5.11.2 - Collisions in One Dimension
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Momentum Conservation
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we're going to talk about momentum conservation in collisions. Can anyone tell me what momentum is?
Isn't momentum the mass of an object multiplied by its velocity?
Correct! And we denote momentum with the letter 'p'. Now, during a collision, the total momentum before the event equals the total momentum after. This is called the conservation of momentum. Does anyone know why this principle is important?
It helps us predict the outcome of the collision, right?
Exactly! So if we know the masses and one object's speed before a collision, we can find the speeds after. Let’s look at the formula: m1v1i = m2v2i + m2v2f. Remember, if both bodies collide, the total momentum is preserved. This means we can create equations to solve for unknowns!
Can you give a simple example?
Sure! If an object with mass 2 kg is moving at 3 m/s and collides with a stationary object of mass 3 kg, how can we calculate the final speed?
Wouldn't we set up the equation like 2 * 3 = (2 + 3) * vf?
Great job! Now, by solving that, we can find the final speed. Always remember the conservation law! We'll recap this point at the end.
Types of Collisions
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now let's distinguish between elastic and inelastic collisions. Who can define an elastic collision for me?
In elastic collisions, both momentum and kinetic energy are conserved.
Exactly! Conversely, inelastic collisions only conserve momentum. Kinetic energy is transformed into other forms, like thermal energy. For example, imagine two cars colliding at low speed—they crumple, converting energy to sound and heat.
So the total kinetic energy after isn’t the same as before?
That's right! The lost kinetic energy is called ‘work done’ during the collision. We can calculate it using the formula we've seen before. For an elastic collision, remember that we have two equations to work with!
Wait, does that mean that in a completely inelastic collision the two masses stick together?
Yes, when two objects undergo a completely inelastic collision, they indeed stick together after colliding. That leads to maximum kinetic energy loss. Here’s a formula for energy loss we can use when they stick: ∆K = K_initial - K_final.
What are some real-world examples of elastic collisions?
Great question! Billiards or ball bouncing are classic examples of elastic collisions, where very little energy is lost. Let's keep an eye on these concepts as we delve deeper.
Kinetic Energy Changes
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Next, let's dive into kinetic energy changes during collisions. Kinetic energy before a collision can be compared to the kinetic energy after. Who remembers the kinetic energy formula?
It's K = (1/2)mv²!
Correct! Now, if we have an elastic collision, kinetic energy before is equal to kinetic energy after. But for a completely inelastic collision, we will see a drop in kinetic energy. For example, if two objects collide, we can calculate this change as follows: ∆K = K_initial - K_final.
So, in a head-on collision, even if they stick together, how is the energy dissipated?
Great observation! The energy is dissipated mostly as sound, heat, and deformation. Let’s analyze a situation: if mass 1 is 3 kg moving at 4 m/s and mass 2 is 5 kg stationary, after a completely inelastic collision, we find the kinetic energy loss.
Could we predict how fast they'll move together?
Absolutely! By applying the momentum formula, we combine their momenta and calculate their common velocity. This method is vital in analyzing real-life collisions.
That seems really useful in crash tests!
Exactly! Understanding the physics behind collisions allows engineers to design safer vehicles.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
In this section, we explore the characteristics of collisions in one dimension. Key concepts include momentum conservation, equations governing elastic and inelastic collisions, and the changes in kinetic energy associated with these collisions. The section also presents various formulas related to momentum and kinetic energy, aiding in analyzing such physical interactions.
Detailed
Collisions in One Dimension
This section examines the nature of collisions in one dimension, focusing on both elastic and completely inelastic collisions. During any collision, the central concept is the conservation of linear momentum, which states that the total momentum before the collision is equal to the total momentum after the collision.
Key Points:
- Completely Inelastic Collision: In this type of collision, two objects stick together after colliding. The momentum conservation equation for a completely inelastic collision is:
m1v1i = (m1 + m2)vf
Where:
- m1 and m2 are the masses of the objects.
- v1i is the initial speed of the moving mass.
- vf is the final speed of both masses after the collision.
- Kinetic Energy Loss: The loss in kinetic energy (∆K) during a completely inelastic collision is derived from:
∆K = K_initial - K_final = (1/2m1v1i^2 + 1/2m2v2i^2) - (1/2(m1 + m2)vf^2)
This formula highlights how kinetic energy is not conserved in inelastic collisions due to energy being transformed into other energy forms, such as heat.
- Elastic Collision: In elastic collisions, both momentum and kinetic energy are conserved. The equations governing elastic collisions are:
m1v1i = m1v1f + m2v2f
and
K_initial = K_final
Through manipulations of these equations, relationships between the final velocities of both masses post-collision can be established.
- Maximal Energy Transfer: Under certain conditions, such as when one mass is significantly larger than the other, a substantial amount of the kinetic energy can be transferred.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Completely Inelastic Collision
Chapter 1 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Consider first a completely inelastic collision in one dimension.
\[ \theta_1 = \theta_2 = 0 \]
\[ m_1 v_{1i} = (m_1 + m_2) v_f \quad (\text{momentum conservation}) \]
\[ v_f = \frac{m_1}{m_1 + m_2} v_{1i} \]
The loss in kinetic energy on collision is
\[ \Delta K = \frac{1}{2} m_1 v_{i1}^2 - \frac{1}{2} (m_1 + m_2) v_f^2 \]
\[ = \frac{1}{2} m_1 v_{i1}^2 - \frac{1}{2} \frac{m_2^2}{m_1 + m_2} v_{i2}^2 \]
\[ = \frac{1}{2} m_1 v_{i1}^2 \left[ 1 - \frac{m_1}{m_1 + m_2} \right] \]
\[ = \frac{1}{2} \frac{m_1 m_2}{m_1 + m_2} v_{i1}^2 \]
Detailed Explanation
In a completely inelastic collision, the two colliding objects stick together after the collision. We denote the initial mass of the first object as m1 moving with an initial velocity v1i. The second mass, m2, is initially at rest. After the collision, both masses move with a common final velocity vf. The law of conservation of momentum holds, so we can set up the equation m1v1i = (m1 + m2)vf, leading to the equation for the final velocity of the combined masses. Moreover, this type of collision results in the maximum loss of kinetic energy, which is calculated by comparing the initial and final kinetic energy, showing that energy is converted into other forms (like sound or heat) during the collision.
