Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Elasticity at Nanoscale
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Today, we're diving into the concept of elasticity at the nanoscale. Can anyone tell me what elasticity means?
Isn't it the ability of a material to return to its original shape after a force is applied?
Exactly! Now, nanomaterials often exhibit enhanced elasticity. Why do you think that might be?
Maybe because they have fewer defects?
Great point! Factors such as fewer structural defects and the contributions of surface atoms indeed make them more elastic. Remember the acronym *FSD*βFewer Structural Defectsβwhen thinking about why nano materials differ!
So, carbon nanotubes can be even stronger than steel?
Right! They combine lightness with extraordinary strength. Any questions about this before we move on?
What about how we measure this elasticity?
Great question! We use techniques like nanoindentation to measure these properties. Letβs summarize: nanomaterials are more elastic due to fewer defects, and we measure this using special techniques.
Hardness in Nanomaterials
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Let's discuss hardness. Can anyone define what hardness is?
Itβs about how resistant a material is to deformation, right?
Exactly! At the nanoscale, materials like nanocrystalline metals exhibit increased hardness. Why do you think that happens?
Could it be because of the Hall-Petch effect?
Excellent! The Hall-Petch effect shows that smaller grain sizes can lead to harder materials. Remember the phrase *Grains Make Gains!* to link grain size and hardness. Can someone give an example of a hard nanomaterial?
What about those engineered nanocomposites?
Spot on! Nanocomposites can indeed be engineered for high hardness. To summarize, hardness increases in smaller grains, and we can recall this with the phrase *Grains Make Gains!*
Deformation at Nanoscale
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Now, letβs tackle deformation at the nanoscale. How is deformation at this scale different?
I think it has to do with how dislocations behave?
Absolutely! In nanowires and thin films, dislocation motion is suppressed, leading to unique responses. Can anyone think of a specific behavior?
Could it lead to pseudo-elasticity?
Exactly! Pseudo-elasticity occurs due to the atomistic nature of deformation. A good mnemonic here is *Pseudo for Produced*, to remember that it's a response produced by the nanoscale structure. In summary, limited dislocation leads to unique deformation mechanisms such as pseudo-elasticity.
Light-Matter Interaction
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Let's shift our focus to light-matter interactions at the nanoscale. What makes these interactions unique?
Is it because of size-dependent properties?
Correct! Size-dependent resonances allow nanoparticles to manipulate light in exciting ways. For example, can anyone tell me what happens to gold nanoparticles when they change size?
They change color, right? Like red, blue, or purple?
Exactly! This unique characteristic is valuable for sensors and imaging. Remember the phrase *Color by Size*! Now, how does light confinement work with nanostructures?
It enhances electric fields, enabling better sensing?
Exactly! By confining light, we improve biosensing techniques. So, letβs recall, size affects color in nanoparticles, and we can enhance electric fields using nanostructures.
Applications of Plasmonics, Quantum Dots, and Photonic Crystals
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Finally, letβs explore some applications. How is plasmonics applied in real-world scenarios?
I heard itβs used in biosensors!
Absolutely! Plasmonics enables highly sensitive biosensing and even in solar cells. Can someone explain how quantum dots are applied?
They are used for displays and medical diagnostics!
Perfect! Quantum dots enhance color accuracy in TVs and assist in bioimaging. What about photonic crystals?
They are used in optical circuits to control light?
Correct! Photonic crystals help create optical filters and waveguides. Letβs summarize: plasmonics for biosensing and energy, quantum dots for imaging and displays, and photonic crystals control light in optical circuits.
Introduction & Overview
Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.
Quick Overview
Standard
Focusing on nanomechanics and nanophotonics, this chapter discusses how nanoscale materials exhibit distinct mechanical behaviors such as elasticity and hardness, as well as remarkable optical phenomena through light-matter interactions. Key applications including plasmonics, quantum dots, and photonic crystals are also highlighted.
