8.7.1 - Magnetic Force

Interactive Audio Lesson

Listen to a student-teacher conversation explaining the topic in a relatable way.

Introduction to Magnetic Forces

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Today, we are going to investigate a fascinating topic: magnetic forces. Can anyone tell me what magnetic force is?

Student 1
Student 1

Isn't it the force that magnets use to attract other materials?

Teacher
Teacher

Exactly! Magnetic force is the attraction or repulsion between objects due to their magnetic properties. Magnets can pull certain metals, like iron, towards them without even touching them. This brings us to a great mnemonic to remember: 'MAGNET'—Magnets Attract and Generate Non-contact Energy Together.

Student 2
Student 2

So, does that mean there are different types of magnets?

Teacher
Teacher

Yes! We have permanent magnets, like fridge magnets, and temporary magnets, which become magnetized in the presence of a magnetic field. Can anyone think of an example of where we see magnets in our daily lives?

Student 3
Student 3

How about in compasses?

Teacher
Teacher

Great observation! A compass uses magnetic force to help us find direction. Now, how do magnetic forces work when two magnets come close to each other?

Student 4
Student 4

If they are opposite poles, they attract; if they are the same poles, they repel!

Teacher
Teacher

Correct! Remember, 'Like poles repel, unlike poles attract'. Let's summarize what we've learned so far: magnetic force is a non-contact force that can either attract or repel materials based on their magnetic polarity!

Experiments with Magnetic Force

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Now that we understand what magnetic forces are, let’s conduct an experiment using two bar magnets. Who can explain what they think will happen when the same poles face each other?

Student 1
Student 1

I think they will push away from each other!

Teacher
Teacher

Great prediction! Let’s observe it. Now, what about the opposite poles?

Student 2
Student 2

Those should pull towards each other.

Teacher
Teacher

Exactly! As you conduct this experiment, keep in mind the acronym 'PUSH'—Polarities In the Same direction cause a 'Push.' Polarities in Opposite directions cause a 'Pull.'

Student 3
Student 3

Let’s see if we can find some iron shavings to see how they react around the magnets.

Teacher
Teacher

Perfect! Observing how iron filings align along magnetic field lines will be enlightening. Remember to note down your observations!

Student 4
Student 4

This is exciting! We’re actually seeing the force in action.

Teacher
Teacher

Now, let's summarize our findings: magnetic forces can attract iron objects even from a distance, demonstrating their non-contact nature. By using our magnets, we explored how different poles interact!

Applications of Magnetic Forces

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

As we wrap up, let's talk about where we see magnetic forces in action in our world. Can anyone name a few?

Student 1
Student 1

I know they are used in motors and generators!

Teacher
Teacher

Absolutely! Motors use magnetic fields to create motion. Our next memory aid will help us remember applications: 'MAGIC,' which stands for Motors, Appliances, Generators, Instruments, and Compasses.

Student 2
Student 2

What about in medical devices? I've heard of MRI machines.

Teacher
Teacher

Yes! MRI machines utilize strong magnetic fields for imaging. It's incredible how vital magnetic forces are in technology today!

Student 3
Student 3

This makes me curious about how we might use magnets in the future.

Teacher
Teacher

That’s the spirit of inquiry! Always ask how existing science can lead to new innovations. To sum up today’s lesson, we learned that magnetic forces are integral to many aspects of technology and help us understand the world around us.

Introduction & Overview

Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.

Quick Overview

This section introduces the concept of magnetic force as a non-contact force that can either attract or repel objects.

Standard

In this section, we discuss the nature of magnetic force, showcasing how magnets can attract materials like iron and repel each other based on polarity. The section emphasizes the non-contact attributes of magnetic forces along with practical activities to observe these phenomena.

Detailed

Youtube Videos

Force and Pressure Full Chapter Class 8 Science | NCERT Science Class 8 Chapter 11
Force and Pressure Full Chapter Class 8 Science | NCERT Science Class 8 Chapter 11
Force and Pressure Class 8
Force and Pressure Class 8
Class 8 Science Chapter 11 | Force And Pressure Full Chapter Explanation (Part 1)
Class 8 Science Chapter 11 | Force And Pressure Full Chapter Explanation (Part 1)
Class 8 Science Chapter 11 | Introduction - Force and Pressure
Class 8 Science Chapter 11 | Introduction - Force and Pressure
Force and Pressure Class 8 Science - Pressure
Force and Pressure Class 8 Science - Pressure
Force and Pressure - Full Chapter Explanation & NCERT Solutions | Class 8 Science Chapter 11
Force and Pressure - Full Chapter Explanation & NCERT Solutions | Class 8 Science Chapter 11

Audio Book

Dive deep into the subject with an immersive audiobook experience.

Understanding Magnetic Force

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Activity 8.6

Take a pair of bar magnets. Place the longer side of one of the magnets over three round shaped pencils or wooden rollers as shown in Fig. 8.10. Now bring one end of the other magnet near the end of the magnet placed on the rollers. Make sure that the two magnets do not touch each other. Observe what happens. Next, bring the other end of the magnet near the same end of the magnet placed on the rollers (Fig. 8.10). Note what happens to the magnet placed on the rollers every time another magnet is brought near it.

