9.1 - Angle Subtended by a Chord at a Point

Interactive Audio Lesson

Listen to a student-teacher conversation explaining the topic in a relatable way.

Definition of Angles and Chords

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Welcome, everyone! Today we're exploring angles subtended by chords at points within a circle. To start, does anyone know what a chord is?

Student 1
Student 1

Isn't a chord a line segment that connects two points on a circle?

Teacher
Teacher

Exactly! Now, if I take a chord PQ and join a point R to it, the angle PRQ is formed. This angle is called the angle subtended at point R. Can anyone tell me how it compares to the angle at the center?

Student 2
Student 2

I think the angle at the center is larger than that at any other point on the circle, right?

Teacher
Teacher

Correct! The angle at the center is the largest. Let's remember that: larger chords correspond to larger angles at the center. This helps in visualizing relationships in circle geometry.

Relationship of Equal Chords

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Now, let's dive into equal chords. If two chords are equal, what can we say about the angles they subtend at the center?

Student 3
Student 3

They should subtend equal angles at the center, right?

Teacher
Teacher

That's exactly right! This leads us to Theorem 9.1 which states that if two chords are equal, they subtend equal angles at the center. Let's have a quick memory aid: think of 'Equal Chords, Equal Angles'—it’s simple to recall!

Student 4
Student 4

Does that mean if two angles are equal, the chords must also be equal?

Teacher
Teacher

Good question! That's covered in Theorem 9.2. If the angles subtended are equal, the chords are equal as well.

Perpendiculars and Bisection

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Let's examine a new property: a perpendicular from the center of a circle to a chord bisects that chord. How do you think we can prove this?

Student 1
Student 1

Maybe we can draw a diagram and use triangles?

Teacher
Teacher

Exactly! By showing that the triangles formed on either side of the perpendicular are congruent, we can conclude that the chord is bisected. Remember this: 'If it's perpendicular, it's bisected!'

Student 2
Student 2

What happens if we know a chord is bisected? Does that mean the perpendicular comes from the center?

Teacher
Teacher

Great connection! That's our next theorem. If a line from the center bisects a chord, it must be perpendicular!

Introduction & Overview

Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.

Quick Overview

This section explores the angles subtended by chords at different points within a circle, emphasizing the relationship between chord lengths and the angles they subtend.

Standard

It discusses how the angle subtended by a chord at the center of a circle relates to the lengths of the chords and their distances from the circle's center. Key properties about equal chords and their subtended angles are elaborated upon through theorems and interactive activities.

Detailed

In this section, we delve into the concept of angles subtended by chords in a circle. When a chord is joined to a point outside the line segment, it creates an angle known as the angle subtended by the chord. The section establishes that the larger the chord, the larger the angle it subtends at the center of the circle. It presents two critical theorems proving that equal chords in a circle subtend equal angles at the center, and conversely, chords that subtend equal angles are equal in length. Moreover, the diagonal proofs and activities provided help to visualize and solidify the understanding of these properties, making them essential for grasping circle geometry.


Youtube Videos

Class 9th - Angle Subtended by a chord at a point
Class 9th - Angle Subtended by a chord at a point
Chapter:10 Theorem: (10.8)(10.9)(10.10)(10.11)(10.12) Circles | Ncert Maths Class 9 | Cbse.
Chapter:10 Theorem: (10.8)(10.9)(10.10)(10.11)(10.12) Circles | Ncert Maths Class 9 | Cbse.
Theorem 9.7 Circles class 9 Maths New syllabus 2023-24 | Theorem 10.8 class 9th Circles old Ncert
Theorem 9.7 Circles class 9 Maths New syllabus 2023-24 | Theorem 10.8 class 9th Circles old Ncert
Every Theorem on Circle with Proofs.| Theorem on Circles.| Class 9 |NCERT.
Every Theorem on Circle with Proofs.| Theorem on Circles.| Class 9 |NCERT.
Angle Subtended by a Chord at a Point (Theorem 10.1 & 10.2) - Circles | Class 9 Maths Chapter 10
Angle Subtended by a Chord at a Point (Theorem 10.1 & 10.2) - Circles | Class 9 Maths Chapter 10
NCERT Grade 9 || CBSE Class 9 - Circles Angle Subtended by a Chord at a Point in Tamil
NCERT Grade 9 || CBSE Class 9 - Circles Angle Subtended by a Chord at a Point in Tamil
Class 9th , Ex - 10 Theorem 10.8 ( Circles ) CBSE NCERT
Class 9th , Ex - 10 Theorem 10.8 ( Circles ) CBSE NCERT
Chapter:10 (Theorem:10.2) Circles | Ncert Maths Class 9 | Cbse.
Chapter:10 (Theorem:10.2) Circles | Ncert Maths Class 9 | Cbse.
Geometry everyone should learn
Geometry everyone should learn
Chapter:10 Ex.10.5 (Q.2) Circles | Ncert Maths Class 9 | Cbse.
Chapter:10 Ex.10.5 (Q.2) Circles | Ncert Maths Class 9 | Cbse.

