3.3.6 - Diagonals of a parallelogram
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Diagonals
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Alright students, today we're diving into the diagonals of a parallelogram. Who can tell me what a diagonal is?
A diagonal is a line segment that connects two non-adjacent vertices of a polygon.
Exactly! In a parallelogram, we have two diagonals. Can anyone tell me if these diagonals are of equal length?
No, they generally aren't equal!
That's right! But here’s an interesting property: what do you think happens when these diagonals cross each other?
Are they bisecting each other?
Correct! They do bisect each other at the point of intersection. This means that each diagonal divides into two equal parts.
So, if I fold the parallelogram to find the midpoints, they should meet at the intersection?
Yes! Let’s try that in our hands-on activity!
Remember: **Diagonals bisect each other** - that's the key takeaway from today!
Hands-On Activity: Finding Midpoints
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now that we've discussed the bisection of diagonals, let’s do an activity! Grab your parallelogram cut-outs.
What should we do first?
Fold the cut-out from one vertex to its opposite. What do you notice about the intersection point of the folds?
It looks like this point marks the midpoint of the diagonal!
Exactly! Let’s perform the same fold for the other diagonal. What do you observe?
They all meet at the same point!
Great observation! This shows that the diagonals not only intersect but bisect each other at this point. That’s our geometric property in action!
So, whenever we have a parallelogram, the diagonals will always bisect each other?
Yes, that remains true for all parallelograms! Keep that in mind.
Proof of Diagonal Bisection
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now, let’s discuss how we can formally prove that the diagonals of a parallelogram bisect each other.
How do we start the proof?
We begin by considering triangles AOB and COD. What do you think we can say about them?
They share common side OA and OC, right?
Correct! Plus, we note that ∠AOB is equal to ∠COD because they are vertically opposite angles. So, we have an angle, a side, and another angle matching!
That sounds like ASA, right?
Exactly! By the ASA criterion, we conclude that the triangles are congruent, which gives us that AO = CO and BO = DO. Anyone remember what this means?
The diagonals bisect each other!
Well done! Remember, this proof solidifies our understanding of the property of diagonals in parallelograms.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
In this section, we learn that the diagonals of a parallelogram are not generally equal in length, but an important property is that they bisect each other. This fact is reinforced through practical activities and geometric rationale, providing a strong foundation for understanding the structure of parallelograms.
Detailed
Diagonals of a Parallelogram
The diagonals of a parallelogram, such as quadrilateral ABCD, are significant in understanding its geometric properties. While it is known that the diagonals are generally not equal in length, they have a unique and important characteristic: they bisect each other.
Key Concept: Bisection of Diagonals
- Definition: To bisect means to divide into two equal parts. In the case of a parallelogram, when the diagonals (e.g., AC and BD) intersect at a point O, they divide each other into two equal segments (AO = CO and BO = DO).
- Activity: By folding a cut-out parallelogram to find the midpoints of the diagonals, students can observe that the midpoints coincide at the intersection point, showcasing the bisection property visually.
- Geometric Proof: Using congruent triangles formed by the diagonals, specifically triangles AOB and COD, we apply the ASA (Angle-Side-Angle) congruency criterion to establish AO = CO and BO = DO, confirming that diagonals bisect each other.
Understanding this property of diagonals is essential as it lays the groundwork for further exploration of parallelograms and their relationships with other geometric figures.
Similar Questions
- Example : HELP is a parallelogram (Lengths are in meters). Given that OE = 5 and HL is 7 more than PE? Find OH.
Solution: If OE = 5 then OP also is 5 (Why?)
PE = 10,
Therefore, HL = 10 + 7 = 17
Hence
\[ OH = \frac{1}{2} \times 17 = 8.5 \; \text{(meters)} \]
- Example: HELP is a parallelogram (Lengths are in feet). If OE = 6 and HL is 4 less than PE, find OH.
Solution: If OE = 6 then OP also is 6 (Why?)
PE = 12,
Therefore, HL = 12 - 4 = 8
Hence
\[ OH = \frac{1}{2} \times 8 = 4 \; \text{(feet)} \]
- Example: HELP is a parallelogram (Lengths are in inches). Given that OE = 3 and HL is 6 more than PE, find OH.
Solution: If OE = 3 then OP also is 3 (Why?)
PE = 5,
Therefore, HL = 5 + 6 = 11
Hence
\[ OH = \frac{1}{2} \times 11 = 5.5 \; \text{(inches)} \]
- Example: HELP is a parallelogram (Lengths are in kilometers). If OE = 7 and HL is twice PE, find OH.
Solution: If OE = 7 then OP also is 7 (Why?)
PE = 4,
Therefore, HL = 2 \times 4 = 8
Hence
\[ OH = \frac{1}{2} \times 8 = 4 \; \text{(kilometers)} \]
- Example: HELP is a parallelogram (Lengths are in centimeters). If OE = 2 and HL is 9 more than PE, find OH.
Solution: If OE = 2 then OP also is 2 (Why?)
