9 - CIRCLES

Interactive Audio Lesson

Listen to a student-teacher conversation explaining the topic in a relatable way.

Understanding Angles Subtended by Chords

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Today, we're going to learn about the angles subtended by chords in a circle. Can anyone tell me what a chord is?

Student 1
Student 1

A chord is a line segment whose endpoints lie on the circle.

Teacher
Teacher

Correct! Now, if we take a chord PQ and a point R outside of it, we can say that the angle PRQ is the angle subtended by PQ at R. It shows how the position of the point changes the angle.

Student 2
Student 2

So does this mean longer chords create bigger angles?

Teacher
Teacher

Exactly! This leads us to our first theorem: the longer the chord, the larger the angle subtended at the center. Remember this with the acronym LCA: Length Creates Angle.

Student 3
Student 3

What if two chords are equal? Will the angles at the center be the same?

Teacher
Teacher

Great question! That’s where Theorem 9.1 comes in: Equal chords subtend equal angles at the center. Can anyone summarize that theorem for me?

Student 4
Student 4

If two chords are equal, then the angles they form at the center are also equal!

Teacher
Teacher

Well done! Now remember, these relationships are crucial for understanding more advanced geometric concepts.

Perpendicular from the Center to a Chord

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Let’s now discuss the perpendicular from the center to a chord. If I draw a chord AB and a line from the center O to it, what do you think happens?

Student 1
Student 1

Is it perpendicular to the chord?

Teacher
Teacher

Yes, that’s part of Theorem 9.3. This means that if you draw a perpendicular from the center to a chord, it bisects the chord! Let’s visualize this. Who can draw a diagram to help us with this rule?

Student 2
Student 2

I can! If M is the midpoint, then AM = MB.

Teacher
Teacher

Perfect! So, why does this happen? It relates back to congruent triangles. Can you remind me which triangle congruence theorem we can use here?

Student 3
Student 3

The Side-Side-Side (SSS) theorem!

Teacher
Teacher

Exactly! Since we have two triangles formed, we can say they are congruent due to equal sides, leading us to CPCT: Corresponding Parts of Congruent Triangles.

Student 4
Student 4

So the bisecting shows that both segments are equal.

Teacher
Teacher

Right! Remember, OM ⊥ AB means the chord is bisected! Keep this in mind!

The Relationship Between Chord Lengths and Distances

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Lastly, let’s explore the relationship between chord lengths and their distances from the center of the circle. Who can tell me what distance from the center is significant?

Student 1
Student 1

The perpendicular distance from the center to the chord, right?

Teacher
Teacher

Exactly! If we consider two chords, longer chords are always closer to the center than shorter ones. Let's remember this with the phrase: Longer Chords, Shorter Distances, or L.C.S.D.

Student 2
Student 2

So if two chords are equal, are they also equidistant from the center?

Teacher
Teacher

Great observation! That leads us to Theorem 9.5: Equal chords of a circle are equidistant from the center. What about the converse?

Student 3
Student 3

If the chords are equidistant from the center, then they’re equal?

Teacher
Teacher

Exactly! Keep that in mind when working with circles. To put it simply, equidistance leads to equality.

Student 4
Student 4

This makes understanding circles easier!

Teacher
Teacher

Indeed! Strong grasping of these properties will aid you in future geometry lessons!

Introduction & Overview

Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.

Quick Overview

This section explores the properties and theorems associated with circles, focusing on angles subtended by chords and the relationship between chord lengths and distances from the center.

Standard

The section covers various properties of circles, including how angles subtended by chords at the center are related to the chord's length. It introduces several theorems regarding equal chords, perpendiculars from the center to a chord, and cyclic quadrilaterals, supported by illustrations and practical exercises.