Detailed
Detailed Summary of Nanomechanics and Nanophotonics
This chapter delves into the fascinating fields of nanomechanics and nanophotonics, which examine the behavior of materials and light at the nanoscale. Understanding these principles opens pathways to innovative applications in various industries.
Mechanical Properties at the Nanoscale
At the nanoscale, materials behave differently compared to bulk materials due to factors like surface effects and quantum confinement. Key mechanical properties discussed include:
- Elasticity: The ability to return to original form post-deformation, characterized by enhanced properties in nanomaterials due to fewer defects.
- Hardness: Resistance to permanent deformation, explained by the Hall-Petch effectβsmaller grains lead to greater hardness.
- Deformation: Unique atomistic mechanisms at play due to limited dislocation motion, especially noticeable in nanowires and thin films.
Measurement techniques such as nanoindentation, AFM, and in-situ TEM are utilized to assess these properties.
Light-Matter Interactions at the Nanoscale
Light interacts with nanoparticles in ways not seen in larger materials, resulting in:
- Absorption and Scattering: Color changes based on size; this is crucial for sensor technologies.
- Confinement of Light: Nanoscale structures can trap light, enhancing applications like biosensing and optical tweezers.
Plasmonics
Plasmonics studies charge density oscillations in metals. Two key concepts discussed are:
- Surface Plasmon Resonance (SPR): Enhances local fields and enables sensitive detection in biosensing.
- Localized Surface Plasmons (LSPs): Allow imaging beyond the diffraction limit, useful in various applications such as solar cells and photothermal therapy.
Quantum Dots
Quantum dots are semiconductor nanocrystals with discrete energy levels, allowing for tunable properties. Applications include:
- Displays (like QLED TVs)
- Bioimaging tools for medical diagnostics
- Solar energy applications that improve efficiency
Photonic Crystals
These structures create photonic band gaps to control light propagation. Different types exist with various applications, including:
- Optical filters and waveguides
- Enhancements in LEDs and lasers
Real-World Applications
The chapter concludes with applications in medicine, electronics, security, and communication leveraging the unique properties of nanomaterials.
Understanding these concepts is vital for grasping advancements in materials science and nanotechnology, important for future innovations.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Learning Objectives
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
By the end of this chapter, you will be able to:
β Understand the unique mechanical behavior of materials at the nanoscale.
β Explain concepts such as elasticity, hardness, and deformation in nanostructures.
β Describe how light interacts with nanomaterials and understand its implications.
β Learn the principles and applications of plasmonics, quantum dots, and photonic crystals.
β Analyze real-world applications of nanomechanics and nanophotonics in science and industry.
Detailed Explanation
This section outlines the key learning objectives of the chapter, highlighting what students can expect to learn about nanomechanics and nanophotonics. It emphasizes understanding the unique behaviors and properties of materials that only occur at the nanoscale, where size dramatically influences their mechanical and optical characteristics.
Examples & Analogies
Think of learning about nanomechanics and nanophotonics like exploring a tiny universe where the rules of physics change. Just like how knowledge about outer space helps us understand the universe, understanding these nanoscale properties helps scientists design better materials and technologies.
Mechanical Properties at the Nanoscale
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
At the nanoscale, materials exhibit mechanical properties that significantly differ from their bulk counterparts due to surface effects, reduced dimensionality, and quantum confinement.
Detailed Explanation
This chunk introduces the topic of mechanical properties at the nanoscale. It explains that when materials are reduced to the nanoscale, their physical characteristics change significantly. Factors such as the influence of their surface area, the limited dimensions that make them behave differently, and the effects of quantum mechanics all contribute to this change.
Examples & Analogies
Imagine a regular-sized rubber band; it can stretch and return to shape easily. Now picture a tiny rubber band thatβs so small that you can barely see it. This tiny band would behave differentlyβit might stretch more before breaking and could have different bouncing properties. This is similar to how materials behave at the nanoscale.
