The modularization of Java applications was introduced with Java 9 through the Java Platform Module System (JPMS). It was one of the most significant changes to the Java language since generics in Java 5. JPMS offers a powerful mechanism to divide code into reliable, reusable, and secure components known as modules. These modules define what they expose to other modules and what they encapsulate. JPMS aims to make applications more scalable, maintainable, and performant by organizing code into explicit, well-defined modules.

A module is a self-contained unit of code that groups together related packages and resources. It specifies:
• Which packages it exports
• Which other modules it requires
Characteristics of a Java Module:
• It has a name.
• It explicitly states dependencies on other modules.
• It encapsulates its internal packages.

Before Java 9:
• Java used JAR files to package and distribute code.
• There was no true module system; dependency conflicts (e.g., “JAR Hell”) were common.
• No reliable way to hide internal APIs or detect conflicts between libraries.
JPMS Solves:
• Reliable configuration
• Strong encapsulation
• Scalable platform (small runtime for IoT)
• Better security and maintainability.

Each module has a module-info.java file at its root which acts as a module descriptor.
Syntax:

module com.example.mylibrary {
requires java.sql;
exports com.example.mylibrary.api;
}

Keywords:
• module: declares the module name.
• requires: declares dependency on another module.
• exports: makes a package accessible to other modules.

1. Module Declaration (module-info.java)
   Defines the module and its dependencies.
   Example:

module com.myapp {
requires java.logging;
requires com.utils;
exports com.myapp.api;
}

1. requires Directive
   Tells the compiler and runtime that a module depends on another module.
   Types:
   • requires: Compile-time and runtime dependency.
   • requires transitive: Exposes the dependency to modules that depend on your module.
   • requires static: Used only at compile time.
2. exports Directive
   Defines which packages are available to other modules.

exports com.myapp.api;

1. opens Directive
   Opens a package for reflection at runtime (important for frameworks like Spring).

opens com.myapp.internal;

1. uses and provides Directives
   Used for ServiceLoader-based dependency injection.

uses com.myapp.MyService;
provides com.myapp.MyService with com.myapp.impl.MyServiceImpl;

Type Description
Application Modules you write for your application.
Automatic Module A regular JAR placed on the module path without a module-info.java.
Unnamed Module Classes loaded from the classpath, not explicitly modularized.
Platform Modules Built-in Java modules (e.g., java.base, java.sql, java.xml).

Java itself is modularized. Some standard modules include:
• java.base: Contains essential classes (automatically required).
• java.sql: JDBC API.
• java.logging: Java Logging API.
• java.xml: XML processing.
You can list all modules via:

java --list-modules

Folder Structure:

src/
├── com.myapp/
│ ├── module-info.java
│ └── com/myapp/Main.java
├── com.utils/
│ ├── module-info.java
│ └── com/utils/Utils.java

Sample module-info.java for com.myapp:

module com.myapp {
requires com.utils;
exports com.myapp;
}

Sample module-info.java for com.utils:

module com.utils {
exports com.utils;
}

Compile:

javac -d out --module-source-path src $(find src -name "*.java")

Run:

java --module-path out -m com.myapp/com.myapp.Main

• Reliable Configuration: No more JAR conflicts or classpath issues.
• Strong Encapsulation: Prevents unwanted access to internal APIs.
• Improved Performance: JVM can optimize startup and memory use.
• Security: Explicit access control reduces attack surfaces.
• Maintainability: Clear boundaries and dependencies.

• Steep learning curve for legacy developers.
• Compatibility issues with non-modular libraries.
• Frameworks like Spring require opens for reflection-based features.
• Not all existing tools and libraries support modules perfectly.

Feature JPMS OSGi
Runtime System Static at compile time Dynamic at runtime
Complexity Simpler Complex
Adoption Higher (post-Java 9) Limited to niche areas
Focus Compile-time modularity Runtime component model.

Steps:
1. Identify and isolate modules in your codebase.
2. Create module-info.java for each module.
3. Move third-party libraries to the module path.
4. Use requires, exports, opens as needed.
5. Refactor reflective access with opens.