PE = 6,
Therefore, HL = 6 + 9 = 15
Hence
\[ OH = \frac{1}{2} \times 15 = 7.5 \; \text{(centimeters)} \]
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Property of Diagonals
Chapter 1 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The diagonals of a parallelogram, in general, are not of equal length. However, the diagonals of a parallelogram have an interesting property.
Detailed Explanation
In a parallelogram, while the diagonals do not necessarily have the same length, they do intersect in a way that is consistent across all parallelograms. This means that the two diagonals divide each other into two equal parts. This property is crucial for understanding the relationship between the sides of a parallelogram and provides insights into its geometry.
Examples & Analogies
Think of a playground seesaw. The point where the seesaw balances is like the intersection of the diagonals in a parallelogram. No matter how heavy one end is, the seesaw balances at its midpoint. Similarly, in a parallelogram, the diagonals meet at a point that equally divides them, showing balance.
Illustrating the Property
Chapter 2 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
DO THIS: Take a cut-out of a parallelogram, say, ABCD (Fig 3.23). Let its diagonals AC and DB meet at O. Find the mid point of AC by a fold, placing C on A. Is the mid-point the same as O? Does this show that diagonal DB bisects the diagonal AC at the point O?
Detailed Explanation
This hands-on activity demonstrates the property of diagonal bisection. By folding the diagonal AC, students can visibly see where the midpoint is located. When they place point C directly over point A, if the midpoint aligns with point O (the intersection point), it confirms that diagonal DB bisects AC at that point. If this observation is repeated with diagonal DB, it further emphasizes the bisection property.
Examples & Analogies
Imagine cutting a pizza in half. When you slice it, no matter how you cut, the center point of the pizza is the same. This is much like how the diagonals of a parallelogram cut through each other; they divide each other evenly at their intersection point, just like the pizza is split evenly at the center.
Justifying the Diagonal Property
Chapter 3 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
To argue and justify this property is not very difficult. From Fig 3.24, applying ASA criterion, it is easy to see that ∆ AOB ≅ ∆ COD (How is ASA used here?). This gives AO = CO and BO = DO.
Detailed Explanation
The ASA (Angle-Side-Angle) criterion states that if two angles and the included side of one triangle are equal to the corresponding angles and side of another triangle, then the two triangles are congruent. In the context of diagonals in a parallelogram, we establish that triangles AOB and COD have equal angles and a shared side (the line segment that forms part of both triangles). Consequently, this congruence allows us to conclude that AO equals CO and BO equals DO—demonstrating that the diagonals bisect each other.
Examples & Analogies
Think about a kite’s tail. The two equal-length lines representing the tail show how each part splits evenly, creating symmetry. Much like the diagonals in a parallelogram creating symmetrical triangles at their intersection, this symmetry showcases balance and equality.
Example Application
Chapter 4 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Example 6: In Fig 3.25 HELP is a parallelogram. (Lengths are in cms). Given that OE = 4 and HL is 5 more than PE? Find OH.
Detailed Explanation
In this example, we apply the property of diagonal bisection to calculate lengths in the parallelogram. Knowing that OE equals 4 allows us to immediately conclude that OP is also 4, as diagonals bisect each other. Since we can also say that PE equals 8 (given OH plus OE), we can deduce all related lengths. Solving the equations built around these relationships allows students to apply theory to practice.
Examples & Analogies
Consider using a ruler to measure the lengths of a shelf. Just like each segment of the shelf needs to be balanced and measured accurately, the diagonals in a parallelogram maintain balance and equal division, allowing for straightforward calculations of different parts based on established properties.
Key Concepts
-
Diagonals bisect each other: The diagonals of a parallelogram intersect at a point that divides each diagonal into two equal segments.
-
Congruent triangles from diagonals: The diagonals create pairs of congruent triangles that help demonstrate the properties of the parallelogram.
Examples & Applications
In parallelogram ABCD, if the diagonals AC and BD intersect at point O, then AO = CO and BO = DO.
If ABCD is a parallelogram, you can fold it along diagonal AC to see that point O is exactly the midpoint of both AC and BD.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
In a parallelogram's dance, the diagonals split like chance!
Stories
Imagine two friends, Ada and B, crossing paths at a park – their meeting point always divides their journey equally. This is how it works with the diagonals in a parallelogram!
Memory Tools
B.D.E. – Bisect Diagonal Exits: Remember that the diagonals bisect at their intersection.
Acronyms
P.E.A.C.E. - Parallelogram's Equal Angle Congruency Exists
Reflects key properties of diagonals and angles.
Flash Cards
Glossary
- Diagonal
A line segment connecting two non-adjacent vertices of a polygon.
- Bisection
The division of something into two equal parts.
- Congruent Triangles
Triangles that are equal in size and shape, having corresponding sides and angles that are equal.
- ASA Criterion
A condition for triangle congruence stating that if two angles and the included side of one triangle are equal to two angles and the included side of another triangle, then the two triangles are congruent.