Examples & Analogies
Imagine two cars colliding at an intersection and sticking together after the impact. This would be an example of a completely inelastic collision. In this scenario, both vehicles would experience significant deformation and would move together in the same direction after the collision, demonstrating how momentum is conserved while kinetic energy is lost.
Elastic Collision
Chapter 2 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Consider next an elastic collision. Using the above nomenclature with θ1 = θ2 = 0, the momentum and kinetic energy conservation equations are
\begin{align}
m_1 V_{1i} + m_2 V_{2i} &= m_1 V_{1f} + m_2 V_{2f} ag{5.23} \
m_1 U_{1i}^2 + m_2 U_{2i}^2 &= m_1 U_{1f}^2 + m_2 U_{2f}^2 ag{5.24} \
\text{From Eqs. (5.23) and (5.24) it follows that,} \
\quad m_{1} \left( V_{1f} - V_{1i} \right) &= m_{2} \left( V_{2f} - V_{2i} \right) \
\text{or,} \
v_{2f} - v_{1f} &= (v_{1i} - v_{2i}) \
\text{Hence,}
\quad v_{2f} &= v_{1i} + v_{1f} \
\text{Substituting this in Eq. (5.23), we obtain} \
v_{1f} &= \frac{(m_{1} - m_{2})}{(m_{1} + m_{2})} v_{1i} ag{5.26} \
\text{and} \
v_{2f} &= \frac{2 m_{2}}{(m_{1} + m_{2})} v_{1i}
\end{align}
Detailed Explanation
In an elastic collision, both momentum and kinetic energy are conserved. The elastic nature of this collision means that no kinetic energy is transformed into other forms of energy. Using the same notation as the previous example, we can express both momentum (m1v1i = m1v1f + m2v2f) and kinetic energy (1/2 m1 v1i^2 = 1/2 m1 v1f^2 + 1/2 m2 v2f^2) conservation equations. These equations allow us to relate the initial and final velocities of the objects involved in the collision, thereby deriving the final speeds of both objects after the collision.
Examples & Analogies
Think of two bouncing balls colliding elastically. When one ball (the cue ball) strikes another stationary ball (the target ball) with a certain speed, they collide and bounce off each other while conserving both momentum and kinetic energy. After the impact, the durations of the contact are very short, and if these balls are of equal mass, they will move apart at right angles to each other depending on their angles of approach, which beautifully showcases both momentum and energy conservation.
Special Cases in Elastic Collisions
Chapter 3 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Special cases of our analysis are interesting. Case I: If the two masses are equal v1f = 0 v2f = v1i The first mass comes to rest and pushes off the second mass with its initial speed on collision. Case II: If one mass dominates, e.g. m2 > > m1 v1f ~ −v1i v2f ~ 0 The heavier mass is undisturbed while the lighter mass reverses its velocity.
Detailed Explanation
In elastic collisions, considering some specific cases can yield interesting results. In Case I, where two objects of equal mass collide elastically, the first object stops moving and transfers its velocity to the second object. This is akin to one ball transferring its motion to another. In Case II, where one mass is significantly larger than the other, the larger mass is hardly affected, while the smaller mass can rebound with a nearly opposite velocity. These cases highlight the dynamics of conservation laws as applied to different mass ratios.
Examples & Analogies
Imagine a game of billiards where the cue ball strikes the eight ball. If both balls are of equal mass and the cue ball is moving toward the stationary eight ball, after the collision, the cue ball stops while the eight ball rolls off with the cue ball's original speed. Conversely, if the cue ball hits a much heavier stationary ball, it will bounce back almost in the direction it came from, while the heavier ball barely moves, illustrating the effects of mass disparity in elastic collisions.
Key Concepts
-
Momentum Conservation: The principle that the total momentum remains constant before and after a collision.
-
Elastic Collision: A collision type where both kinetic energy and momentum are conserved.
-
Inelastic Collision: A collision where momentum is conserved, but kinetic energy changes.
-
Kinetic Energy Loss: The difference in kinetic energy before and after an inelastic collision.
Examples & Applications
Example 1: A car crashes and the two cars crumple together indicating it's an inelastic collision, with energy lost to heat and sound.
Example 2: Two billiard balls collide and bounce off with new velocities maintaining both momentum and kinetic energy.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
In elastic strikes, energy abounds, inelastic scrunch, where energy drowns.
Stories
Imagine two balls bouncing perfectly off each other in a game, their energy intact—an elastic collision. Now picture two cars colliding, crumpled together—an inelastic crash where energy is lost.
Memory Tools
MEL - Momentum Equals Loss (in inelastic collisions).
Acronyms
CEM - Conservation of Energy and Momentum.
Flash Cards
Glossary
- Momentum
The product of an object's mass and velocity, conserved during collisions.
- Elastic Collision
A collision where both momentum and kinetic energy are conserved.
- Inelastic Collision
A collision where momentum is conserved, but kinetic energy is not.
- Kinetic Energy
The energy an object possesses due to its motion, calculated as K = (1/2)mv².
