10.3 - Sound Needs a Medium for Propagation
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Sound Propagation
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we will talk about how sound travels. Can anyone tell me if sound can travel through air?
Yes! We hear sounds in the air all the time.
But can it travel through space? Because space is a vacuum.
Great observation! No, sound cannot travel through a vacuum. It needs a medium like air, water, or even solids. Let's remember that with the acronym 'S-P-M', meaning Sound Requires Propagation Medium.
So, what's the difference between how sound travels in air and through water?
Good question! We'll see that shortly when we do our experiments.
In summary, sound requires a medium like air or water to travel, and it cannot propagate through a vacuum.
Activity Demonstration of Sound in Air
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let's perform Activity 10.7. Who can bring a metal tumbler here?
I have one, Teacher!
Perfect! Now, we will place a cell phone inside the tumbler and call it from another phone. What do you think will happen?
I think we will hear the ringing!
Exactly! Now, when I put my hands around the tumbler and suck the air out, what will happen to the sound?
I think it will get quieter.
Yes, and when there’s no air left, you won't hear anything. So, what does that mean?
It means sound can't travel without a medium!
Correct! So, let's summarize that sound needs a medium to propagate.
Exploring Sound in Liquids and Solids
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now we will discuss how sound travels through liquids and solids. Let's conduct Activity 10.8 with a bell in water. What do you think will happen?
I think we will hear the bell ringing underwater!
Let's try it out. Remember, sound travels faster in liquids than in air. After that, we'll try Activity 10.9.
Why would sound travel faster in liquids?
That’s because molecules in liquids are closer together than those in gases, making it easier for sound waves to pass through. Now, let’s try the metal rod experiment to see how sound travels in solids.
Can I hold one end of the rod? I want to hear my friend tapping on the other end!
Yes, that’s the perfect way to see sound traveling through a solid, just like when we make toy telephones with strings! Remember, sound can travel through different media.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
In this section, the concept that sound cannot propagate through a vacuum is introduced. Several activities demonstrate how sound travels through different media, such as air, water, and solids, explaining the fundamental principle that sound needs a medium for propagation.
Detailed
Sound Needs a Medium for Propagation
Sound is a form of energy that is produced by vibrating bodies and travels through a medium. In this section, we explore how sound propagates and the importance of media in sound transmission.
- Propagation of Sound: Sound travels from one place to another, and this phenomenon can be easily demonstrated through everyday experiences, such as hearing a bell ring or a friend calling.
- Activities to Demonstrate Sound Propagation:
- Activity 10.7: Using a metal tumbler and a cell phone to observe sound propagation and how sound gets fainter when air is removed from the tumbler, illustrating that sound needs a medium to travel.
- Activity 10.8: Demonstrating sound travel in liquids by shaking a bell underwater.
- Activity 10.9: Investigating sound travel in solids using a metre scale or metal rod to hear tapping at the other end.
- Main Takeaway: Sound requires a medium to propagate. It can travel through gases, liquids, and solids, but it cannot travel in a vacuum. Understanding this concept is crucial as it relates to other aspects of sound such as frequency, amplitude, and pitch in subsequent sections.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
How Sound Propagates
Chapter 1 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
When you call up your friend who is standing at a distance, your friend is able to hear your voice. How does the sound propagate or travel to her?
Detailed Explanation
Sound travels through a medium, which could be air, water, or solid objects. When you speak, your vocal cords vibrate, creating sound waves that move through the air. These waves then reach your friend's ears, allowing them to hear your voice.
Examples & Analogies
Imagine throwing a stone in a pond. The ripples that form are similar to how sound waves travel through the air. Just as the ripples move across the water, sound waves move through the air (or other mediums) to reach another person.
Experiments with Sound in a Tumbler
Chapter 2 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Activity 10.7
Take a metal or glass tumbler. Make sure that it is dry. Place a cell phone in it. (Remember that the cell phone must not be kept in water.) Ask your friend to give a ring on this cell phone from another cell phone. Listen to the ring carefully. Now, surround the rim of the tumbler with your hands. Put your mouth on the opening between your hands. Indicate to your friend to give a ring again. Listen to the ring while sucking air from the tumbler. Does the sound become fainter as you suck air?