Audio Book

Dive deep into the subject with an immersive audiobook experience.

Definition of Angle Subtended by a Chord

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

You have already studied about circles and its parts in Class VI.
Take a line segment PQ and a point R not on the line containing PQ. Join PR and QR. Then ∠ PRQ is called the angle subtended by the line segment PQ at the point R.

Detailed Explanation

In this section, we introduce the concept of angles subtended by a chord at a given point outside the line containing the chord. When we have a line segment (the chord) named PQ and a point R that is not on the same line, we can draw two lines connecting R to the endpoints of the chord. The angle formed by these two lines (PR and QR) is called ∠ PRQ. This angle represents the measure of how 'open' or 'wide' the angle appears from the perspective of point R.

Examples & Analogies

Imagine you are standing on a street at point R, and you are looking at two corners of a building positioned at points P and Q. The view you have in front of you, created by the lines of sight from your eyes to each corner of the building, represents the angle ∠ PRQ. The further away you stand, the smaller this angle will appear, while standing closer makes it wider.

Angles Subtended at Different Points

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

What are angles POQ, PRQ and PSQ called? ∠ POQ is the angle subtended by the chord PQ at the centre O, ∠ PRQ and ∠ PSQ are respectively the angles subtended by PQ at points R and S on the major and minor arcs PQ.

Detailed Explanation

In relation to the chord PQ, we differentiate between three key angles: 1. ∠ POQ, which is the angle subtended at the center of the circle (point O) by the chord PQ. This angle gives us a good idea of the span of the chord in the circle. 2. ∠ PRQ is the angle at point R, as described earlier. 3. ∠ PSQ is similar to ∠ PRQ but positioned at point S, on the opposite side of the chord. The distinguishing factor lies in which arc is larger or smaller, leading to different measures of angles from these external points.

Examples & Analogies

Think of holding a pizza (the circle) in front of you. The slice (the chord) is PQ. If you look at the tip of the pizza slice from the center (O), you see the angle POQ. If you shift your position and look from a point to the side (like points R and S), you will see different angles corresponding to those positions despite looking at the same slice.

Relationship Between Chord Length and Angles

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Let us examine the relationship between the size of the chord and the angle subtended by it at the centre. You may see by drawing different chords of a circle and angles subtended by them at the centre that the longer the chord, the bigger will be the angle subtended by it at the centre.

Detailed Explanation

This chunk helps us understand an important relationship in circles: as the length of the chord increases, the angle it subtends at the center also increases. To grasp this, envision drawing an arc from the center to the endpoints of the chord. A longer chord also extends across a larger section of the circle, presenting a wider angle at the center. This could be represented mathematically but can also be visually observed by sketching different lengths of chords within the same circle.

Examples & Analogies

Picture a fan with blades. The longer the blade (the chord in this example), the more area it covers in front of the fan. If you imagine standing at the center of the fan, longer blades create a larger viewing angle than shorter ones. You can even relate it to how more opened-out arms mean a larger angle when you stretch out your arms compared to having them close together.

Equal Chords Subtend Equal Angles

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

What will happen if you take two equal chords of a circle? Will the angles subtended at the centre be the same or not? Draw two or more equal chords of a circle and measure the angles subtended by them at the centre.