Elasticity
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Elasticity is the ability of a material to return to its original shape after a mechanical force is removed. Nanomaterials often show enhanced elastic properties due to:
β Fewer structural defects.
β Dominant surface atom contributions.
β Reduced grain boundaries.
For example, carbon nanotubes can exhibit elastic moduli exceeding those of steel while remaining extremely light and flexible.
Detailed Explanation
This chunk defines elasticity and how it is affected at the nanoscale. It explains that because nanomaterials have fewer defects and different structures, they can be more elastic than larger materials. The mention of carbon nanotubes illustrates this point, as they are incredibly strong yet lightweight, showcasing enhanced elasticity.
Examples & Analogies
Think of a slinky toy. If you stretch it and let go, it returns to its original shape. Now imagine making a tiny slinky out of a special material that stretches even more but snaps back just as wellβthis tiny slinky represents how nanomaterials can behave with enhanced elasticity.
Hardness
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Hardness is a measure of a material's resistance to deformation, particularly permanent deformation or scratching. At the nanoscale:
β Materials like nanocrystalline metals show increased hardness.
β The Hall-Petch effect explains how reduced grain sizes can lead to harder materials.
β Nanocomposites are engineered for high hardness and durability.
Detailed Explanation
Hardness is discussed in this section, explaining how at the nanoscale, certain materials become much harder than larger pieces of the same material. It introduces the Hall-Petch effect, which relates smaller grain sizes in metals to increased hardness, and notes how nanocomposites are designed to maximize these properties.
Examples & Analogies
Picture a regular steel ball and a tiny, finely crafted steel marble. The tiny marble can be engineered to be much harder and more scratch-resistant than its larger counterpart, thanks to its nanoscale features. This illustrates the principles of hardness at the nanoscale.
Deformation
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Deformation at the nanoscale is influenced by:
β Suppression of dislocation motion.
β Atomistic deformation mechanisms.
β Unusual strain-stress behaviors.
In nanowires and thin films, dislocations are limited, leading to unique mechanical responses such as pseudo-elasticity or strain-induced phase transitions.
Detailed Explanation
This chunk covers how deformation behaves differently at the nanoscale. Factors like dislocation motion being suppressed and atomistic mechanisms at play lead to unique behaviors. It explains how materials can display properties like pseudo-elasticity, making them respond unpredictably when stressed.
Examples & Analogies
Imagine bending a thick rubber rod versus a very thin rubber band. The thin band might bend unexpectedly without breaking, exhibiting different responses to stress. This is similar to how nanomaterials can showcase unusual deformation behaviors.
Measurement Techniques
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
To study these mechanical properties, scientists use:
β Nanoindentation: Measures hardness and elastic modulus.
β Atomic Force Microscopy (AFM): Maps surface stiffness and deformation.
β In-situ Transmission Electron Microscopy (TEM): Observes deformation in real-time.
Detailed Explanation
Here, the methods used to measure mechanical properties at the nanoscale are explained. Nanoindentation helps quantify hardness, AFM allows for surface mapping, and TEM gives real-time observation of material behavior under stress. These techniques are critical for understanding nanoscale mechanics.
Examples & Analogies
Think of trying to measure the flexibility of a tiny rubbery toy. Just like you would need a special tool to measure its stretchiness appropriately, scientists use these advanced instruments to study how nanoscale materials behave.
Light-Matter Interactions at the Nanoscale
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
At the nanoscale, the interaction of light with matter gives rise to extraordinary optical phenomena.
Detailed Explanation
This section introduces how light interacts with nanoscale materials, leading to unique optical phenomena. The smaller scale allows for different interactions between light and materials, resulting in interesting behaviors that can be harnessed in various applications.
Examples & Analogies
Imagine shining a flashlight through a glass of water versus a glass of glitter. In the glass of glitter, the way light scatters and shines through creates beautiful patterns and colorsβsimilarly, nanoscale interactions with light can produce stunning effects!
