3. Laws of Motion

Motion is influenced by forces. The study of the effect of forces on the motion of bodies is governed by Newton’s Laws of Motion, which form the foundation of classical mechanics.

This chunk introduces the concept of motion and its dependence on forces. It emphasizes that the study of motion is based on Newton's Laws, which are fundamental principles that describe how objects move.

Think of a soccer game where players influence the motion of the ball by kicking it. Their kicks (forces) change the ball's state of rest or motion.

Force is a push or a pull that changes or tends to change the state of rest or motion of a body.

• Vector quantity
• SI unit: newton (N)
• 1 newton = force needed to give 1 kg of mass an acceleration of 1 m/s²

This chunk defines force as a push or pull, and highlights its role in changing the state of motion of objects. It also classifies force as a vector quantity, meaning it has both magnitude and direction. The SI unit for measuring force is the newton, which quantifies how much force is needed to accelerate a kilogram mass at a certain rate.

When you push a shopping cart, you're applying a force. If you push it hard enough, it accelerates, changing from being at rest to moving.

Statement: A body continues in its state of rest or of uniform motion in a straight line unless an external force is applied.

• Explains inertia: the tendency of an object to resist change in its state of motion.
• If net force = 0, then:
  • A body at rest stays at rest
  • A body in motion continues moving uniformly

Newton's First Law states that an object will not change its state of motion unless acted upon by an external force. This principle is known as inertia, which describes how objects resist changes in their motion. If no net force acts on an object, it will either remain at rest or continue moving at a constant velocity.

When you're riding in a car that suddenly stops, your body lurches forward because it wants to continue moving at the same speed – that's inertia in action!

Statement: The rate of change of momentum of a body is directly proportional to the applied force and takes place in the direction of the force. F=ma Where:

• F = force
• m = mass
• a = acceleration Also: Momentum (p)=mv ⇒ F = dp/dt

The Second Law indicates that the acceleration of an object depends on two variables: the net force acting on it and its mass. It introduces the formula F = ma, where force equals mass times acceleration. The concept of momentum is also explained, showing how force causes a change in momentum over time.

If you have two carts, one empty and one full of bricks, and you push both with the same force, the empty cart will accelerate faster because it has less mass, demonstrating how mass affects acceleration.

Statement: For every action, there is an equal and opposite reaction.

• Forces always occur in pairs
• These forces act on different bodies Examples:
• Recoil of a gun
• Walking (foot pushes backward, ground pushes forward)

Newton's Third Law emphasizes that forces come in pairs. For every action force, there is a reaction force of equal strength but in the opposite direction. This law applies in various scenarios where interactions occur between two bodies.

When you jump off a small boat onto the dock, your push down on the boat causes it to move backward. Your action of jumping leads to the reaction of the boat moving in the opposite direction.

Inertia: The property of a body to resist change in its state of motion or rest. Types of Inertia:

1. Inertia of Rest – Body remains at rest unless acted upon (e.g., rider falls backward when horse starts suddenly)
2. Inertia of Motion – Body continues to move unless acted upon (e.g., passenger moves forward when bus stops suddenly)
3. Inertia of Direction – Body continues in the same direction (e.g., mud flies off rotating tire)

Inertia is defined as the tendency of objects to maintain their current state of motion. There are three types of inertia: (1) Inertia of Rest, where objects at rest remain so unless a force is applied; (2) Inertia of Motion, where objects in motion stay in motion; and (3) Inertia of Direction, where objects moving in a particular direction continue to do so until acted upon.

When a cyclist suddenly brakes, the cyclists and their bike experience inertia of motion and continue moving forward even as the bike stops.

Momentum=Mass×Velocity (p=mv)

• Vector quantity
• SI unit: kg·m/s
• Greater momentum = greater force required to stop

Momentum is defined as the product of mass and velocity, expressed as p = mv. It is a vector quantity, meaning it has both magnitude and direction. The greater the momentum of an object, the more force is needed to stop it.

Think of a heavy truck moving at a high speed; the larger the mass and the faster it's moving, the more force it will take to stop it compared to a small car moving slowly.

Impulse=Force×Time=Δp

• Equal to the change in momentum
• SI unit: N·s Examples:
• Batsman hitting a ball (force applied for a short time)
• Padded surfaces reduce force by increasing time of contact

Impulse is defined as the product of force and the time duration over which the force acts, leading to a change in momentum. It is represented as Δp. The SI unit for impulse is newton-seconds (N·s). This concept is crucial in many practical scenarios, where applying force over a longer time can reduce the impact force experienced.

When a batsman hits the cricket ball, they apply force for a brief moment. If the bat is padded, it increases the time of impact and reduces the forces on both the bat and the ball, leading to smoother contact.

Examples:

• Wearing seatbelts (First law)
• Rockets launching (Third law)
• Pushing a cart (Second law)
• Catching a cricket ball with soft hands (Impulse)

Newton's Laws of Motion have practical applications in everyday life. For instance, wearing seatbelts corresponds to the First Law since it protects you by applying a force to stop your motion in case of a crash. Rockets demonstrate the Third Law by using thrust to propel themselves forward. The Second Law applies when pushing a cart, as the amount of force needed increases with its mass, and catching a ball gently illustrates impulse by reducing the force experienced.

Consider seatbelts in a car; they help keep people in motion at the same speed as the car, demonstrating inertia. When rockets launch, the force of the thrust pushes downward and creates an equal reaction upwards, propelling the rocket into space.

--