Detailed Explanation

In this activity, you use two bar magnets to explore how they interact with each other without making contact. When you bring one magnet near another while they are placed on rollers, you'll notice that one magnet can either attract or repel the other. This capability to exert a force without direct contact is what defines a magnetic force. The attraction occurs when opposite poles of the magnets face each other, while the same poles will repel each other.

Examples & Analogies

Think of how magnets are used on refrigerator doors. They hold the door closed without touching any other part, illustrating how magnetic force operates at a distance. This is similar to how Earth’s gravity pulls objects towards it without needing to touch them.

Electrostatic Force

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

A straw is said to have acquired electrostatic charge after it has been rubbed with a sheet of paper. Such a straw is an example of a charged body. The force exerted by a charged body on another charged or uncharged body is known as electrostatic force. This force comes into play even when the bodies are not in contact. The electrostatic force, therefore, is another example of a non-contact force.

Detailed Explanation

When you rub a straw with paper, electrons move, causing the straw to gain a charge. When you bring this charged straw close to another straw, it can either attract or repel it based on their charges. This interaction happens without the two straws touching, demonstrating that electrostatic force, like magnetic force, is a non-contact force.

Examples & Analogies

You might have seen how your hair stands up when you take off a woolen hat. This happens because of the static electricity generated by the friction between the hat and your hair, which creates an electrostatic force.

Gravitational Force

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Objects or things fall towards the earth because it pulls them. This force is called the force of gravity, or just gravity. This is an attractive force. The force of gravity acts on all objects. The force of gravity acts on all of us all the time without our being aware of it. Water begins to flow towards the ground as soon as we open a tap. Water in rivers flows downward due to the force of gravity.

Detailed Explanation

Gravitational force is what keeps you grounded and pulls objects toward the center of the Earth. It acts on everything, giving weight to all materials, and this force is what causes orbits in space and natural movements of planets. For example, when you drop a ball, gravity pulls it downward.

Examples & Analogies

Imagine throwing a ball up into the air. It rises for a moment but eventually falls back down due to gravity pulling it back toward the Earth, similar to how the Moon orbits the Earth because of gravitational attraction.

Conclusion on Non-contact Forces

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Does the magnet on the rollers begin to move when the other magnet is brought near it? Does it always move in the direction of the approaching magnet? What do these observations suggest? Does it mean that some force must be acting between the two magnets? You have learned in Class VI that like poles of two magnets repel each other and unlike poles attract each other. Attraction or repulsion between objects can also be seen as another form of pull or push.

Detailed Explanation

These observations lead to the conclusion that non-contact forces, such as magnetic force, electrostatic force, and gravitational force, still have significant effects on the movement of objects. Each of these forces have specific characteristics (like attraction or repulsion) that dictate how they interact with various materials.

Examples & Analogies

Think about roller coasters. Just as the forces acting on the roller coaster can make it zoom down hills or rise high into the air, non-contact forces like magnetism and gravity influence the movement of everything around us in subtle and powerful ways.

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Magnetic poles: The regions on a magnet where the magnetic force is strongest.

  • Attraction and Repulsion: The fundamental behavior of magnets that either pull objects towards them or push them away.

  • Non-contact force: A force that can act at a distance without physical contact.

Examples & Real-Life Applications

See how the concepts apply in real-world scenarios to understand their practical implications.

Examples

  • A refrigerator magnet sticking to the door demonstrates magnetic attraction.

  • A compass showing direction utilizes Earth's magnetic field.

Memory Aids

Use mnemonics, acronyms, or visual cues to help remember key information more easily.

🎵 Rhymes Time

  • Magnets attract and repel, with forces we can tell.

📖 Fascinating Stories

  • Once upon a time, two magnets met. The north pole wanted to hug the south, but the same poles turned away. They taught us that opposites attract while brothers repel.

🧠 Other Memory Gems

  • PULL - Poles Unite, Like repels.

🎯 Super Acronyms

MOTION - Magnets Offer Two Interactions

  • Opposite is Nice.

Flash Cards

Review key concepts with flashcards.

Glossary of Terms

Review the Definitions for terms.

  • Term: Magnetic Force

    Definition:

    The force exerted by magnets to attract or repel other objects.

  • Term: Permanent Magnets

    Definition:

    Magnets that maintain their magnetic properties over time.

  • Term: Temporary Magnets

    Definition:

    Materials that exhibit magnetic properties only in the presence of a strong magnetic field.

  • Term: Poles

    Definition:

    The two ends of a magnet where the magnetic force is strongest; commonly referred to as north and south poles.

  • Term: Electromagnetism

    Definition:

    The interaction between electricity and magnetism.

  • Term: Attraction

    Definition:

    The force that pulls objects towards each other.

  • Term: Repulsion

    Definition:

    The force that pushes objects away from each other.