Absorption and Scattering
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Nanoparticles can absorb and scatter light in unique ways due to:
β Size-dependent resonances.
β Shape anisotropy.
β Material composition.
For instance, gold nanoparticles can appear red, blue, or purple depending on size, making them useful for sensors and imaging.
Detailed Explanation
This chunk explains that nanoparticles absorb and scatter light based on their characteristics. Size and shape play crucial roles in how light interacts with them, leading to color changes and unique behaviors that are useful in technology.
Examples & Analogies
Think about playing with different colored filters. Changing the size and shape of your filters can make what you see change colors. Similarly, nanoparticles can change color based on their size, which is helpful in developing sensors that can detect specifics in light patterns.
Confinement of Light
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Light can be confined in spaces smaller than its wavelength using nanostructures:
β Enhances electric fields locally.
β Enables high-sensitivity biosensing.
β Used in nano-optical tweezers to manipulate small particles.
Detailed Explanation
This section discusses how nanoscale structures can trap light, making it behave differently than it does in larger spaces. This confinement enhances local electric fields and has practical applications in areas such as biosensing and manipulating particles at the nanoscale.
Examples & Analogies
Imagine trying to trap wind with your handsβif your hands are far apart, not much air gets trapped, but if you close them tightly, the air is contained. Similarly, nanostructures trap light effectively, leading to useful applications in science.
Plasmonics
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Plasmonics involves the study of plasmonsβquantized oscillations of free electron gas in metals.
Detailed Explanation
This chunk introduces plasmonics, focusing on how light interacts with free electrons in metals to produce plasmons. These phenomena lead to applications in various areas, including sensors and medical technologies.
Examples & Analogies
Think of the way water ripples when you throw a stone into it. The ripples are similar to how plasmons behaveβcreating waves of electronic energy that have interesting effects when interacting with light.
Surface Plasmon Resonance (SPR)
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Occurs when light excites electrons at a metal-dielectric interface:
β Enhances local electromagnetic fields.
β Enables real-time biosensing with high sensitivity.
Detailed Explanation
This section explains SPR, a phenomenon crucial for biosensing applications. By exciting electrons at an interface, SPR enhances electromagnetic fields, making it possible to detect changes at very small scales with high sensitivity.
Examples & Analogies
Imagine a camera focusing in to capture the tiniest details of a leaf. SPR acts like that focused camera, allowing scientists to 'see' and measure very small changes in biosensors.
Localized Surface Plasmons (LSPs)
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Observed in nanoparticles:
β Create intense local fields around the particles.
β Enable imaging beyond the diffraction limit.
Detailed Explanation
LSPs are discussed as phenomena in nanoparticles where strong local fields are generated. This effectively enhances imaging capabilities, allowing scientists to view details they couldnβt typically resolve with regular optical systems.
Examples & Analogies
Think of using a magnifying glass to see tiny detailsβLSPs act like a super magnifying lens, making it possible to 'see' features at the nanoscale that are otherwise invisible to the naked eye.
Applications of Plasmonics
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
β Biosensors: Detect minute concentrations of biomolecules.
β Solar Cells: Enhance light absorption.
β Photothermal Therapy: Convert light to heat to destroy cancer cells.
Detailed Explanation
This chunk outlines several key applications of plasmonics, demonstrating its relevance in real-world technologies. Plasmonics is used in biosensors for medical diagnostics, solar arrays for energy efficiency, and in therapies that rely on converting light to heat.
Examples & Analogies
Think of a superhero who can harness sunlight to heal. In a way, plasmonics acts like that superhero, providing methods to harness light almost magically to benefit health and technology.
Quantum Dots
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Quantum dots (QDs) are nanometer-sized semiconductor particles exhibiting quantum confinement effects.
Detailed Explanation
This section introduces quantum dots, highlighting their unique properties due to their size. Being so small, they have confined electrons, leading to discrete energy levels and tunable colors, which make them very valuable in new technologies.
