3.4.2. Choropleth Maps

The choropleth maps are also drawn to depict the data characteristics as they are related to the administrative units. These maps are used to represent the density of population, literacy/growth rates, sex ratio, etc.

Choropleth maps provide a visual representation of how certain characteristics (like population density or literacy rates) vary across different administrative regions, such as states or districts. Each region is shaded or colored based on the value of the characteristic it represents, allowing for easy comparison across areas.

Imagine a map of a school showing grades in each class. Classes with high grades could be shaded in green, and those with failing grades in red. This way, you can quickly identify which classes are performing well and which need extra help.

Requirement for drawing Choropleth Map (a) A map of the area depicting different administrative units. (b) Appropriate statistical data according to administrative units.

To create a choropleth map, you first need a base map that clearly outlines the boundaries of the administrative units you are studying (like states or countries). Then, you must gather and use relevant statistical data for these units to determine how to shade or color each area based on the variables you are analyzing.

Think of a puzzle where each piece represents a different area. You need to first have all the pieces laid out (the map) and then use different colors to fill in these pieces based on how well each piece contributes to a bigger picture (the statistical data).

(a) Arrange the data in ascending or descending order. (b) Group the data into 5 categories to represent very high, high, medium, low and very low concentrations. (c) The interval between the categories may be identified on the following formulae i.e., Range/5 and Range = maximum value – minimum value. (d) Patterns, shades or colour to be used to depict the chosen categories should be marked in an increasing or decreasing order.

When creating a choropleth map, you start by sorting your data. Next, you categorize this data into five groups based on value ranges—very low, low, medium, high, and very high. The range of your data gives you the ability to divide it evenly into these categories using a simple calculation. Finally, you assign specific colors or patterns to each category, typically going from light to dark or from one color to another to visually signify increasing values.

Consider grading papers on a scale. You might sort students' scores into ranges: below 50 (red for failure), 50-70 (yellow for average), 70-85 (light green for good), and above 85 (dark green for excellent). When you create a visual display of this, it quickly tells you which students need help and which are excelling.

Example 3.13: Construct a Choropleth map to represent the literacy rates in India in 2001 as given in Table 3.10.

Construction (a) Arrange the data in ascending order as shown above. (b) Identify the range within the data. In the present case, the states recording the lowest and highest literacy rates are Bihar (47%) and Kerala (90.9%), respectively. Hence, the range would be 91.0 – 47.0 = 44.0 (c) Divide the range by 5 to get categories from very low to very high. (44.0/5 = 8.80. We can convert this value to a round number, i. e., 9.0 (d) Determine the number of the categories alongwith the range of each category. Add 9.0 to the lowest value of 47.0 as so on.

In this example, the first step is to arrange literacy rates from low to high. Next, you identify the minimum and maximum rates (47% for Bihar and 90.9% for Kerala), and calculate the range. By dividing this range into five equal categories, you create bands to classify literacy levels. These bands are then used to color different states in your choropleth map, allowing viewers to see which states have high or low literacy rates.

Imagine you are grading students' performance from worst to best: the lowest performer gets a failing grade, while the top performers might be in the top two grades. When you color in the students based on their performance ranges, it allows teachers to easily see which groups need more help.

--
