Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Calculating the Number of Photographs Needed
Unlock Audio Lesson
Today, we're going to figure out how many photographs we need to cover a certain area in aerial photogrammetry. Can anyone tell me what parameters we need to consider?
Do we need the area dimensions and the overlap percentages?
Exactly! We'll use the area lengths, overlaps, and the scale of the photography. For example, if we have a longitudinal overlap of 60% and a side overlap of 30%, these will affect our calculations significantly.
How do we use those overlaps to calculate the number of photos?
Great question! We can use the formula: N1 = L / {(1 - OL) scale * photograph dimension} + 1 for longitudinal overlap. Do you want to try calculating for given dimensions?
Sure! If the flight line is 20 km and the photograph size is 23 cm, how would we do that?
Let's work through it step by step together. Remember to convert all units to meters for accuracy.
By the end of this, we’ll know how to determine the total number of photographs altogether, right?
That’s the goal! Let's also summarize our key points: overlapping percentages significantly influence the calculations and proper unit conversion is essential.
Understanding Relief Displacement
Unlock Audio Lesson
Next, let's discuss relief displacement. Who can explain what it is?
Isn't it the effect of elevation difference on how images are captured from the air?
That's correct! The higher an object is, the more it can appear to be displaced from where it actually is in the photo. For a given image displacement, we can calculate its height above datum using the formula d = rh/H.
How does the camera's focal length play a role in this?
Excellent query! It directly affects the scale and the distance estimates. If you understand this, you’re well on your way to mastering photogrammetry!
So, if the focal length increases, does the relief displacement also get affected?
Precisely! Increased focal lengths can lead to more pronounced relief displacements for the same height. Let’s summarize: remember that the displacement depends on elevation, focal length, and the relationship between these factors.
Practical Example Calculations
Unlock Audio Lesson
Now, let’s solve some practical example problems to solidify what we’ve learned. Who remembers how to compute the height of the tower using relief displacement?
We use the tower's actual height and the distance from the principal point, along with the formula.
Right again! Can someone give me an example from our notes?
For example, if a tower is 50 m and we measure a displacement of 0.254 cm from its bottom to top image?
Fantastic! Let's apply it in the equation to find heights. Remember to convert and simplify where necessary.
This really helps to understand how the different heights and measurements influence our calculations!
Exactly! Keep practicing these examples to make the concepts second nature!
Introduction & Overview
Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.
Quick Overview
Standard
The section provides detailed examples illustrating how to calculate critical parameters in aerial photogrammetry, including relief displacement and the number of photographs needed for coverage. Key formulas are introduced along with several relevant scenarios to enhance understanding.
Detailed
In this section, we delve into the technical aspects of aerial photogrammetry through a series of examples that illustrate the calculations of various photogrammetric parameters. Key points covered include the determination of the number of photographs required per flight line, the analysis of relief displacement, and the calculations regarding vertical photographs taken at specific elevations. Each example incorporates the necessary formulas, provides solutions, and emphasizes the significance of understanding these concepts in practical applications. Students will learn to navigate through different parameters such as scale, distances, and overlaps to ensure effective mapping and analysis.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Calculating Number of Photographs
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
A= L1 x L2 = 20 km x 16 km = 20000 m x 16000 m, Longitudinal overlap (OL) = 60% = 0.6, Side overlap (OS) =30% = 0.3, Scale 1: 15000, Photograph size = 23 cm x 23 cm = 0.23 m x 0.23 m = (L x L) N1 = Number of photographs per flight line = [L / {(1 – OL ) scale * L}] + 1 = [20000 / {(1 – 0.6) 15000 * 0.23}] + 1 = 14.49 + 1 = 16 (taking round figure to cover entire area) N2 = Number of flight lines = [L / {(1 – OS ) scale * L}] + 1 = [16000 / {(1 – 0.3) 15000 * 0.23}] + 1 = 6.62 + 1 = 8 (Taking whole no of flight lines) Total number of photograph required = N1 x N2 = 15 x 8 = 120 No
Detailed Explanation
This example shows how to calculate the number of aerial photographs required to cover an area effectively. We start with the dimensions of the area, which is 20 km by 16 km, and convert it to meters for easier calculations.
- First, compute the area as: A = 20 km x 16 km = 20000 m x 16000 m.
- Determine the longitudinal overlap (OL), which is given as 60%, meaning 0.6 in decimal form. This overlap is crucial as it ensures that adjacent photographs will capture some of the same area, helping in creating seamless maps.