Examples & Analogies
Imagine a tiny, colorful bead that shines differently in different lights. Quantum dots are like those beads; changing their size can alter their color and brightness, leading to innovative uses in displays and imaging technologies.
Key Features of Quantum Dots
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
β Electrons and holes are confined in all three dimensions.
β Discrete energy levels similar to atoms.
β Tunable emission spectra by changing particle size.
Detailed Explanation
This chunk elaborates on the unique features of quantum dots, pointing out how their tiny size leads to effects that allow for color tuning and discrete energy levels that function similarly to atomic energy levels.
Examples & Analogies
Picture a tiny light bulb that changes color when you twist it. Quantum dots act like this bulb, where changing their structure allows them to emit different colors or energies, creating vibrant applications in electronics.
Applications of Quantum Dots
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
β Displays: Used in QLED TVs for bright, color-accurate screens.
β Bioimaging: Fluorescent labeling for medical diagnostics.
β Solar Cells: Increase energy conversion efficiency.
Detailed Explanation
This part emphasizes the wide-ranging applications of quantum dots, from enhancing display technologies to improving medical imaging and boosting solar energy conversion. Their unique properties facilitate these advancements.
Examples & Analogies
Think of quantum dots as special paint used to create vivid murals that come to life under different lights. These applications enable brighter screens and more efficient solar panels, much like vibrant art can shift our perspective.
Photonic Crystals
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Photonic crystals are materials with periodic variations in refractive index.
Detailed Explanation
This section introduces photonic crystals and their defining characteristics, especially how their structured refractive index affects light propagation. The periodic structure can block certain wavelengths of light.
Examples & Analogies
Imagine a finely woven fabric where some colors can't pass through. Photonic crystals function similarly, selectively allowing colors to filter through based on their structure, which has exciting implications for optical devices.
Principles of Photonic Crystals
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
β Create photonic band gaps, preventing light of certain wavelengths from propagating.
β Control light in integrated optical circuits.
Detailed Explanation
This chunk dives into the principles governing photonic crystals, explaining that certain designs can create band gaps where specific light wavelengths cannot propagate. This control over light allows for various applications in optical technologies.
Examples & Analogies
Think of a toll road where only certain vehicles can pass through depending on their size. Photonic crystals operate like this road, guiding and controlling what kind of light can travel through them based on design.
Types of Photonic Crystals
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
β 1D Crystals: Alternating layers (e.g., Bragg reflectors).
β 2D and 3D Crystals: More complex control over light direction and confinement.
Detailed Explanation
This section categorizes photonic crystals into different types based on their dimensions. 1D crystals involve simple layered structures, while 2D and 3D crystals provide more sophisticated control over light, leading to enhanced functionalities.
Examples & Analogies
Imagine building a multi-layer cake with different flavorsβ1D being a single flavor layer, and 3D being complex with multiple layers of various flavors. Each type provides unique tastes, just as different photonic crystals provide unique light properties.
Applications of Photonic Crystals
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
β Optical Filters: Select specific wavelengths.
β Waveguides: Guide light with minimal loss.
β LEDs and Lasers: Improve light emission and efficiency.
Detailed Explanation
In this chunk, the applications of photonic crystals are described, showcasing their role in improving technologies like optical filters, light guides, and emission devices. Their ability to control light leads to significant improvements in efficiency and function.
Examples & Analogies
Think of your favorite music playlist. A photonic crystal is similar to a skilled DJ who can select and mix songs perfectly, allowing only the best sounds through while blocking out the noise, enhancing the overall listening experience.
Real-World Applications of Nanomechanics and Nanophotonics
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
β Medical Devices: Nanomechanical sensors for detecting biomolecular interactions.
β Flexible Electronics: Use nanomaterials with high elasticity.
β Security: Anti-counterfeiting using optical signatures from quantum dots.
β Communication: High-speed data transmission using photonic circuits.
