4.10 - Admixtures in Special Concretes
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Self-Compacting Concrete (SCC)
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, let's dive into Self-Compacting Concrete, or SCC. Who can tell me what makes SCC different from regular concrete?
I think it flows better, right?
Exactly! SCC flows under its own weight. To achieve this, we use admixtures like high-range water reducers. Can anyone name an example of such an admixture?
Isn't Polycarboxylate Ether one of them?
Correct! PCEs are widely used. Additionally, viscosity-modifying admixtures prevent segregation. Can anyone explain why we need air-entrainers in SCC?
So it can withstand freezing and thawing?
Right! Air-entrainers trap microscopic air bubbles, enhancing durability. To remember these points, think of 'SCC: Super fluid, Controlled Cohesion.'
In summary, SCC uses PCEs, VMAs, and air-entrainers to achieve desired properties. Well done, everyone!
High-Performance Concrete (HPC)
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now let's move on to High-Performance Concrete, or HPC. What are some of its defining characteristics?
HPC has improved strength and durability!
Exactly! It often includes superplasticizers. Why do you think silica fume might be added?
To enhance strength and reduce permeability?
Yes! Silica fume provides great benefits. We also use corrosion inhibitors for reinforced concrete in harsh environments. Can anyone name one?
Calcium nitrite?
Great job! Calcium nitrite helps protect against chlorides in coastal areas. To summarize, HPC blends superplasticizers, silica fume, and corrosion inhibitors for outstanding performance!
Shotcrete
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Next, we are going to cover Shotcrete. Who can tell me what shotcrete is used for?
It's used for applications like tunnels and slopes, right?
Spot on! In shotcrete, accelerators are essential for fast setting. Why do we need to improve pumpability?
To ensure it can be applied to vertical surfaces easily!
Exactly! Plasticizers improve workability. As a mnemonic, think of 'Shotcrete: Speedy, Held, and Tight.'
To recap, shotcrete uses accelerators for rapid setting and plasticizers for pumpability. Great discussion today!
Mass Concrete
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now let’s discuss Mass Concrete. What issues are we trying to prevent when using mass concrete?
We want to avoid thermal cracking due to heat of hydration.
Exactly! That’s why we often use retarders. Can anyone think of any supplementary cementitious materials we might use?
Fly ash or slag?
Correct! SCMs help control the temperature during hydration. Remember the phrase 'Mass Concrete: Moderation of Heat.'
In summary, mass concrete employs retarders and SCMs to manage hydration heat effectively. Excellent participation today!
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
Admixtures are specially formulated additives that enhance the properties of specific types of concrete, such as Self-Compacting Concrete (SCC), High-Performance Concrete (HPC), Shotcrete, and Mass Concrete. This section details the unique requirements and combinations of admixtures used to optimize the performance of these special concretes.
Detailed
Admixtures in Special Concretes
In modern construction, specialized concrete types are essential for meeting unique performance demands. Admixtures have been developed to cater to the needs of advanced concretes:
-
Self-Compacting Concrete (SCC)
SCC requires high-range water reducers (such as Polycarboxylate Ethers, PCE), Viscosity Modifying Admixtures (VMAs) to prevent segregation, and air-entrainers to enhance flow and reduce resistance. -
High-Performance Concrete (HPC)
This type of concrete utilizes combinations of superplasticizers, shrinkage reducers, silica fume, and corrosion inhibitors tailored for reinforced concrete, especially in marine environments. -
Shotcrete
In this application, accelerating admixtures are crucial for achieving rapid setting times. Plasticizers are also used to improve pumpability, making the material easier to apply in vertical or overhead applications. -
Mass Concrete
Here, retarders are critical for controlling the heat of hydration to prevent thermal cracking, alongside the use of supplementary cementitious materials (SCMs) like fly ash or slag to aid temperature management.
These advanced admixtures not only enhance the structural qualities of concrete but also contribute to sustainability and efficiency in construction practices.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Self-Compacting Concrete (SCC)
Chapter 1 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
- Self-Compacting Concrete (SCC)
- Requires:
- High-range water reducers (PCE).
- VMAs to prevent segregation.
- Air-entrainers to improve flow and reduce resistance.
Detailed Explanation
Self-Compacting Concrete (SCC) is a special type of concrete that flows and compacts under its own weight without the need for vibration. To achieve this, specific admixtures are used:
- High-range water reducers (PCE): These admixtures maintain the right amount of water while enhancing the flow of concrete, making it easier to pour and shape.
- Viscosity Modifying Admixtures (VMAs): These help in preventing segregation, which is when solid particles separate from the liquid. They ensure that the concrete remains homogenous even when it's flowing freely.
- Air-entrainers: These are used to introduce tiny air bubbles into the mix, which not only helps improve the flow of the SCC but also enhances its resistance to freezing and thawing cycles.
Overall, these components work together to create a concrete that can fill forms and undercuts naturally and maintain stability and strength.
Examples & Analogies
Think of SCC like a thick smoothie that pours easily into a glass without needing a straw to help it along. Just as a good smoothie has the right ingredients to flow smoothly without separating, SCC combines special admixtures that ensure it flows freely and settles evenly without the need for extra vibrations.
