Case Study 3: Intel’s Skylake Mobile CPUs (14nm FinFET)
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Power Gating
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we’ll explore how power gating contributes to the efficiency of Intel's Skylake CPUs. What do you think power gating means?
Does it mean turning off parts of the CPU that aren’t being used?
Exactly! By disabling inactive cores and execution units, the CPU doesn't waste energy. This helps conserve battery life, especially in thin laptops.
So, it helps in reducing power during idle times?
Correct! This technique is essential for maintaining a balance between performance and energy efficiency. Can anyone give an example of scenarios where power gating is beneficial?
I think when the laptop is just sitting idle or performing light tasks?
Right again! Power gating is particularly effective in those situations. Let's remember the acronym 'PIE' (Performance, Idle power, Efficiency) to recall its importance.
In summary, power gating is a critical feature that allows CPUs to optimize power usage. It significantly reduces energy consumption during standby states.
Dual-Edge Triggered Flip-Flops
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let's now discuss dual-edge triggered flip-flops. Do anyone know how they differ from traditional flip-flops?
Aren't they activated on both the rising and falling edges of the clock signal?
Correct! This means they can operate at a lower clock frequency while maintaining throughput. Why is that beneficial?
It potentially reduces the power since the clock frequency is lower, right?
Exactly, great job! By lowering the clock frequency while maintaining performance, Skylake CPUs become more power-efficient. Remember 'D-DF' for Dual-Edge, Dual Function.
To recap: Dual-edge triggered flip-flops help achieve efficient operation at lower power levels while ensuring performance consistency.
10T SRAM Cells
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Next, let's talk about 10T SRAM cells. What do you think makes them different from standard SRAM cells?
I believe it’s about stability at lower voltages?
Absolutely! The 10T SRAM cells provide better state retention, especially under low-voltage conditions, making them ideal for low-power applications.
And they help reduce leakage, right?
That's right! The design of 10T cells enhances memory retention and minimizes leakage power, essential for improving overall device efficiency. Let's remember '10T = 10 Tips to save power!'
In summary, 10T SRAM cells contribute significantly to cache efficiency, blending performance with energy saving.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
The case study highlights how Intel's Skylake Mobile CPUs achieved optimized performance for ultrabooks and thin laptops through strategic component decisions such as dual-edge triggered flip-flops and power gating, leading to significant power efficiency improvements.
Detailed
Intel’s Skylake Mobile CPUs (14nm FinFET)
The Intel Skylake Mobile CPUs represent a significant achievement in balancing high performance and low power consumption for ultrabooks and thin laptops. Key design decisions included the use of dual-edge triggered flip-flops, which allowed the CPUs to maintain throughput at lower clock frequencies. Power gating was employed to shut down inactive cores and unused execution units, thereby conserving power when full processing capacity was unnecessary. Additionally, the incorporation of a shared L3 cache with 10T SRAM cells enhanced memory retention with lower leakage rates. Thermal throttling and dynamic voltage frequency scaling (DVFS) mechanisms were crucial for adjusting power delivery based on thermal conditions.
The impact on power efficiency was notable, enabling burst performance during high-load applications while significantly reducing idle power consumption. Overall, Skylake CPUs managed to achieve a leakage power reduction of approximately 50% during standby states, which improved battery life by up to 1.5 hours compared to previous generations. This case study exemplifies how intelligent design choices at the component level can lead to substantial enhancements in power efficiency for consumer electronics.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Design Goal
Chapter 1 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Design Goal: Balanced high performance and low power for ultrabooks and thin laptops.
Detailed Explanation
The primary objective of Intel's Skylake Mobile CPUs was to deliver an optimal blend of high performance and low power consumption, specifically tailored for ultrabooks and thin laptops. This means that while the processors needed to be powerful enough for demanding tasks, they also had to operate efficiently to extend battery life and reduce heat generation.
Examples & Analogies
Think of a sports car that needs to be fast but also fuel-efficient. Just like car manufacturers must balance speed and fuel consumption to meet consumer needs, Intel aimed to achieve high processing speeds in their CPUs without draining the battery quickly.
Key Component Decisions
Chapter 2 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Key Component Decisions:
- Dual-Edge Triggered Flip-Flops: Allowed same throughput at lower clock frequencies.
