Introduction to Bolted Connections
Unlock Audio Lesson
Today, we will talk about bolted connections used in steel structures. Bolted connections are becoming more popular than rivets and welding due to their ease of installation and reduced risk of failure. Can anyone tell me why that might be?
Maybe it's because they're quicker to install?
Exactly! They're less labor-intensive. Rivets need more effort to install correctly, while welding can create critical weaknesses if not done properly. Now, let's discuss the types of bolts commonly used.
What are the most common types?
Great question! The two most common high-strength bolts are A325 and A490, which have different strength properties and applications. Remember: A325 is made from heat-treated medium carbon steel, while A490 is made from an alloy of steel and is even stronger.
How do we know which size to use?
Good observation! The size of the bolt often depends on the application. We typically use bolts such as 3/4" or 1" for various constructions. Don't forget to check the nominal area in Table 23.1 for specific applications!
Types of Bolted Connections
Unlock Audio Lesson
Now let’s delve into the two types of bolted connections: bearing type and slip-critical. Can someone explain the difference?
I think bearing type uses shear and bearing to transmit loads?
Spot on! The bearing type transmits loads through a combination of shear and bearing on the bolt itself. In contrast, slip-critical relies on friction, and it is crucial that it doesn’t slip under service loads. Can anyone think of scenarios where one type might be preferred over the other?
Maybe in an area where vibrations are high, slip-critical would be better?
Absolutely! Good thinking. The choice depends on the environment and load conditions.
Nominal Strength of Bolts
Unlock Audio Lesson
Next, we need to understand how to calculate the nominal strength of bolts. The equation is essential for ensuring our connections are secure. Who remembers the formula?
Is it R = F_b A_n?
Close! It’s R = F_b A_n, where F_b is the tensile strength of the bolt and A_n is the tensile stress area. This ratio is crucial for determining the strength of each bolt. Can anyone explain why this might be important?
If we get it wrong, the structure could fail?
Exactly! Proper calculations ensure the integrity of the structure. Always check the tensile stress area against the gross area too!