High-Performance Concrete (HPC)
Chapter 2 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
- High-Performance Concrete (HPC)
- Uses combinations of:
- Superplasticizers.
- Shrinkage reducers.
- Silica fume or mineral admixtures (covered in Chapter 5).
- Corrosion inhibitors for reinforced concrete in marine environments.
Detailed Explanation
High-Performance Concrete (HPC) refers to concrete that has superior properties, such as high strength, low permeability, and increased durability. To achieve these characteristics, several key admixtures are combined:
- Superplasticizers: These are water reducers that allow for a lower water-cement ratio while maintaining workability, leading to stronger concrete.
- Shrinkage reducers: These help minimize cracking due to drying shrinkage, making the concrete more resilient over time.
- Silica fume: This is a byproduct of silicon metal production that greatly improves the strength and durability of HPC.
- Corrosion inhibitors: In marine environments, where concrete is exposed to saltwater, these admixtures protect the embedded steel reinforcements from rusting and damage, which can compromise the integrity of structures.
By using these components effectively, HPC provides durability and longevity in challenging conditions.
Examples & Analogies
Imagine building a bridge in a coastal area. You wouldn't want it to wear down quickly from saltwater corrosion. HPC acts like a high-quality raincoat that not only keeps you dry from the rain (corrosion) but also remains breathable and comfortable (strong and durable) even when the weather gets rough.
Shotcrete
Chapter 3 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
- Shotcrete
- Accelerating admixtures are critical to achieve fast setting.
- Plasticizers improve pumpability.
Detailed Explanation
Shotcrete is a method of applying concrete in a spray form, often used for building shapes like tunnels, pools, and retaining walls. The application of accelerating admixtures is essential since they help the concrete set quickly. This quick setting is especially important in situations where the sprayed concrete might be exposed to gravity and needs to harden rapidly to maintain its shape. Additionally, plasticizers are used to improve pumpability, ensuring that the concrete mixture can be pumped swiftly through hoses to the applicator without clogging. This ensures a smooth and efficient construction process.
Examples & Analogies
Think about making a cake batter that you need to pour quickly into a hot frying pan. You want it to set fast, so you add a special ingredient that helps it cook quickly. In shotcrete, the accelerators work in a similar way, ensuring the concrete sets rapidly as it’s being sprayed onto surfaces.
Mass Concrete
Chapter 4 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
- Mass Concrete
- Retarders used to control heat of hydration and avoid thermal cracking.
- SCMs (like fly ash or slag, discussed in Chapter 5) also aid temperature control.
Detailed Explanation
Mass concrete refers to large volumes of concrete placed in one go, such as in dams or large foundations. One challenge with mass concrete is the heat generated during hydration – the chemical process when water mixes with cement. This heat can cause thermal cracking, which weakens the structure. To mitigate this, retarders are used to slow down the setting time, allowing the heat to dissipate more gradually. Additionally, supplementary cementitious materials (SCMs) like fly ash or slag can be incorporated to further control the heat and improve the overall properties of the concrete mix. By managing hydration and temperature effectively, mass concrete can be placed safely and efficiently.
Examples & Analogies
Imagine making a large pot of soup on the stove. The heat from cooking can cause the pot to crack if it gets too hot too quickly. Using a lower heat setting (like using retarders) allows the soup to simmer without bubbling over, keeping your pot intact. Similarly, in mass concrete, controlling the heat prevents cracking.
Key Concepts
-
Self-Compacting Concrete: SCC requires high-range water reducers, VMAs, and air-entrainers for better flow.
-
High-Performance Concrete: HPC integrates superplasticizers, silica fume, and corrosion inhibitors for enhanced durability.
-
Shotcrete: Shotcrete uses accelerators and plasticizers for rapid application and pumpability.
-
Mass Concrete: Mass concrete uses retarders and SCMs to control heat of hydration.
Examples & Applications
Example of SCC: A bridge foundation constructed using SCC that flows into complex, tight spaces without voids.
Example of HPC: A high-rise building utilizing HPC in its columns and beams for increased load-bearing capacity.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
To make concrete that flows with ease, add PCE and air—if you please.
Stories
Imagine building a bridge. You need the concrete to flow without stopping—this is where SCC, with its high-range reducers, comes in!
Memory Tools
For HPC, remember 'SSS'—Superplasticizer, Silica fume, and Shrinkage reducers.
Acronyms
Think 'SCM' for Mass Concrete
Supervision of Cracking Management through retarders.
Flash Cards
Glossary
- SelfCompacting Concrete (SCC)
A type of concrete that can spread and fill molds under its own weight, requiring no compaction.
- HighPerformance Concrete (HPC)
Concrete with superior strength, durability, and a reduced permeability compared to regular concrete.
- Shotcrete
A concrete application method which involves spraying concrete onto surfaces at high velocity.
- Mass Concrete
Large volumes of concrete that must be managed to control temperature and avoid cracking.
- Admixture
A material added to concrete to improve its properties, such as workability, strength, and durability.
