4.3. Cohesive soils compacted dry of optimum vs. wet.

Shear strength of cohesive soils compacted dry of optimum (flocculated structure) will be higher than those compacted wet of optimum (dispersed structure).

Cohesive soils, such as clays, can exhibit different strengths based on their moisture content during compaction. When cohesive soils are compacted dry of optimum moisture content, they tend to form a flocculated structure. This means the particles are arranged in a way that enhances their resistance to shear forces, resulting in higher shear strength. Conversely, when such soils are compacted at or above optimum moisture, they assume a dispersed structure, which reduces their overall strength. Hence, for effective construction projects, understanding this distinction is crucial.

Think of making a clay sculpture. When the clay is dry and crumbly, it's easier to press and mold into a sturdy figure (similar to a flocculated structure). If you add too much water, the clay becomes mushy and loses its form (similar to a dispersed structure), making it easier to squash but harder to maintain shapes.

On dry side of optimum, the structure is flocculated. The particles repel and density is less. Addition of water increases lubrication and transforms the structure into dispersed structure.

The state of moisture during compaction significantly affects the arrangement of soil particles. On the dry side of optimum moisture content, cohesion particles tend to clump together, creating a flocculated structure—this results in a reduced density as the particles repel each other due to repulsive forces. However, when water is added, it serves to lubricate the particles, leading to a transformation into a dispersed structure. This transition increases the soil’s ability to be worked with but decreases its strength when moist.

Imagine a group of friends holding hands while trying to form a circle on a slippery surface. If they are holding hands loosely (dry side of optimum), they might not form a stable circle (flocculated). However, if water is introduced (like adding lubrication), they can twist and turn around easily, but they might lose the initial grip needed to hold the circle together effectively (dispersed).

The strength and modulus of elasticity of soil on the dry side of optimum will always be better than on the wet side for the same density. Soil compacted dry of optimum shows brittle failure and that compacted on wet side experiences increased strain.

Soil's behavior during compaction finalizes its mechanical properties such as strength and stiffness or modulus of elasticity. Soils compacted dry of optimum exhibit higher strength and elasticity compared to their wet counterparts when both are at the same density. This is largely due to the structural arrangement of soil particles—drier soils tend to hold their shapes under pressure better but can lead to brittle failure when stressed. In contrast, wet soils, while weaker, can undergo greater deformation before failing, often absorbing more strain.

Consider two bridges made of the same material. One is built with a rigid frame (dry side of optimum) which can hold more weight but might crack under too much pressure (brittle failure). The other bridge has a flexible design (wet side) which can bend and stretch under load but might not hold as much weight safely. This comparison illustrates the differences in failure modes between dry-compacted and wet-compacted soils.

--
