3.2.1.3 - Tunnels: Below ground or under water
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Tunnels
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we will discuss tunnels, which are essential for transportation. Can anyone tell me the basic function of a tunnel?
Tunnels allow vehicles to travel underground or underwater, right?
Great! Tunnels facilitate movement while also minimizing disruptions to the surface. What are some other benefits of tunnels?
They can help avoid traffic and protect the environment by reducing surface infrastructure.
Exactly! They are crucial for easing traffic flow and can help in preserving ecological areas. Let's remember this as 'Tunnels = Traffic Relief + Eco-friendliness.'
Construction Methods of Tunnels
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now, let’s delve into how tunnels are constructed. Can anyone mention a common method used for tunneling?
Isn't there a method called 'cut and cover'?
Correct! The cut-and-cover method is one way tunnels are built, where a trench is excavated and then covered. Student_4, can you think of another method?
I think the bored method where machines do the digging is another way.
Exactly! Bored tunnels are created using machines that help avoid disturbance on the surface. Let’s use 'Bored = Below Surface Stability'.
Notable Tunnels Around the World
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let’s review some significant tunnels globally. Who can mention a famous tunnel and its importance?
The Gotthard Base Tunnel in Switzerland is the longest train tunnel.
Right! The Gotthard Base Tunnel is a marvel, running 57 km under the Swiss Alps, reducing travel time significantly. How about another example?
The Channel Tunnel connects England and France and helps with trade and travel.
That's correct! The Channel Tunnel enhances connectivity across the English Channel. Remember this as 'Tunnels = Trade + Travel Efficiency'.
Challenges in Tunnel Construction
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Tunnel construction is not without challenges. What issues do you think engineers face when building a tunnel?
They must deal with the pressure of soil and water surrounding the tunnel.
Exactly! Maintaining structural integrity against such pressures is critical. What do you think could happen if these pressures aren't managed?
There could be collapses or significant damage to the tunnel.
Precisely! Proper design and construction methods are essential. Let's remember: 'Pressure = Priority'.
The Future of Tunnel Engineering
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Finally, what advancements do you think might shape the future of tunnel engineering?
Perhaps more automated machinery for construction?
Yes! Automation can enhance efficiency. Any other ideas?
Innovative materials that can better withstand pressure could also help.
Great thought! Advancements in materials and technology will continue to evolve this field. Remember: 'Innovation is Key!'
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
Tunnels serve as crucial infrastructure for transportation, effectively allowing the movement of vehicles and goods under the earth or water. Various construction methods are highlighted, including approaches like cut and cover and pipe jacking, with notable examples such as the Gotthard Base Tunnel and the Channel Tunnel illustrating their importance in global connectivity.
Detailed
Tunnels: Below Ground or Under Water
Tunnels are vital constructions that facilitate the movement of vehicles and goods through the earth or beneath water bodies. They are intricate passages created by excavating soil and rock, necessitating specialized construction methods due to the pressure exerted by surrounding materials. Among the various methods employed, the cut-and-cover method involves digging a trench which is then covered by a supportive structure, while the bored method utilizes machines to create tunnels deep below the surface. Other techniques include the shaft method for reaching significant depths and pipe jacking, which utilizes hydraulic jacks to push pipes underground.
Notable examples of tunnels include the Gotthard Base Tunnel in Switzerland, the world's longest and deepest train tunnel, and the Channel Tunnel connecting England and France, showcasing the engineering prowess and depth of design involved in modern tunnel construction. These tunnels not only enhance transportation efficiency but also significantly reduce travel times, offering strategic advantages in global transport networks.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Introduction to Tunnels
Chapter 1 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Tunnels are underground or under water, enclosed passages constructed by digging through rock, soil and earth, for movement of vehicles.
Detailed Explanation
Tunnels serve as pathways beneath the earth or water, allowing vehicles to traverse areas that might be challenging or impossible to cross otherwise. They are crucial for efficient transportation as they can minimize travel time and circumvent geographical obstacles. Essentially, tunnels create a direct connection between two points, enhancing the transport network.
Examples & Analogies
Consider a tunnel like a straw that connects two parts of a drink—without the straw, you might have to tilt the cup or spill the drink to get to the other side. Tunnels streamline complex journeys into simpler routes.
Construction Methods for Tunnels
Chapter 2 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
With the massive excavation needed, the integrity of the passage is subject to the loading and pressure of the surrounding earth and/or water, construction of tunnels is highly specialised. There are various methods of tunnel construction on land, such as, Cut and cover method where a trench is cut and covered by some support; Bored method where boring machines are used; Clay kicking method common from the time of World War I, where clayey soil is literally kicked to create a tunnel; Shaft method is used for reaching great depths from the ground level and pre-cast shaft structures with concrete walls are lined and connected; Pipe jacking method where pipes are driven underground using hydraulic jacks, usually under existing infrastructures like roads, railways, etc.; and Box jacking method where boxes instead of pipes are driven in. For underwater tunnel construction usually calls for immersing tubes or boring tunnels through rock.
