35.18 - Use of PGA in Performance-Based Seismic Design (PBSD)
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to PBSD and PGA
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we are going to explore Performance-Based Seismic Design, often referred to as PBSD. Can anyone tell me what they think PBSD might involve?
I think it's about designing buildings that can withstand earthquakes.
That's correct! PBSD focuses on meeting specific performance objectives under different levels of seismic activity. A crucial part of this design approach is Peak Ground Acceleration or PGA. How do you think PGA is used in this context?
Isn't it related to how much the ground moves during an earthquake?
Exactly! PGA measures the maximum acceleration of ground motion. It is used to establish performance categories such as operational, life safety, and collapse prevention. Let's remember these categories with the mnemonic OLC: Operations, Life Safety, and Collapse.
Can you explain more about those categories and their PGA values?
Sure! Operational means PGA about 0.1g, suggesting minor damage. Life Safety is around 0.2g, allowing for moderate damage but preventing collapse. Finally, Collapse Prevention starts at 0.36g, designed to avoid total failure. So, it’s essential to consider these when designing structures.
How does this relate to the safety of people inside the buildings?
Great question! The design categories help ensure that in the event of an earthquake, occupants can safely evacuate, and the structure can endure without completely failing.
Performance Objectives in PBSD
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now let’s delve deeper into the performance objectives associated with different PGA levels in PBSD. Why do you think it’s essential to have these thresholds?
Maybe to ensure buildings can handle the shaking without falling down?
Exactly! Each PGA threshold corresponds to a level of expected structural performance. For example, if we design for operational use with a PGA of around 0.1g, we anticipate only minor issues. Can anyone share why implementing these thresholds is crucial?
So that people can plan for safety and respond accordingly in an earthquake?
Right! It helps engineers in planning for risks, ensuring that buildings are built to withstand specified seismic forces while maintaining safety.
And what happens if we exceed these values?
Good point! Exceeding these thresholds could lead to significant structural damage or even collapse. That’s why understanding PGA and its implications is vital.
Annual Exceedance Probabilities and PGA
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Next, let’s discuss how PGA relates to annual exceedance probabilities. Can someone tell me what they understand about this concept?
I think it’s about the likelihood of experiencing a certain level of ground shaking over time.
Exactly! For instance, if a structure is designed for a 10% probability of exceedance in 50 years, it means there's a substantial risk of experiencing that PGA during its lifetime. What does this imply for engineers?
They need to be aware of how often those levels might be reached and design accordingly.
Precisely! They can use this information to design for safety and performance. Let’s remember this using the acronym 'PGA-P', which stands for 'Probability Ground Acceleration – Planning'.
So, engineers must consider these probabilities when planning seismic safety into buildings?
Yes! By doing so, they ensure that structures are appropriately designed for the seismic risks they may face.
Summary of Key Concepts
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Before we end, let’s summarize what we have learned about the use of PGA in PBSD. Who can list the performance objectives linked to different PGA levels?
Operational, Life Safety, and Collapse Prevention?
Correct! Can someone recall the specific PGA values tied to those objectives?
0.1g for Operational, 0.2g for Life Safety, and 0.36g for Collapse Prevention.
Excellent! And why is it significant to consider the annual exceedance probabilities in this design?
To understand the likelihood of experiencing that level of shaking during the building's lifespan.
Absolutely! Understanding these relationships helps engineers create safer, more resilient structures. Thanks for participating today!
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
The section discusses how PGA serves as a foundational element in PBSD by establishing performance objectives that correlate to different levels of ground shaking, categorized into operational, life safety, and collapse prevention. Each category corresponds to specific PGA values and associated damage levels.
Detailed
Use of PGA in Performance-Based Seismic Design (PBSD)
Performance-Based Seismic Design (PBSD) is an engineering approach that emphasizes the achievement of specific performance objectives when designing structures for seismic activity. In this context, Peak Ground Acceleration (PGA) is instrumental in defining these objectives, reflecting the expected ground shaking levels during an earthquake. The following performance categories are associated with specific PGA thresholds:
- Operational (PGA ≈ 0.1g): This level represents minor damage, making it conducive for continued use after modest earthquakes.
- Life Safety (PGA ≈ 0.2g): At this threshold, moderate damage can occur, but structures are designed to prevent collapse, ensuring occupant safety.
- Collapse Prevention (PGA ≈ 0.36g and above): This highest category allows for severe damage without total structural failure, prioritizing life safety.