Detailed

Detailed Summary

In this section, we delve into the intricate properties of circles, principally the relationships between chords, angles, and distances from the center. The section begins by defining the angle subtended by a chord at a point on the circumference of the circle and at the center. The key takeaway is that longer chords subtend larger angles at the center, as illustrated through diagrams. Two significant theorems are presented:

  1. Theorem 9.1 states that equal chords in a circle subtend equal angles at the center, and its converse implies that if two chords subtend equal angles, then they must be equal as well.
  2. An exploration of the perpendicular from the center to a chord reveals that this line bisects the chord. This assertion is validated through triangle congruences.

The section also emphasizes relationships between chord lengths and their distances from the center, concluding that equal chords are equidistant from the center and that conversely, chords equidistant from the center are equal. Additionally, it addresses angles subtended by arcs and presents theorems regarding cyclic quadrilaterals and angles in segments.

Overall, these insights into the properties of circles are foundational for advancing into further geometry concepts and applications.

Youtube Videos

Every Theorem on Circle with Proofs.| Theorem on Circles.| Class 9 |NCERT.
Every Theorem on Circle with Proofs.| Theorem on Circles.| Class 9 |NCERT.
Circles | Introduction | Chapter 9 | SEED 2024-2025
Circles | Introduction | Chapter 9 | SEED 2024-2025
Circle Complete Chapter | All Theorems And Formulas | Quick Revision | Class 9th Maths
Circle Complete Chapter | All Theorems And Formulas | Quick Revision | Class 9th Maths
Circles | One Shot | Class 9 Maths
Circles | One Shot | Class 9 Maths
Class 9 Maths | Circles | Theorem 9.10 | Chapter 9 | NEW NCERT | CBSE 2025 -26 #class9 #cbse #ncert
Class 9 Maths | Circles | Theorem 9.10 | Chapter 9 | NEW NCERT | CBSE 2025 -26 #class9 #cbse #ncert
All Theorems | Class 9th Circle | Chapter 9 | One Shot Video | Maths Ncert
All Theorems | Class 9th Circle | Chapter 9 | One Shot Video | Maths Ncert
CBSE Class 9 || Maths || Circles || Animation || in English @digitalguruji3147
CBSE Class 9 || Maths || Circles || Animation || in English @digitalguruji3147
Circles, Surface Areas & Volumes | Areas Related to Circles | Class-10th | One Shot Revision
Circles, Surface Areas & Volumes | Areas Related to Circles | Class-10th | One Shot Revision
NCERT Grade 9 || CBSE Class 9 - Circles Theorem 10.6 in Tamil
NCERT Grade 9 || CBSE Class 9 - Circles Theorem 10.6 in Tamil
How to find centre of a circle
How to find centre of a circle

Audio Book

Dive deep into the subject with an immersive audiobook experience.

Angle Subtended by a Chord

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

You have already studied about circles and its parts in Class VI. Take a line segment PQ and a point R not on the line containing PQ. Join PR and QR. Then ∠ PRQ is called the angle subtended by the line segment PQ at the point R. What are angles POQ, PRQ and PSQ called in Fig. 9.2? ∠ POQ is the angle subtended by the chord PQ at the centre O, ∠ PRQ and ∠ PSQ are respectively the angles subtended by PQ at points R and S on the major and minor arcs PQ.

Detailed Explanation

This chunk explains the concept of angles subtended by a chord. A chord is a line segment connecting two points on a circle. The angle formed at a point outside the chord (like point R) is termed as 'angle subtended by the chord'. Here, ∠ POQ, formed at the circle's center by the same endpoints as the chord, is mentioned as well as angles formed on the arcs of the circle by points R and S.

Examples & Analogies

Think about a pizza. If you have a slice cut by a line (chord), and you're observing it from a point outside that slice, the angle you see formed at that outside point is similar to ∠ PRQ. The larger the slice of pizza you choose (the bigger the chord), the bigger the angle you see!

Relationship Between Chord Length and Angle

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Let us examine the relationship between the size of the chord and the angle subtended by it at the centre. You may see by drawing different chords of a circle and angles subtended by them at the centre that the longer is the chord, the bigger will be the angle subtended by it at the centre. What will happen if you take two equal chords of a circle?

