5.4 - Applications of Trigonometry

Interactive Audio Lesson

Listen to a student-teacher conversation explaining the topic in a relatable way.

Understanding Angles of Elevation

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Today, we'll learn about angles of elevation. This is the angle formed from the horizontal line when you look up towards an object.

Student 1
Student 1

Why do we need to use trigonometry for angles of elevation?

Teacher
Teacher

Great question! We use trigonometry to calculate distances and heights that are hard to measure directly. For example, by knowing the height of a tower and measuring the angle of elevation from the ground, we can find how far away we are from the tower.

Student 2
Student 2

Can you give an example of that?

Teacher
Teacher

Sure! If a tower is 50 m tall and the angle of elevation is 30 degrees, we can use the tangent function to find the distance from the tower.

Student 3
Student 3

I remember that tan(θ) = opposite/adjacent!

Teacher
Teacher

Exactly! And in our example, the 'opposite' is the height of the tower. So, we set it up as tan(30°) = 50/distance.

Student 4
Student 4

And then we can solve for distance, right?

Teacher
Teacher

That's right! Let’s work on solving that together.

Applying Tangent in Real Life

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Continuing from our last discussion, if we apply the tangent equation, what do we find for distance?

Student 1
Student 1

We have tan(30°) = 50/distance, so distance = 50/tan(30°).

Teacher
Teacher

Correct! And what is tan(30°)? Do you remember?

Student 2
Student 2

Yes, it’s 1/sqrt(3) or about 0.577!

Teacher
Teacher

Excellent! Now plug that value into the distance equation.

Student 3
Student 3

So distance = 50/(1/sqrt(3)), which multiplies to 50*sqrt(3).

Student 4
Student 4

Which is approximately 86.6 m!

Teacher
Teacher

Fantastic! So this process can be used in various applications to determine distances.

Angles of Depression Explained

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Now, let's explore angles of depression. This is the angle formed when looking down from a certain height.

Student 1
Student 1

So, if we're at the top of a building looking down, that’s an angle of depression?

Teacher
Teacher

Correct! Just like angles of elevation, we can also use them in calculations.

Student 2
Student 2

Can we use the same trigonometric functions?

Teacher
Teacher

Yes, exactly! You’ll often find that you can still apply sin, cos, or tan based on the context.

Student 3
Student 3

Can you show an example of this?

Teacher
Teacher

Certainly! Let’s say you are on a cliff looking down at a boat with an angle of depression of 45 degrees. You can use similar tangent relationships to calculate the distance from the cliff you are at!

Student 4
Student 4

So it works the same as before?

Teacher
Teacher

Exactly! It’s just the idea of looking upward versus downward.

Introduction & Overview

Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.

Quick Overview

This section explores the practical applications of trigonometry in measuring heights and distances.

Standard

In this section, we delve into how trigonometry is applied to determine heights and distances that are challenging to measure directly, as well as angles of elevation and depression. Practical examples illustrate these concepts in action.

Detailed

Detailed Summary

In this section, we discuss the real-world applications of trigonometry, focusing on its utility in calculating heights and distances that are difficult to measure directly. Trigonometry helps us find angles of elevation and depression that are essential in various fields such as architecture, navigation, and surveying. An example illustrates the process of determining the distance to a tower by measuring the angle of elevation from a certain point on the ground and using the height of the tower. This section serves as a bridge between theoretical concepts and their practical implementations, demonstrating the importance of trigonometry in everyday life.

Youtube Videos

Applications of Trigonometry Class 10
Applications of Trigonometry Class 10
Class 10th Some Applications of Trigonometry One Shot 🔥 | Class 10 Maths Chapter 9 | Shobhit Nirwan
Class 10th Some Applications of Trigonometry One Shot 🔥 | Class 10 Maths Chapter 9 | Shobhit Nirwan
SOME APPLICATIONS OF TRIGONOMETRY in 1 Shot: FULL CHAPTER (Theory + PYQs) | Class 10 Board | WARRIOR
SOME APPLICATIONS OF TRIGONOMETRY in 1 Shot: FULL CHAPTER (Theory + PYQs) | Class 10 Board | WARRIOR
Some Application Of Trigonometry FULL CHAPTER | Class 10th Mathematics | Chapter 9 | Udaan
Some Application Of Trigonometry FULL CHAPTER | Class 10th Mathematics | Chapter 9 | Udaan
Class 10th Trigonometry One Shot 🔥 | Class 10 Maths Chapter 8 | Shobhit Nirwan
Class 10th Trigonometry One Shot 🔥 | Class 10 Maths Chapter 8 | Shobhit Nirwan
Some Applications Of Trigonometry | Exercise 9.1 | Chapter 9 |
Some Applications Of Trigonometry | Exercise 9.1 | Chapter 9 |
Class 10 Maths - Day 4 || Trigonometry & Some Applications of Trigonometry || Ritik Sir
Class 10 Maths - Day 4 || Trigonometry & Some Applications of Trigonometry || Ritik Sir
A Trigonometric problem of 10th standard is discussed #maths #trigonometry #trigonomerric
A Trigonometric problem of 10th standard is discussed #maths #trigonometry #trigonomerric
Some Applications Of Trigonometry | Maths Chapter 9 Class 10 | Height And Distance Class 10 | CBSE
Some Applications Of Trigonometry | Maths Chapter 9 Class 10 | Height And Distance Class 10 | CBSE
Trigonometry Basics
Trigonometry Basics