- For the side overlap (OS), given as 30% or 0.3, which also helps in ensuring good coverage in the sideways direction.
- We are also given the photographs' scale of 1:15000 and their size of 23 cm by 23 cm, converted to meters for calculations.
- To find the number of photographs per flight line (N1), we use the formula based on area, overlap, and scale:
N1 = L / {(1 – OL) * scale * size} - Plugging in our values: N1 = [20000 / {(1 - 0.6) * 15000 * 0.23}] + 1. This computes to approximately 16 photographs.
- Similarly, compute the number of flight lines (N2) using side overlap:
N2 = [16000 / {(1 - 0.3) * 15000 * 0.23}] + 1, yielding approximately 8 flight lines. - Finally, multiply the number of photographs per flight line by the number of flight lines to get the total number of photographs required: Total = N1 * N2 = 16 * 8 = 120 photographs.
Examples & Analogies
Imagine you're taking pictures of a large garden to create an aerial map. Each photo captures a section of the garden, but to make sure you don't miss any parts, you intentionally overlap each photo with the next. Just like how you would overlap photos to maintain continuous coverage of your subject, the same principle applies here to ensure the entire area is captured with proper overlaps.
Relief Displacement Calculation Example 4.11
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Example 4.11: The distance from the principal point of a photograph to the image of the top of a tower is 6.44 cm and the elevation of the tower above the above datum is 250 m. What is the relief displacement of the tower if the scale is 1:10,000 above datum and the focal length of the camera is 20 cm? Solution: r = 6.44 cm, h = 250 m, scale =1:10000, f = 20 cm d = r h / H and S = f / H or H = f / S So, d = r h S / f d = (6.44 / 100) * 250 / (0.20 * 10000) = 6.44 / 800 = 0.00805 cm
Detailed Explanation
In this example, we are tasked with calculating the relief displacement for a tower from its photograph.
- Understand the variables: r is the distance from the principal point to the top of the tower image (6.44 cm), h is the elevation of the tower above the datum (250 m), scale is given as 1:10,000, and f is the focal length of the camera (20 cm).
- Convert values to consistent units: Since we're working with cm for r and f, we need to convert h to cm too. Calculate H which is the height above the datum corresponding to the scale and focal length:
H can be derived from the scale by noting that S = f / H, rearranging gives H = f / S where S = 1/10000 when translated into decimal. Calculate H = 20 cm / (1/10000) = 200,000 cm or 2000 m. - Next step is to calculate the relief displacement (d) using the formula d = (r * h * S) / f:
- First calculate r in meters (6.44 cm = 0.0644 m), then apply values:
- d = (0.0644 m * 250 m * (1/10000)) / 0.20 m = 0.00805 m.
- The final value of relief displacement is then simply stated in cm for a clear response, thus d = 0.00805 cm.
Examples & Analogies
Think of a photograph of a building taken from your drone. If the camera isn't perfectly straight, the taller parts of the building might appear displaced from where they actually are in relation to the rest of the image. This phenomenon is called relief displacement. In our tower's case, we measured how far off the tower's top appears due to this displacement and used our calculations to find out exactly how much it's off.
Calculating Tower Height Example 4.12
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Example 4.12: The vertical photograph of a flat area having an average elevation of 250 m above datum was taken with a camera of 20 cm focal length. A line PQ, 250 m long, measures 8.50 cm on the photograph. A tower TQ appears on the photograph, and the distance between the images of top and bottom of the tower TQ measures 0.46 cm on the photograph. If the distance of the image of the top of the tower from principal point of the photograph is 6.46 cm, determine the height of tower TQ above datum. Solution: Ground distance = 250 m, map distance = 8.50 cm, f = 20 cm, r = 6.46 cm, d = 0.46 cm S = f / H = 0.20 / H [(8.50 / 100) / 250] = 0.20 / H So, H = 0.20 * 25000 / 0.085 H = 588.24 m d = r h / H (0.46 / 100) = (6.46 / 100) * h / 588.24 h = 0.46 * 588.24 / 6.46 h = 41.90 m
Detailed Explanation
This example demonstrates how to calculate the height of the tower from an aerial photograph.
- Identify the variables: Ground distance (PQ) is 250 m, measured length on the photograph is 8.50 cm, focal length is f = 20 cm, distance r from the principal point of the image to the tower's image top is 6.46 cm, and the parallax difference d = 0.46 cm.
- Calculate the scale S: The scale can be calculated from the focal length and height (H). Scale S = f / H.
