31. Case Study II: GEORGE WASHINGTON BRIDGE

Whereas the forces in a cable can be determined from statics alone, its configuration must be derived from its deformation. Let us consider a cable with distributed load p(x) per unit horizontal projection of the cable length (thus neglecting the weight of the cable). An infinitesimal portion of that cable can be assumed to be a straight line, Fig. 31.1 and in the absence of any horizontal load we have H = constant.

In this chunk, we establish that we can analyze the forces acting on a cable using statics. However, to understand the shape that the cable takes under load, we need to consider how it deforms. The loads acting on the cable are 'distributed', which means they are spread out over the length of the cable rather than concentrated at a point. The mention of 'H = constant' indicates that if there is no horizontal load acting on the cable, then the horizontal component of the force (H) remains unchanged.

Think of a slack rope hanging down from two points. If you add a small weight to the middle of the rope, it will pull down and create a curve. This curve represents how the cable's shape changes under load, and we can predict this shape by analyzing how forces balance out.

Summation of the vertical forces yields (+ ?)(cid:6)F = 0 V +wdx+(V +dV) = 0, where V is the vertical component of the cable tension at x. Because the cable must be tangent to T, we have Vtan(θ) = H. Substituting into Eq. 31.1-b yields d/dx(Htan(θ)) + wdx = 0, (Htan(θ)) = w.

This chunk extends our understanding of forces acting on the cable by introducing equations that describe the balance of vertical forces. We see that the vertical component of tension in the cable, V, is related to the weight distribution (w) along the cable's length. The concept of tangents here relates to the angle at which the cable hangs (θ). By substituting different terms, we uncover how the tangential forces and weight affect the cable's shape.

Imagine holding a slingshot; the tension in the rubber band can be thought of as the vertical tension V. When you pull back the band, you can see how the angle changes. Understanding these forces allows engineers to design and build bridges like the George Washington Bridge safely.

For a cable subjected to a uniform load w, we can determine its shape by double integration of Eq. 31.5. The resulting equations show that v = x(L - x) for the vertical displacement of the cable.

This segment discusses how to calculate the cable's shape under uniform loading by integrating the equations derived earlier. The formula v = x(L - x) indicates that the vertical position (v) depends on the distance along the cable (x) and overall span (L). This results in a parabolic shape, which is characteristic of suspended cables under uniform loads.

Picture a parabolic curve, like a hanging piece of spaghetti. When tension is applied evenly, the spaghetti bends into a nice curve, illustrating how suspension cables behave under weight. This shape is crucial when designing large structures.

Since the maximum sag h occurs at midspan (x = L), we can solve for the horizontal force H as H = (wL^2)/(8h). This relation clearly shows that the horizontal force is inversely proportional to the sag h.

Here, we learn how to calculate the horizontal force (H) acting on the cable based on the sag (h) and load (w). The equation indicates that as sag increases, the required horizontal force decreases. This inverse relationship is crucial for ensuring that bridges like the George Washington Bridge remain stable and safe under load.

Consider two people trying to pull a rope; if one side is lower (more sag), it means the other side is under less tension to keep it taut. This visual can help understand why understanding the relationship between sag and force is vital for structural engineers.

Whereas the horizontal force H is constant throughout the cable, the tension T varies. The maximum tension occurs at the support where the vertical component V = wL/2 and horizontal one is H.

In this chunk, we differentiate between horizontal force and vertical tension. While H remains constant, the tension (T) experienced by the cable varies along its length, peaking at the supports where the load is greatest. This informs engineers about the stresses that can occur within the cable when subjected to various forces.

Think of a hammock strung between two trees. The tension is highest where the hammock is attached to the trees because that’s where the weight is concentrated. Similarly, cables need to be analyzed to ensure they won't snap at these high-stress points.

Had we assumed a uniform load w per length of cable, the equation would have been one of a catenary. The cable between transmission towers is a good example of a catenary.

This section introduces the concept of a catenary, which describes the shape a flexible chain or cable assumes under its own weight when supported at its ends. Understanding the catenary is important because it has real-world applications in various structures, such as cable-stayed bridges and suspension bridges.

If you hang a chain from two points and let it drape down, the resulting curve is a catenary. This helps visualize how cables work in real-world applications like the George Washington Bridge, where engineers use calculations based on these shapes to optimize safety and efficiency.

--