Audio Book

Dive deep into the subject with an immersive audiobook experience.

Introduction to Applications

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Trigonometry is used to find:
● Heights and distances that are difficult to measure directly.
● Angles of elevation and depression.

Detailed Explanation

In this chunk, we learn about the practical uses of trigonometry. One of the main applications is in measuring heights and distances that we cannot easily access. For example, if you want to know the height of a tree but cannot climb it, trigonometry provides a method to calculate that height using angles. Additionally, trigonometry helps in understanding angles of elevation (looking up) and depression (looking down).

Examples & Analogies

Imagine you are standing some distance away from a tall building. You want to know how tall the building is, but it’s too unsafe to go near it or climb to the top. By measuring the angle at which you are looking up to the top of the building (the angle of elevation), you can use trigonometry to calculate the building’s height with just this angle and your distance from the base.

Example Problem: Finding Distance Using Trigonometry

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

✦ Example:
From a point on the ground, the angle of elevation to the top of a tower is 30°. If the tower is 50 m high, find the distance of the point from the base of the tower.
Solution:
Let distance = d m.
tan 30° = Height / Distance = 50 / d
tan 30° = 1 / √3 ⇒ 1 / √3 = 50 / d
d = 50√3 ≈ 86.6 m.

Detailed Explanation

In this example, we learn how to apply the concept of an angle of elevation to find a distance. The angle of elevation to the top of a tower is given as 30°, while the height of the tower is 50 meters. We denote the horizontal distance from the tower as 'd'. Using the trigonometric function tangent (tan), which relates the angle with the opposite side (height of the tower) and adjacent side (distance from the tower), we set up the equation. The tangent of 30° equals the height (50 m) divided by this unknown distance (d). Solving the equation gives us the distance d as approximately 86.6 meters.

Examples & Analogies

Think about standing on a flat ground looking up at a tall structure, such as a cell tower. If you hold a protractor to measure the angle you need to look up to see the top of the tower and you know how high the tower is, you can use trigonometry to find out how far away from the tower you are standing. This is similar to determining how far back you need to stand to get a clear view of a mountain while ensuring you don’t get too close!

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Trigonometry: The branch of mathematics that deals with the relationships between the sides and angles of right-angled triangles.

  • Angle of Elevation: The angle formed when looking up towards an object.

  • Angle of Depression: The angle formed when looking down towards an object.

  • Applications: Trigonometry is useful in various fields such as surveying, architecture, and engineering.

Examples & Real-Life Applications

See how the concepts apply in real-world scenarios to understand their practical implications.

Examples

  • To find the distance from a tower given its height and the angle of elevation, use the formula distance = height/tan(angle). For instance, if a tower is 50m tall and the angle of elevation is 30°, the distance would be approximately 86.6 m.

  • During construction, architects may need to know the angle of elevation from a ground point to a structure to ensure proper height and alignment.

Memory Aids

Use mnemonics, acronyms, or visual cues to help remember key information more easily.

🎵 Rhymes Time

  • When looking up at a towering height, the angle of elevation gives us insight.

📖 Fascinating Stories

  • Imagine a climber at the top of a mountain. They look down and see a boat far away, realizing they need to calculate the distance using angles.

🧠 Other Memory Gems

  • SOHCAHTOA helps remember sin = opposite/hypotenuse, cos = adjacent/hypotenuse, tan = opposite/adjacent.

🎯 Super Acronyms

E.D. for Elevation and Depression - Elevating our calculations upwards and depressing them downwards!

Flash Cards

Review key concepts with flashcards.

Glossary of Terms

Review the Definitions for terms.

  • Term: Angle of Elevation

    Definition:

    The angle formed from the horizontal line of sight when looking upward towards an object.

  • Term: Angle of Depression

    Definition:

    The angle formed from the horizontal line of sight when looking downward towards an object.

  • Term: Tangent (tan)

    Definition:

    A trigonometric function that relates the angle of a triangle to the ratio of the length of the opposite side to the length of the adjacent side.