Furthermore, the link between PGA and annual exceedance probabilities is crucial, as PBSD incorporates expected seismic events over time (for example, a 10% chance in 50 years of experiencing a certain level of ground shaking). This section highlights the significance of PGA in formulating performance criteria and ensuring that structures can withstand anticipated seismic activities while maintaining safety and functionality.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Performance Objectives for Ground Shaking Levels
Chapter 1 of 2
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
PBSD requires defining performance objectives for different levels of ground shaking:
- Operational (PGA ≈ 0.1g) – minor damage
- Life Safety (PGA ≈ 0.2g) – moderate damage, no collapse
- Collapse Prevention (PGA ≈ 0.36g and above) – severe damage, no total failure
Detailed Explanation
Performance-Based Seismic Design (PBSD) is a method that focuses on how buildings and structures respond during earthquakes. It revolves around setting clear performance objectives for various levels of ground shaking, categorized by the Peak Ground Acceleration (PGA).
- Operational (PGA ≈ 0.1g): At this level of ground shaking, the building may experience minor damage, such as cosmetic issues like cracks in walls, but it remains functional and safe for use.
- Life Safety (PGA ≈ 0.2g): Here, structures are designed to sustain moderate levels of damage without collapsing. This means while there may be more pronounced damage such as failing non-structural elements, the main structure is safe, and occupants can escape without risk of collapse.
- Collapse Prevention (PGA ≈ 0.36g and above): In these scenarios, the design aims to prevent total failure of the structure even if it suffers severe damage. Such structures are critical as they ensure that those inside are protected from substantial risks of injury or death during strong seismic events.
Examples & Analogies
Imagine a glass jar, which represents a building. At a light tap (Operational level, 0.1g), the jar may shake but remain intact. If someone knocks it harder (Life Safety level, 0.2g), the jar might crack but stay upright. However, if it's hit with great force (Collapse Prevention level, 0.36g), it might shatter but special designs ensure that it won't explode into dangerous sharp fragments, keeping bystanders safe.
Linking PGA to Annual Exceedance Probabilities
Chapter 2 of 2
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
PGA is linked to Annual Exceedance Probabilities in performance criteria (e.g., 10% in 50 years).
Detailed Explanation
The concept of Annual Exceedance Probabilities helps in assessing the risk involved with different levels of seismic activity over time. It quantifies the likelihood of exceeding a certain level of ground shaking measured in PGA.
For instance, if there is a probability of 10% in 50 years, it implies that there is a 10% chance of experiencing an earthquake strong enough to produce a specified PGA within the next 50 years. This understanding helps engineers and city planners to prepare adequately for seismic risks by modifying design projects and establishing safety measures.
Examples & Analogies
Think of it like playing a game of chance where you draw a card. If a specific card represents a strong earthquake, the likelihood of pulling that card out (the probability) helps you decide how to prepare your deck (the building design). If the game lasts long (like 50 years), and your chance of pulling that card is 10%, you know you need to be prepared for it to happen within that time.
Key Concepts
-
PGA: Maximum ground acceleration used to determine structural performance during seismic events.
-
Performance Objectives: Specific goals related to structural safety and damage thresholds predicted for seismic activity.
-
Operational, Life Safety, Collapse Prevention: Categories that define expected performance levels during earthquakes.
Examples & Applications
An operational design for a building might ensure it has a PGA tolerance of 0.1g, allowing for minor damage after small tremors.
A life safety-focused structure would be designed to resist damage associated with a PGA of 0.2g, ensuring that the structure does not collapse.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
PGA is key, it helps us see; how structures stand with the quake's decree!
Stories
Imagine buildings like brave warriors, prepared to meet the shaking earth, each designed for different battles—some for minor skirmishes and others for grand quakes.
Memory Tools
OLC for performance objectives: Operational, Life Safety, Collapse prevention. Remember OLC!
Acronyms
PGA-P
Probability Ground Acceleration – Planning!
Flash Cards
Glossary
- Peak Ground Acceleration (PGA)
The maximum acceleration experienced by the ground during an earthquake.
- PerformanceBased Seismic Design (PBSD)
An engineering approach that focuses on achieving defined performance objectives during seismic events.
- Operational
A performance objective category with minor damage expectations, linked to a PGA of approximately 0.1g.
- Life Safety
A performance objective category aimed at preventing collapse with moderate damage, associated with a PGA of around 0.2g.
- Collapse Prevention
A performance objective category for severe damage without total failure, beginning at a PGA of about 0.36g.
