold the string with your hands on either sides of the triangle and rotate the triangle about the string a number of times. What happens? Do you recognize the shape that the triangle is forming as it rotates around the string?

In this chunk, an activity is presented to understand how a right circular cone is generated. By rotating a right-angled triangle around one of its sides, students can visually and practically comprehend the formation of a cone. This hands-on experience solidifies the concept of cones in geometry as three-dimensional objects.

Think about how a ice-cream cone is created at an ice-cream shop: when you rotate a triangle base, you create the cone shape that holds the ice cream.

In Fig. 1.1(c) of the right circular cone, the point A is called the vertex, AB is called the height, BC is called the radius and AC is called the slant height of the cone. Here B will be the centre of the circular base of the cone.

This chunk defines the elements of a cone: the vertex (point where the cone tapers), the height (distance from the base to the vertex), the radius (distance from the center of the base to its edge), and the slant height (the distance from the vertex to any point on the circular base). Understanding these parts is critical for calculating surface areas and volumes.

Think of a party hat again: the tip of the hat is the vertex, the height is how tall the hat is, the radius is the distance from the center of the circular rim to its edge, and the slant height is the line on the outside of the hat from the tip down to the edge.

The curved surface area of a cone is given by the formula: Curved Surface Area of a Cone = $πrl$ where $r$ is its base radius and $l$ its slant height.

This formula calculates the curved surface area of a cone by multiplying π, the base radius, and the slant height of the cone. This is important for understanding how much 'outside' surface area a cone has, which can be relevant for things like painting or covering the cone.

If you were to cover your party hat with glitter, knowing the curved surface area would tell you how much glitter you need to make it sparkle!

If the base of the cone is to be closed, then a circular piece of paper of radius r is also required whose area is $πr^2$. So, Total Surface Area of a Cone = $πrl + πr^2$ = $πr(l + r)$.

The total surface area of a cone includes both the curved area and the area of the base. This combines everything that would need to be covered or painted on the cone's surface and base, ensuring a proper understanding of the entire surface.

Think of wrapping a candy cone: you need to know both the wrapper that covers the cone's side and the flat circle that covers the top of the candy to ensure it's completely wrapped.

Therefore, Volume of a Cone = $\frac{1}{3}πr^2h$ where $r$ is the base radius and $h$ is the height of the cone.

This formula explains how to calculate the volume of a cone. It represents how much space is inside the cone and is one-third the volume of a cylinder that has the same base radius and height as the cone. Students will learn how to apply this formula to different problems involving cones.

Consider a funnel for pouring liquids: when you fill the funnel, you want to know how much it will hold—this volume formula gives you that answer!

Example 1: Find the curved surface area of a right circular cone whose slant height is 10 cm and base radius is 7 cm.

Solution: Curved surface area = πrl = 22/7 × 7 × 10 cm^2 = 220 cm^2.

This chunk presents an example calculation using the curved surface area formula. It demonstrates how to substitute values into the formula and perform the calculation, which is valuable practice for students.

Imagine you want to decorate a cone-shaped party hat and need to know how much decoration to buy. This example shows you exactly how to calculate that area.

In this chapter, you have studied the following points: Curved surface area of a cone = $πrl$, Total surface area of a cone = $πr(l + r)$, Volume of a cone = $\frac{1}{3}πr^2h$.

This chunk summarizes the critical formulas learned in this section. Reinforcing these key points helps ensure retention and allows students to quickly reference these formulas in the future.

Think of the formulas as recipes: you need these ingredients (formulas) to recreate your geometry 'dishes' (calculations) successfully!

--