Detailed Explanation

When we take two equal chords in a circle, it raises the question of whether they subtend equal angles at the center. If we were to measure the angles created by these equal chords at the center, we would find that they are indeed equal. This equality can be proven geometrically by showing that the triangles formed by the chords and the radii to their endpoints are congruent, leading to the conclusion that their respective angles are also congruent.

Examples & Analogies

Imagine two identical slices of cake on a circular plate. By measuring the angles from the center of the plate to the points where the slices touch the edges, you'll find the angles are identical — corresponding to the equal sizes of your slices. This is a common pattern seen in regular shapes when they are symmetrically arranged.

Theorem Proof for Equal Chords

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Theorem 9.1: Equal chords of a circle subtend equal angles at the centre. Proof: You are given two equal chords AB and CD of a circle with centre O. You want to prove that ∠ AOB = ∠ COD.

Detailed Explanation

To prove that equal chords subtend equal angles, we examine triangles formed by the radii and the chords. Given that both chords are equal in length and also equal to the radii of the circle leading to the points where the chords touch the circle, we can show that those triangles contain two sides that are equal and the base (the chord) is also equal. Thus, the angles subtended at the center from both chords are also equal due to the property of congruent triangles.

Examples & Analogies

Think of identical pairs of eyeglasses where the arms of each are similarly set out and the lenses are of the same size. Just like identical glasses creating the same visual angles when viewed, equal chords maintain the angle symmetry in the circle.

Exploring Consequences of Equal Angles

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Now if two chords of a circle subtend equal angles at the centre, what can you say about the chords? Are they equal or not? Let us examine this by the following activity.

Detailed Explanation

This section asks us to consider a situation where angles are equal at the center but we need to find out if this implies that the chords must also be equal. By tracing around the circles and cutting the discs along the specified angles, we can literally overlap the arcs created and see whether they remain congruent, which will provide proof that the chords are indeed equal.

Examples & Analogies

Imagine drawing two identical arcs in sand using two sticks. If you create the same arc lengths (following equal angles) from the same center, aligning them perfectly would show they cover the same distance on the ground — demonstrating their equality. This is like perfectly matching pair pieces in a puzzle.

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Angle Subtended by a Chord: The angle formed at a point (within or on the circle) by lines drawn to the endpoints of the chord.

  • Equal Chords: Chords of equal lengths that subtend equal angles at the center.

  • Theorems of Chords: Statements regarding the properties of chords in relation to angles and distances from the circle's center.

Examples & Real-Life Applications

See how the concepts apply in real-world scenarios to understand their practical implications.

Examples

  • {'example': 'Example 1: Given equal chords AB and CD of a circle. Prove that their angles at the center, ∠AOB and ∠COD, are equal.', 'solution': 'Given: AB = CD; we know OA = OB = OC = OD (radii). By SSS congruence, ΔAOB ≅ ΔCOD. Thus, ∠AOB = ∠COD.'}

  • {'example': 'Example 2: Two equal chords of a circle subtend equal angles. Prove the chords are equal.', 'solution': 'Given: ∠AOB = ∠COD; angles subtended at the center lead to ΔAOB ≅ ΔCOD. Hence, AB = CD.'}

Memory Aids

Use mnemonics, acronyms, or visual cues to help remember key information more easily.

🎵 Rhymes Time

  • Chords that are equal, angles don't differ; In circles they stay, they never quiver.

📖 Fascinating Stories

  • In a magical land of circles, two friends, AB and CD, discovered that wherever they went, their angles at the center were always equal, making them best friends forever.

🧠 Other Memory Gems

  • C.P.C.T.C. - Corresponding Parts of Congruent Triangles are Congruent!

🎯 Super Acronyms

ECA - Equal Chords Angle! Remember that equal chords subtend equal angles.

Flash Cards

Review key concepts with flashcards.

Glossary of Terms

Review the Definitions for terms.

  • Term: Chord

    Definition:

    A line segment whose endpoints are points on the circumference of a circle.

  • Term: Angle Subtended

    Definition:

    The angle formed at a given point by two lines drawn from the endpoints of a chord.

  • Term: Equal Chords

    Definition:

    Chords in a circle that have the same length.

  • Term: Center of a Circle

    Definition:

    The fixed point from which all points on the circle are equidistant.

  • Term: Perpendicular

    Definition:

    A line that meets another line at a right angle (90 degrees).