- We set up the proportions based on the ground to map distances: (Map distance / Ground distance = Scale) that gives us ground height H:
- (8.50 cm / 250 m) = (0.20 cm) / H. Rearranging gives us H = (0.20 * 25000) / 0.085 = 588.24 m approximately.
- Next, calculate the height of tower TQ above datum: rearranging d = (r * h) / H leads us to calculate height:
Set d = 0.46 cm to find h using our known values: h = (0.46 * 588.24) / 6.46, yielding h = 41.90 m. - Therefore, the height of the tower TQ above the datum is approximately 41.90 m.
Examples & Analogies
Imagine taking a picture of a tall tree with a ruler placed next to it. Just like measuring the tree's height using the image while considering where the ruler sits in relation to the camera, we use the principles from this calculation to find out how tall our tower is by analyzing its image on the photo.
Tower Image Displacement Calculation Example 4.13
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Example 4.13: The tower AB 50 m high above the ground, appears in a vertical photograph, was taken at a flying height of 2500 m above msl. The distance of the image of the top of the tower from principal point of the photograph is 6.35 cm. Determine the displacement of the image of the top of the tower with respect to the image of its bottom. The elevation of the bottom of the tower is 1250 m above msl. Solution: r = 6.35 cm= 0.0635 m, h = 50 m H = Flying height above the bottom of tower = 2500 – 1250 = 1250 m The displacement of the image of the top of the tower with respect to the image of its bottom = d = r h / H d = 0.0635 * 50 / 1250 d = 0.254 cm = 2.54 mm
Detailed Explanation
In this example, we calculate the displacement of a tower's image as seen in a vertical photograph.
- Understand the variables: The tower has a height (h) of 50 m, and its base is at an elevation of 1250 m, with the photograph taken from a flying height of 2500 m above mean sea level (msl).
- Convert variables: We note the distance of the image of the tower's top from the principal point is r = 6.35 cm, converted to meters as r = 0.0635 m.
- Calculate effective flying height: The effective height above the tower's bottom is computed as: H = 2500 m - 1250 m = 1250 m, which takes into account the elevation of the bottom of the tower.
- Calculate displacement: Use the formula d = (r * h) / H. Plugging the values gives: d = (0.0635 m * 50 m) / 1250 m = 0.254 cm or 2.54 mm.
- This calculation finds the displacement of the top of the tower image consequently providing insight into how high the tower appears relative to its base in the photograph.
Examples & Analogies
Think about how tall buildings can appear shorter or taller based on your viewpoint. If you take a photo of a building standing at an angle, the top may appear shifted compared to the bottom based on the shot. The same measurement concept applies when we look at how the tower appears in the image – the closer it is to the camera, the less displacement we’ll see.
Definitions & Key Concepts
Learn essential terms and foundational ideas that form the basis of the topic.
Key Concepts
-
Longitudinal and Side Overlap: These are essential for determining how many photographs are needed for complete coverage.
-
Relief Displacement: An important phenomenon affecting the perception of heights in aerial images.
-
Scale of Photography: Critical for understanding the relationship between photograph distance and actual ground distance.
Examples & Real-Life Applications
See how the concepts apply in real-world scenarios to understand their practical implications.
Examples
-
Example 4.11: Calculate the relief displacement of a tower given its height and the scale.
-
Example 4.12: Calculate the height of Tower TQ using measurements of vertical photographs.
Memory Aids
Use mnemonics, acronyms, or visual cues to help remember key information more easily.
🎵 Rhymes Time
-
When towers are tall and shadows are long, the displacement can make the image feel wrong.
📖 Fascinating Stories
-
Imagine you're a bird flying over a city. As you soar higher, the buildings look smaller; they seem to slide down the photo—this is the relief displacement at work!
🧠 Other Memory Gems
-
For remembering the formula of relief displacement, think 'r h / H' (Remember height over Height).
🎯 Super Acronyms
OL = Overlap Length; remember that for aerial photography maths.
Flash Cards
Review key concepts with flashcards.
Glossary of Terms
Review the Definitions for terms.
-
Term: Longitudinal overlap (OL)
Definition:
The percentage overlap of one photograph with the previous photograph along the flight line.
-
Term: Side overlap (OS)
Definition:
The percentage overlap of one photograph with the adjacent photograph across the width.
-
Term: Relief displacement (d)
Definition:
The apparent displacement of an object in a photograph due to its height above the datum.
-
Term: Scale
Definition:
The ratio of a distance on the photograph to the corresponding distance on the ground.
-
Term: Principal Point
Definition:
The central point of a photograph from which other measurements are derived.