Detailed Explanation
Building a tunnel is not simple. Different methods are employed based on terrain and requirements. For example:
- Cut and cover involves digging a trench, building the tunnel walls, and covering it back up.
- Bored method uses large machines to create the tunnel without disrupting too much above-ground activity.
- Clay kicking involves pushing clay out of the way for smaller tunnels.
- Pipe jacking and Box jacking are methods to install pipes or boxes below ground level, useful when avoiding disruption to current structures. Understanding these methods is crucial since construction engineers must choose the best technique depending on the environment.
Examples & Analogies
Imagine building a treehouse. Depending on where you build it (ground, on another tree), you might dig a hole, use a ladder, or even lift a platform up to the trees. Each technique has to consider the surrounding things—just like building a tunnel does.
Longest and Notable Tunnels
Chapter 3 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The world’s longest road tunnel is the Lærdalstunnelen, of 24.5 Km linking Aurland and Lærdal, and offering a ferry free connection built in 2000, followed by the Yamate tunnel in Tokyo, Japan measuring 18.2Km built in 2015 and the Zhongnanshan in Shaanxi, China measuring 18.04Km built in 2017. The Eisenhower Road tunnel in Colorado is one of the world’s highest tunnels at a height of 3,401m above sea level, on the Rocky Mountains. The world’s longest and deepest train tunnel is the Gotthard Base Tunnel in Switzerland, running 57 Km in length and at a depth of 2300m under the Swiss Alps, significantly reduced train travel time connecting Zurich to Milan. Previously this distinction was held by the Seikan railway tunnel, spanning the Tsugaru strait connecting Honshu and Hokkaido, running 53 Kms at 140m depth. Another phenomenal feat is the Channel tunnel across the English Channel between England and France, spanning 50Km, having two rail and one service tunnel for passenger and freight.
Detailed Explanation
Some remarkable tunnels showcase what's possible through engineering. For example, the Gotthard Base Tunnel in Switzerland is particularly notable. It's not only the longest train tunnel but also one of the deepest, significantly reducing travel time between major cities by allowing high-speed rail access through the Alps. Each tunnel serves important functions, such as easing traffic bottlenecks or allowing for transportation under natural barriers like water bodies or mountains.
Examples & Analogies
Think of these tunnels like superhighways for trains or cars that cut through mountains instead of going over them. Just as a bridge helps cars cross a river quickly, tunnels allow vehicles to ‘dive’ underground, speeding up journeys.
Modern Engineering in Tunnels
Chapter 4 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
A piece of modern engineering is the SMART (Stormwater Management and Road Tunnel) Tunnel in Kuala Lumpur, Malaysia, designed keeping in mind the flash flood situation that the city faces and operates in three ways: as a road tunnel when there is no flood, the upper level operates for traffic while the lower channel allows water diversion when there are medium floods; and closes for traffic but allows floodwater to flow through via a holding pond, bypass tunnels and a storage reservoir during heavy floods.
Detailed Explanation
The SMART Tunnel is a remarkable solution tailored to the challenges posed by heavy rains and flooding in Kuala Lumpur. Its versatility means it can serve multiple purposes: it functions as a road tunnel for everyday use, but also channels water during rainy periods. By managing stormwater, it prevents flooding in the urban area, showing how engineering solutions can adapt to environmental needs.
Examples & Analogies
Envision a sponge that absorbs water: when it rains, the sponge expands accommodating excess water, but when it's dry, it serves as a regular, useful sponge. The SMART Tunnel mimics this function, adapting its role based on local conditions.
Key Concepts
-
Tunnels serve to facilitate the movement of vehicles and goods under the earth or water.
-
Construction methods vary, including cut-and-cover and bored tunneling techniques.
-
Noteworthy tunnels like the Gotthard Base Tunnel and Channel Tunnel exemplify modern engineering.
Examples & Applications
The Gotthard Base Tunnel improves travel time across the Swiss Alps by running 57 kilometers underneath them.
The Channel Tunnel enhances trade and connectivity between England and France by functioning as both passenger and freight transportation.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Tunnels dig deep, through rock and clay, allowing vehicles to travel on their way.
Stories
Once upon a time, in a city surrounded by mountains and rivers, engineers decided to build tunnels to connect different regions. They faced many challenges of pressure but overcame them by using advanced methods. The tunnels became lifelines for trade and transport.
Memory Tools
Remember 'TASP' for tunnels: 'Tunnels Allow Safe Passage'.
Acronyms
TUNNEL
Tunnels Underneath New Networks Enhance Life.
Flash Cards
Glossary
- Tunnel
An underground or underwater passage used for the movement of vehicles or goods.
- Cut and Cover
A method of tunnel construction that involves digging a trench, building the tunnel wall, and then covering it.
- Bored Tunnel
A tunnel created using boring machines that excavate the tunnel underground.
- Gotthard Base Tunnel
The world's longest and deepest railway tunnel located in Switzerland.
- Channel Tunnel
A rail tunnel beneath the English Channel connecting England and France.