Detailed Explanation
In this activity, when you place your hands around the tumbler and suck air out, you are creating a partial vacuum. Sound travels best through mediums like air, and when there is less air in the tumbler, the sound waves have a harder time propagating, making the sound fainter. When you remove your mouth, allowing air back in, the sound becomes louder again.
Examples & Analogies
Think of listening to your voice in a tunnel versus an open field. In a narrowed space (like the tumbler), sound may not travel as effectively if there is less air, akin to how sounds echo and resonate differently in large, open spaces compared to confined areas.
Sound Traveling Through Different Mediums
Chapter 3 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Activity 10.8
Take a bucket or a bathtub. Fill it with clean water. Take a small bell in one hand. Shake this bell inside the water to produce sound. Make sure that the bell does not touch the body of the bucket or the tub. Can you hear the sound of the scratching? Ask your friends around you if they were able to hear the same sound?
Detailed Explanation
When you shake the bell underwater, the sound it produces travels differently compared to when it is in air. Water is denser than air, allowing sound waves to move more effectively. This shows that sound can travel through liquids; however, it's important to note that the medium affects how the sound is perceived.
Examples & Analogies
Think of how you can hear someone talking clearly while underwater but find it hard to hear outside. This is because sound travels faster and more efficiently through water than it does through air. It's similar to how you can hear someone shouting outside on a clear day much more easily than when you're in a noisy room.
Sound Traveling Through Solids
Chapter 4 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Activity 10.9
Take a metre scale or a long metal rod and hold its one end to your ear. Ask your friend to gently scratch or tap at the other end of the scale. You can also perform the above activity by placing your ear at one end of a long wooden or metallic table and asking your friend to gently scratch the other end of the table.
Detailed Explanation
In this activity, when you scratch or tap the rod, the sound vibrations travel through the solid material. Sound travels faster through solids than gases or liquids because the particles in solids are much closer together, allowing sound waves to transfer energy more effectively from one particle to the next.
Examples & Analogies
Imagine the way you might hear a friend tapping on a table more clearly by putting your ear directly on the surface. The vibrations travel through the table (the solid), allowing you to perceive the sound once it reaches your ear, just like how a child hears music through the ground when a band plays on the street above.
Summary of Sound Propagation
Chapter 5 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
We find that sound can travel through wood or metal. In fact, sound can travel through any solid. You can perform interesting activities to show that sound can also travel through strings. Have you ever made a toy telephone?
Detailed Explanation
Overall, we understand that sound is produced by vibrating objects and travels through different mediums: gases, liquids, and solids. Each medium allows sound waves to propagate, but the efficiency may vary based on density and particle arrangement.
Examples & Analogies
Just like how we can talk through a string telephone made from two cups and a string, sound can travel effectively through these materials. The string acts as a medium that transports the vibrations from one cup to another, demonstrating that sound needs a medium to travel.
Key Concepts
-
Sound requires a medium to travel: Sound cannot propagate through a vacuum.
-
Different mediums affect the speed of sound: Sound travels faster in liquids and solids than in gases.
-
Vibrating objects produce sound: The source of sound is always a vibration.
Examples & Applications
When you shout, your voice travels through the air to reach your friend's ears.
Underwater, if a bell is shaken, the sound can be heard clearly due to water being a good medium.
Tapping a metal rod creates sound that travels effectively and is heard at the other end.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Sound in air, water, and solids flow, without a medium, it won't go!
Stories
Once upon a time, a little sound wave wanted to travel the world. But it found out that without air or water, it couldn't go anywhere—only through the mediums it navigated freely.
Memory Tools
Remember 'S-P-M': Sound Propagation Medium.
Acronyms
M.A.W. - Medium, Air, Water!
Flash Cards
Glossary
- Medium
The substance through which sound travels, such as air, water, or solids.
- Propagation
The movement of sound waves through a medium.
- Vacuum
A space entirely devoid of matter where sound cannot propagate.
- Vibration
The rapid back-and-forth motion of an object that produces sound.
- Amplitude
The maximum extent of a vibration, which determines the loudness of sound.
