3.3.5 - Angles of a parallelogram
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Angles of a Parallelogram
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Good morning class! Today, we're going to discuss the angles of a parallelogram. Can anyone tell me what shapes make up a parallelogram?
A parallelogram has two pairs of opposite sides that are parallel.
Exactly! Now, what do you think happens to the angles of a parallelogram?
I think opposite angles are equal!
Right! We can remember that with the acronym 'OAE' — Opposite Angles Equal. Let's consider some examples to illustrate this. Who can draw a parallelogram and label its angles?
Can I also show how opposite angles are equal in my drawing?
Of course! The more examples, the better understanding we'll have!
I’ll draw one now, and I see angle A equals angle C!
Fantastic! This property helps us determine unknown angles in problems.
Adjacent Angles of a Parallelogram
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now, let's explore adjacent angles. What do you think happens to angles A and B in a parallelogram?
They should be supplementary, right? Their measures add up to 180°.
Exactly! Remember the mnemonic 'AS180' for Adjacent Angles Supplementary. Who can show that on their drawings?
I just made a right triangle next to my parallelogram, and that helped me understand!
Great method! Using external shapes like triangles can aid our comprehension of supplementary angles.
Is there a way to check my calculations logically?
Absolutely. After summing your adjacent angles, you can verify that they equal 180°.
Finding Unknown Angles
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let's consolidate what we've learned by finding unknown angles. If ∠A = 70°, what are m∠B and m∠C?
I think ∠B must be 110° because 70° + 110° = 180°.
Well done! And what about ∠C?
It also equals 70° since it's the opposite angle to ∠A!
I see how these properties together help confirm all angle measures.
Exactly! Understanding these relationships will be beneficial in solving more complex geometric problems. Keep practicing!
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
The angles in a parallelogram are notable for having specific properties: opposite angles are equal, and adjacent angles are supplementary. This section provides conceptual exploration and examples to understand these properties clearly.
Detailed
Angles of a Parallelogram
In this section, we explore the fascinating properties of angles in parallelograms. A parallelogram is defined as a quadrilateral with opposite sides that are parallel. When we focus on the angles, we discover some important characteristics:
Key Properties:
- Opposite Angles: In a parallelogram, the opposite angles are equal. For example, if we label the angles of a parallelogram ABCD, then angle A equals angle C (m∠A = m∠C), and angle B equals angle D (m∠B = m∠D).
- Adjacent Angles: The adjacent angles are supplementary, meaning that their measures add up to 180 degrees. For instance, m∠A + m∠B = 180° and m∠C + m∠D = 180°. This can be visualized using transversal lines intersecting parallel sides that create interior angles.
Significance:
Understanding these properties is crucial in various applications of geometry, allowing us to deduce missing angle measures and offering a foundation for understanding more complex geometric shapes.
Conclusion:
The study of parallelograms emphasizes the harmonious relationships between their angles, providing a pathway to explore its more complex forms, such as rectangles and rhombuses. The study and proof of these properties underscore the elegance of geometric principles.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Opposite Angles of a Parallelogram
Chapter 1 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
We studied a property of parallelograms concerning the (opposite) sides. What can we say about the angles?
DO THIS
Let ABCD be a parallelogram (Fig 3.17). Copy it on a tracing sheet. Name this copy as A′B′C′D′. Place A′B′C′D′ on ABCD. Pin them together at the point where the diagonals meet. Rotate the transparent sheet by 180°. The parallelograms still coincide; but you now find A′ lying exactly on C and vice-versa; similarly B′ lies on D and vice-versa.
Does this tell you anything about the measures of the angles A and C? Examine the same for angles B and D. State your findings.
Property: The opposite angles of a parallelogram are of equal measure.
Detailed Explanation
In a parallelogram, opposite angles have the same measure. To understand this, imagine taking a parallelogram ABCD and tracing it onto another sheet as A'B'C'D'. By pinning them together at the intersection of the diagonals and rotating the sheet, we can see that the points A' and C coincide, indicating that angles A and C are equal. The same applies for angles B and D. Therefore, opposite angles in a parallelogram must always be equal.
Examples & Analogies
Think of a parallelogram like a pair of opposing magnets; when you turn one magnet to line it up with the other, they match perfectly. Just as those magnets hold their positions when they're aligned, the angles at opposite corners of the parallelogram remain equal, no matter how you turn it.
Adjacent Angles of a Parallelogram
Chapter 2 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
TRY THESE
Take two identical 30° – 60° – 90° set-squares and form a parallelogram as before. Does the figure obtained help you to confirm the above property?
You can further justify this idea through logical arguments.
If AC and BD are the diagonals of the parallelogram, (Fig 3.18) you find that ∠1 =∠2 and ∠3 = ∠4 (Why?)
Property: The adjacent angles in a parallelogram are supplementary.
Detailed Explanation
Adjacent angles in a parallelogram are supplementary, meaning that the sum of each pair of adjacent angles equals 180 degrees. When you look at the diagonals of the parallelogram, angles ∠1 and ∠2 are formed by one pair of adjacent sides, while ∠3 and ∠4 form another pair. Since they share a side and are on opposite sides of the diagonal, they must sum up to 180 degrees. Thus, adjacent angles in a parallelogram are always supplementary.
Examples & Analogies
Imagine sitting at a rectangular table. If you're at one corner and your friend is sitting at the opposite corner, the angles formed by the corners around you add up to make a straight line (180 degrees). Every time you turn to face another corner, those angles you see are still together making a straight line. This is similar to how adjacent angles in a parallelogram relate to each other.
Example Application
Chapter 3 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Example 4: In Fig 3.20, BEST is a parallelogram. Find the values x, y and z.
Solution: S is opposite to B. So, x =100° (opposite angles property) y =100° (measure of angle corresponding to ∠x) z =80° (since ∠y, ∠z is a linear pair).
Detailed Explanation
To find the angles in parallelogram BEST, we apply the properties we discussed. Knowing that opposite angles are equal, we determine that if angle S is opposite to B and equals 100°, then ∠B must also equal 100°. Since angles y and z are adjacent, they must add up to 180° because of the supplementary property. Therefore, if angle y is 100°, then angle z = 180° − 100° = 80°.
Examples & Analogies
Think of following a set of rules in a board game. If you know one player has 100 points (angle of x), then by the rules of the game, the player across from them must also have 100 points (angle of y). The points next to the first player then must total to the whole set of 180 points available, meaning they lose some of their points (angle of z). This reflects how angles work in a parallelogram!
Key Concepts
-
Opposite Angles: In a parallelogram, opposite angles are equal in measure.
-
Adjacent Angles: Adjacent angles in a parallelogram are supplementary, adding up to 180 degrees.
Examples & Applications
If angle A is 70°, angle C is also 70° (opposite angles property).
If angle A is 60°, then angle B would be 120° (using supplementary angles property).
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
In a parallelogram, to remember, the pairs of opposite angles are equal, so stay clever!
Stories
Imagine two friends at angles walking opposite directions. Their measures are the same, just like in a parallelogram!
Memory Tools
Use 'OAE' for Opposite Angles Equal and 'AS180' for Adjacent Supplementary.
Acronyms
PANGS - Parallelograms have All Opposite angles equal and Adjacent angles Supplementary.
Flash Cards
Glossary
- Parallelogram
A quadrilateral with opposite sides that are parallel.
- Supplementary Angles
Two angles that add up to 180 degrees.
- Opposite Angles
Angles that are across from each other in a polygon; in a parallelogram, they are equal.
- Adjacent Angles
Angles that are next to each other, sharing a vertex.
