4. Frame Analysis

Frame structures are the structures having the combination of beam, column and slab to resist the lateral and gravity loads. These structures are usually used to overcome the large moments developing due to the applied loading. Frames structures can be differentiated into: 1- Rigid frame structure: which are further subdivided into: a. Pin ended b. Fixed ended 2- Braced frame structure: which is further subdivided into: a. Gabled frames b. Portal frames

Frame structures are built with a combination of beams, columns, and slabs, designed to bear both gravity and lateral loads. They are essential for effectively managing the large moments caused by applied loads. Two main types of frame structures are identified: rigid frames and braced frames.

• Rigid frames resist deformation because their beams and columns act together to handle moments, which provides great stability.
• Braced frames utilize diagonal supports between beams and columns to resist lateral forces.

Imagine a house built with a strong skeleton structure. The beams are like the bones, keeping everything upright, while the columns are like the legs, providing support. If you try to push the house, the bracing works like muscles to keep it from toppling over.

The word rigid means ability to resist the deformation. Rigid frame structures can be defined as the structures in which beams & columns are made monolithically and act collectively to resist the moments which are generating due to applied load. Rigid frame structure provides more stability. This type of frame structures resists the shear, moment and torsion more effectively than any other type of frame structures.

A rigid structural frame is one that remains stable under load, meaning it resists deformation. The key feature is that beams and columns are integrated into a single unit, which helps to effectively manage moments caused by loading. This structure is capable of withstanding various forces including shear, bending moments, and torsion, making it ideal for large buildings like skyscrapers.

Think of a rigid frame as a table made from solid wood versus a table bundled with weak plastic. The solid wood table is sturdy and can hold heavy books without bending. Similarly, a rigid frame holds up under pressure without collapsing.

In this frame system, bracing is usually provided between beams and columns to increase their resistance against the lateral forces and side-ways forces due to applied load. Bracing is usually done by placing the diagonal members between the beams and columns. This frame system provides more efficient resistance against the earthquake and wind forces.

Braced structural frames include diagonal supports, or braces, that enhance stability and resistance against lateral forces, such as wind or seismic activity. These braces help distribute loads effectively across the structure, providing increased resilience compared to rigid frames.

Imagine an 'A' shape made with two long sticks joined at the top and connected at the base. This shape is much more stable and harder to topple than a square made of the same sticks. Similarly, braced frames use diagonal supports to ensure safety against external forces.

Gable frame steel structure building is a typical construction system. Its upper structure consists of steel of parapet, gutter, roof purlin, steel frame, and wall purlin, etc. This kind of building offers a series of advantages including lightweight construction and cost-effectiveness.

A gabled structural frame is characterized by its steep roof design resembling a triangle. This structure is lightweight and uses considerably less material than reinforced concrete. As a result, it can mitigate earthquake damage, lower foundation costs, and allows for flexible column arrangements that facilitate efficient construction.

Consider the difference between an average house with a heavy concrete roof versus a lightweight steel-framed building. The steel building, like a tent, can sway with the wind and distribute forces better, making it safer in stormy weather.

Portal structural frames usually look like a door. This frame system is very much in use for construction of industrial and commercial buildings.

Portal frames are designed to resemble door frames, serving primarily in industrial and commercial settings. They are efficient for supporting large spans without internal columns, maximizing usable space, and facilitating construction.

Think of a large garage door that opens up fully, allowing cars to park inside without bumping into walls. This design provides maximum space and ease of access, similar to how portal frames create open areas in industrial buildings.

It is a path through which the load of a frame structure is transmitted to the foundations. In frame structures, usually load first transfers from slab to beams then to from beam to columns, then from columns it transfers to the foundation.

The load path is the journey that loads take through the structural elements of the frame before reaching the foundation. First, loads from the roof (slabs) move down to beams, which then transfer these loads to the columns. Finally, the columns direct these loads down into the foundation.

Just like how groceries in a multi-story building are unloaded: you take them from your bag (roof/slab), put them on the kitchen counter (beams), move them to the table (columns) and finally to the cupboard (foundation), each step ensures everything is securely held in place.

One of the best advantages of frame structures is their ease in construction. It is very easy to teach the labor at the construction site. Frame structures can be constructed rapidly. Economy is also a very important factor in the design of building systems. Frame structures have economical designs.

Frame structures are favored for their straightforward construction process, making them easy to teach builders. They can be erected quickly, reducing labor costs, while their economic designs result in efficient material usage, keeping overall costs low.

Picture assembling a flat-pack furniture item versus building one from scratch. The flat-pack is straightforward and can be done quickly, ensuring efficiency and lower costs, just like frame structures promote quick construction and minimal waste.

In frame structures, span lengths are usually restricted to 40 ft when normal reinforced concrete. Otherwise spans greater than that can cause lateral deflections.

One limitation of frame structures is related to span lengths. For normal reinforced concrete, spans are generally limited to around 40 feet. Exceeding this limit can lead to excessive lateral deflections, compromising structural integrity.

Imagine a long, flimsy table that bows under pressure if it’s too long without enough support. Similarly, frame structures need to balance span lengths with stability to prevent dangerous sagging.

Frame structures appear to be more flexible, economical and can carry heavy loads. Frame structures can be rehabilitated at any time. Different services can be provided in frame structures. Thus the frame structures are flexible in use.

In contrast to traditional load-bearing structures, frame structures offer superior flexibility and efficiency. They can support heavier loads without necessitating thicker walls, which saves on construction costs and allows for easier modifications and renovations.

Think of comparing a tall tree with thick branches to a bamboo plant. The tree may be heavy and rigid, while the bamboo bends and sways without breaking, showing flexibility. Similarly, frame structures adapt better to various needs than traditional buildings.

--