Detailed Explanation
This section concludes by presenting various real-world applications of nanomechanics and nanophotonics, demonstrating how these principles can directly impact fields like medicine, electronics, security, and communication. It illustrates the practical importance of the theories discussed throughout the chapter.
Examples & Analogies
Imagine a smart device that can track your health down to tiny changesβthis is like using the precise technologies discussed. These applications show us how understanding small-scale science leads to innovations that affect our everyday lives.
Chapter Summary
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
This chapter explored the principles of nanomechanics and nanophotonics, highlighting the distinct mechanical behaviors and optical phenomena occurring at the nanoscale. From enhanced elasticity and hardness to advanced light manipulation through plasmonics and photonic crystals, these topics form the backbone of many cutting-edge technologies. By understanding these principles, learners can appreciate the role of nanoscale mechanics and optics in revolutionizing materials science, electronics, medicine, and photonics.
Detailed Explanation
This chunk summarizes the chapter's content and emphasizes the transformative impact of nanomechanics and nanophotonics across various fields. It reinforces the importance of these concepts in advancing modern science and technology.
Examples & Analogies
Just like understanding the rules of a game is crucial to winning, mastering the principles of nanomechanics and nanophotonics can lead to breakthroughs in technology, helping us solve problems and innovate in ways we once thought impossible.
Definitions & Key Concepts
Learn essential terms and foundational ideas that form the basis of the topic.
Key Concepts
-
Unique Mechanical Properties: Nanoscale materials show enhanced elasticity and hardness due to fewer defects.
-
Light-Matter Interaction: Nanoscale materials allow for unique phenomena such as localized color changes and enhanced biosensing.
-
Applications of Plasmonics: SPR and LSPs are pivotal in biosensing and energy applications.
-
Significance of Quantum Dots: Their size-dependent properties enhance imaging and display technologies.
-
Photonic Crystal Principles: Periodical variations in refractive index create band gaps for light control.
Examples & Real-Life Applications
See how the concepts apply in real-world scenarios to understand their practical implications.
Examples
-
Carbon nanotubes exhibit extraordinarily high elasticity and a tensile strength greater than steel.
-
Gold nanoparticles can change color based on size due to their unique light absorption and scattering properties.
-
Quantum dots are employed in QLED TVs to produce vibrant colors by adjusting their sizes.
-
Photonic crystals are used to design optical filters in communication technologies.
Memory Aids
Use mnemonics, acronyms, or visual cues to help remember key information more easily.
π΅ Rhymes Time
-
Elasticity flows, like a stretched rubber hose, it will bounce back, thatβs how it goes!
π Fascinating Stories
-
Imagine a tiny rubber band around a needle; when you stretch it, it always returns to its formβlike nanomaterials returning to their shape after stress.
π§ Other Memory Gems
-
For hardness, remember: Small Grains = Strong Gains! This can help you recall the Hall-Petch effect.
π― Super Acronyms
Remember the acronym **PQS** - *Plasmonics, Quantum Dots, Surface effects* to quickly recall the key aspects of nanophotonics.
Flash Cards
Review key concepts with flashcards.
Glossary of Terms
Review the Definitions for terms.
-
Term: Elasticity
Definition:
The property of a material to return to its original shape after deformation.
-
Term: Hardness
Definition:
Resistance of a material to permanent deformation or scratching.
-
Term: Deformation
Definition:
The change of shape or size of an object under applied forces.
-
Term: Plasmonics
Definition:
The study of plasmons, which are quantized oscillations of free electron gas in metals.
-
Term: Quantum Dots
Definition:
Nanometer-sized semiconductor particles that exhibit quantum confinement effects.
-
Term: Photonic Crystals
Definition:
Materials with periodic variations in refractive index that create photonic band gaps to control light.
-
Term: Nanoindentation
Definition:
A technique used to measure the hardness and elastic modulus of materials at the nanoscale.
-
Term: Surface Plasmon Resonance (SPR)
Definition:
The resonance that occurs when light excites electrons at a metal-dielectric interface.