Detailed Explanation

In this chunk, the relationship is established between the length of a chord and the angle it subtends at the center of the circle. As a chord increases in length, the angle at the center formed by the chord also increases. This observation leads to the idea that chords of equal length will subtend equal angles at the center.

Examples & Analogies

Imagine a rubber band stretched into different lengths. When the band is short and stretched tight, the angle you can hold it at increases as you stretch it further. Just like in our example with the chords, when the rubber band is longer, you can see a wider stretch (larger angle) at the center.

Equal Chords Subtend Equal Angles

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Draw two or more equal chords of a circle and measure the angles subtended by them at the centre. You will find that the angles subtended by them at the centre are equal.

Detailed Explanation

This part states that if two chords of equal length are drawn in a circle, the angles they subtend at the center of the circle will also be equal. This is a fundamental property of circles that can be proved mathematically through congruent triangles formed by the radii of the circle connecting to both chords.

Examples & Analogies

Think of two identical ropes hanging from a tree. If you make them both the same length and attach them to the same point, when you pull them outwards to form angles, they will form the same angle at the tree (the analogy of the center of a circle!).

Proof of Equal Chords Subtending Equal Angles

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Theorem 9.1 : Equal chords of a circle subtend equal angles at the centre. Proof: You are given two equal chords AB and CD of a circle with centre O. You want to prove that ∠ AOB = ∠ COD. In triangles AOB and COD, OA = OC (Radii of a circle), OB = OD (Radii of a circle), AB = CD (Given). Therefore, ∆ AOB ≅ ∆ COD (SSS rule). This gives ∠ AOB = ∠ COD (Corresponding parts of congruent triangles).

Detailed Explanation

This chunk provides the mathematical proof for Theorem 9.1 which states that equal chords subtend equal angles at the center of the circle. By using principles of congruence (SSS - side-side-side), it is shown that the two triangles formed by the equal chords and radii are congruent, thus establishing that their corresponding angles are equal.

Examples & Analogies

Imagine two identical pizzas cut into two equal slices. When observing from the center, the angle those slices make (the angle subtended) will be exactly the same because the slices are equal in size, just like the equal chords in our theorem.

Chords Subtending Equal Angles are Equal

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Theorem 9.2 : If the angles subtended by the chords of a circle at the centre are equal, then the chords are equal. Theorem 9.4 : The line drawn through the centre of a circle to bisect a chord is perpendicular to the chord.

Detailed Explanation

Theorem 9.2 presents the converse of Theorem 9.1 — it states that if two angles subtended at the center are equal, then the corresponding chords are also equal. Theorem 9.4 introduces the concept that a line drawn from the center to bisect a chord will always meet the chord at a right angle, establishing another critical relationship.

Examples & Analogies

Think of a seesaw at a playground. If you were to balance it perfectly, the lengths on both sides would be equal. This balance is similar to how chords function with angles; equal angles maintain equal chords, akin to making sure the seesaw is balanced from the center point.

Perpendicular from the Center to a Chord

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Activity: Draw a circle on a tracing paper. Let O be its centre. Draw a chord AB. Fold the paper along a line through O so that a portion of the chord falls on the other. Let the crease cut AB at the point M. Then, ∠ OMA = ∠ OMB = 90° or OM is perpendicular to AB.

Detailed Explanation

This chunk introduces an activity to visualize how a line drawn from the circle's center to a chord creates a right angle with the chord, meaning it is perpendicular. The concept of bisecting a chord is also introduced — the line from the center divides the chord into two equal lengths at the point where it intersects.

Examples & Analogies

Think about cutting a cake. If you cut it perfectly through the middle from the top (center), the two halves will be equal. Here, the center of the cake is like our center O, and the cut represents the perpendicular line to the chord.