- Power Gating: Used for inactive cores and unused execution units.
- Shared L3 Cache with 10T SRAM Cells: Enhanced low-leakage memory retention.
- Thermal Throttling & DVFS: Adjusted power delivery based on thermal headroom.
Detailed Explanation
Intel made several key component decisions to support their design goals:
1. Dual-Edge Triggered Flip-Flops: This technology enabled the CPUs to achieve the same data processing speed while operating at lower clock frequencies, thereby saving power.
2. Power Gating: This refers to shutting off power to inactive cores and execution units, which helps in minimizing power consumption when those components are not in use.
3. Shared L3 Cache with 10T SRAM Cells: Utilizing 10T SRAM cells in the cache reduced leakage current, making the memory more power-efficient during operation.
4. Thermal Throttling and DVFS (Dynamic Voltage and Frequency Scaling): These technologies allowed the CPU to adjust power delivery based on the current thermal conditions, optimizing performance while preventing overheating.
Examples & Analogies
Imagine a water tap; if you only need a little water (inactive components), you wouldn't want to leave it running at full blast. Similarly, power gating is like turning off that tap for unused cores. Dual-edge flip-flops are akin to a two-lane highway allowing cars to traverse more efficiently without needing to speed up (lower clock frequencies).
Impact on Power Efficiency
Chapter 3 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Impact on Power Efficiency:
- Enabled burst performance for high-load applications while maintaining low idle power.
- Reduced leakage power by ~50% in standby states.
- Improved battery life by up to 1.5 hours over previous generation CPUs.
Detailed Explanation
The design choices made in the Skylake architecture led to significant advancements in power efficiency:
1. Burst Performance: The CPUs could handle demanding applications effectively (burst performance), while still consuming minimal power during idle times.
2. Reduced Leakage Power: By optimizing the design, leakage power diminished by approximately 50% in standby mode, meaning that the CPUs drained far less battery when not actively in use.
3. Extended Battery Life: The cumulative result of these enhancements was a substantial improvement in battery life, with users experiencing up to 1.5 hours longer use compared to the previous CPU generation.
Examples & Analogies
Consider a smartphone that can handle intense gaming sessions (burst performance) while still saving battery when it's just sitting in your pocket. The dramatic reduction in leakage power in standby is like turning off unnecessary notifications (minimizing distractions) to preserve battery life while the phone is not being actively used.
Key Concepts
-
Power Gating: A method used to reduce power consumption by turning off unused CPU components.
-
Dual-Edge Triggered Flip-Flops: Enhances performance while maintaining lower energy consumption by being activated on both clock edges.
-
10T SRAM Cells: Provides improved stability and reduced leakage in memory storage.
-
Thermal Throttling: Prevents overheating by dynamically adjusting CPU performance.
-
Dynamic Voltage Frequency Scaling: Allows processors to adjust voltage and frequency based on workload demands.
Examples & Applications
Power gating in Skylake CPUs shuts down unused cores, helping to save power during light computing tasks.
Using dual-edge triggered flip-flops enables Intel to maintain performance while utilizing lower frequency clocks.
10T SRAM cells are implemented in the Skylake architecture to ensure reliable memory functionality under low voltage with minimal leakage.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Power gating saves the day, when chips stop, they don't play.
Stories
Imagine your laptop as a car. Power gating is like stopping at red lights to conserve fuel. The car (CPU) only goes full throttle when needed.
Memory Tools
Remember '10T = Ten Tips for saving power', to recall the benefits of 10T SRAM cells.
Acronyms
D-DF for Dual-Edge, Dual Function, reminding us of the efficiency inherent in dual-edge flip-flops.
Flash Cards
Glossary
- Power Gating
A technique used to turn off unused portions of a CPU to save power.
- DualEdge Triggered FlipFlops
Flip-flops that are triggered on both the rising and falling edges of a clock signal, allowing for lower operational frequencies.
- 10T SRAM Cells
Memory cells that enhance state retention and reduce leakage, often used in low-power designs.
- Thermal Throttling
A method of reducing CPU performance to lower temperature and prevent overheating.
- Dynamic Voltage Frequency Scaling (DVFS)
A technique that adjusts the voltage and frequency according to workload demands.