Equal Chords and Distances from the Center

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Let AB be a line and P be a point. The length of the perpendicular from a point to a line is the distance of the line from the point. A circle can have infinitely many chords. You may observe by drawing chords of a circle that longer chord is nearer to the centre than the smaller chord.

Detailed Explanation

This chunk describes how the distance of chords from the center of the circle relates to their lengths. A longer chord is closer to the center, while shorter chords are farther away. The defined distance here is the shortest line (perpendicular) from a point (the center) to the line (the chord).

Examples & Analogies

Imagine throwing a dart at a dartboard. The closer you get to the bullseye (center), the better your score (longer chord). As your scores (lengths) improve, you are getting closer to that central point!

Cyclic Quadrilaterals and Their Properties

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

A quadrilateral ABCD is called cyclic if all the four vertices of it lie on a circle. You will find a peculiar property in such quadrilaterals: the sum of either pair of opposite angles of a cyclic quadrilateral is 180º.

Detailed Explanation

Here, a cyclic quadrilateral is defined as a four-sided figure where all corners touch the circumference of a circle. An important property of such shapes is that the sum of each pair of opposite angles equals 180 degrees. This property is foundational in geometry and has many practical applications.

Examples & Analogies

Think of a round table with four friends sitting around it. If they sit in what can be called a cyclic manner and pair up, their sitting arrangements' angles can be thought of as 180° all around the table, making sure everyone has a clear view!

Summary of Key Points

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

In this chapter, you have studied several points, including the relationship between chords, angles, and properties of circles.

Detailed Explanation

This part encapsulates the key concepts discussed in the chapter, consisting of results regarding angles subtended by chords, equal chords, perpendicular lines from the center to chords, and properties of cyclic quadrilaterals.

Examples & Analogies

These principles can be visualized in activities like drawing circles, juggling balls in patterns, or even constructing real-life circular features like pizza or wheels, solidifying how math relates to everyday life!

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Chords: Line segments whose endpoints lie on the circle.

  • Angles Subtended: Angles formed by chords at points on or around the circle.

  • Congruent Angles: Angles that are equal in measurement.

  • Cyclic Quadrilaterals: Quadrilaterals with all vertices on a circle.

Examples & Real-Life Applications

See how the concepts apply in real-world scenarios to understand their practical implications.

Examples

  • {'example': 'If two intersecting chords of a circle make equal angles with the diameter passing through their point of intersection, prove that the chords are equal.', 'solution': 'Let AB and CD be two chords intersecting at E. Since they subtend equal angles at the diameter, using properties of angles and congruence, we conclude that AB = CD.'}

  • {'example': 'Prove that the perpendicular from the center of a circle to a chord bisects the chord.', 'solution': 'By constructing triangles using the radius and the midpoint of the chord, we use the SSS theorem to show that the two segments created by the chord are equal.'}

Memory Aids

Use mnemonics, acronyms, or visual cues to help remember key information more easily.

🎵 Rhymes Time

  • Chords are like friends, together they stand, angles by their sides, in this circle so grand.

📖 Fascinating Stories

  • In a magical circle, two equal chords were friends. They always subtended equal angles at the center, making everyone respect their bond.

🧠 Other Memory Gems

  • Remember: LCA for Longer Chords, Create Angles.

🎯 Super Acronyms

Use CPCT for Corresponding Parts of Congruent Triangles often!

Flash Cards

Review key concepts with flashcards.

Glossary of Terms

Review the Definitions for terms.

  • Term: Chord

    Definition:

    A line segment whose endpoints lie on the circumference of the circle.

  • Term: Angle Subtended

    Definition:

    The angle formed at a specific point by the endpoints of a chord.

  • Term: Perpendicular

    Definition:

    A line that intersects another line at a right angle (90 degrees).

  • Term: Congruent

    Definition:

    Two figures are congruent if they have the same shape and size.

  • Term: Cyclic Quadrilateral

    Definition:

    A quadrilateral whose vertices all lie on a circle.

  • Term: Equidistant

    Definition:

    Equal distances from a certain point.
