Quality Assurance in Analytical Techniques
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Surrogates
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let's start by discussing surrogates. Can anyone tell me what a surrogate is?
Isn't a surrogate something we add to a sample to help evaluate our analysis?
Exactly! Surrogates are compounds similar to the analyte we are measuring. They help us understand how well we can recover the analyte during our analysis process.
So if we add a surrogate, we can see how much of it we can recover to check our methods?
Yes, and we use this recovery efficiency to estimate the loss and validate our results. Remember the acronym R.E.C.O.V.E.R. – Recovery Efficiency Confirms Operational Validity of Environmental Results!
That's a great way to remember it! What do we do next after adding the surrogate?
Next, we need to extract it from our sample, using solvents like hexane. This is crucial to isolating our surrogates for analysis.
Extraction Techniques and Concentration
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
After adding our surrogate, we extract it using solvents. What solvent did we discuss specifically?
Hexane, right?
Correct! Hexane is used because it effectively partitioned surrogate compounds. So, after we extract with hexane, what’s our next step?
Do we concentrate the sample?
Yes! Usually, we concentrate the extracted sample to a smaller volume to increase the analyte's detected signal in the instrument. How do we typically achieve concentration?
By using a rotary evaporator or a nitrogen stream, right?
Exactly! Concentration is crucial for enhancing sensitivity when we inject smaller sample volumes into instruments.
Calibration and Recovery Calculations
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now let's move to calibration. Why is calibration important in our analytical methods?
It helps us relate our instrument response to the quantification of the analyte!
Exactly! So when we inject our surrogate and get an instrument response, we need a calibration curve to interpret that response correctly. Can someone explain how we calculate recovery?
We take the mass we recovered and compare it to what we initially added, right?
Great! We can express that in percentage recovery. How do we avoid issues that can arise during this process?
By carefully measuring and documenting every step to catch discrepancies early, I guess.
Correct! Documentation is key to ensuring validity in our analytical results.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
Quality assurance ensures reliable analytical results in environmental monitoring. This section explores surrogate compounds that mimic analytes, the extraction and concentration methods used, and the calculations needed to assess recovery efficiency, ultimately aiding in accurate environmental assessments.
Detailed
Quality Assurance in Analytical Techniques
This section delves into the critical importance of quality assurance (QA) in analytical techniques used for environmental monitoring and analysis. Central to this discussion is the concept of surrogates—compounds that behave similarly to the analyte of interest, facilitating the evaluation of recovery efficiency in analytical processes.
Key Points:
- Surrogate Analysis: Surrogates are spiked into environmental samples to estimate the recovery rates of the target analyte. Their concentration helps calculate how much analyte is likely present in the sample based on recovery percentages.
- Extraction Process: In a practical example, a sample is diluted with hexane, highlighting the importance of selection and retrieval methods. The procedure involves liquid-liquid extraction, emphasizing the significance of achieving separation and proper quantification without contamination from the matrix.
- Concentration Techniques: Concentrating the extracted sample is vital for detecting trace levels of analytes. Various methods are available, including rotary evaporators and inert gas flows, which simplify drown sample sizes making them suitable for analysis.
- Calibration: Calibration plays a pivotal role in analytical methods. A calibration curve allows researchers to relate instrument responses to concentrations of the analyte, ensuring quality and robustness of results.
- Recovery Calculations: Careful calculations for recovery efficiency show the importance of accurately documenting and understanding the losses that occur during the analysis process.
Overall, mastery of these quality assurance practices enhances the credibility of analytical results in environmental analyses.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Understanding Surrogates
Chapter 1 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
So problem C relates to, you have a sample, 1 liter. To this, we are adding 1 ml of 100 milligram solution of a surrogate. ... The surrogate is a compound that is likely to behave like the analyte of interest.
Detailed Explanation
In analytical chemistry, when measuring a specific substance (analyte) in a sample, a surrogate is added to the sample to help evaluate the efficiency of the analysis process. The surrogate behaves similarly to the analyte, allowing researchers to assess how much of the analyte can be recovered during the analytical process. For example, if we are testing for a pollutant in water, we might add a surrogate pollutant that behaves in the same way, helping us understand how much of the real pollutant might be lost during sample processing.
Examples & Analogies
Imagine you're trying to track how much tea you spill when making a cup. If you pour in a known amount of colored water (the surrogate) into your cup where the tea (the analyte) is, you can see how much colored water remains when you're done. This gives you an idea of how much tea might have been lost due to spills or absorption.
Extraction and Concentration Process
Chapter 2 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The sample was extracted with 50 ml of hexane. ... The purpose of our concentration step, what is the objective of this concentration step?
Detailed Explanation
During the extraction process, a solvent (in this case, hexane) is used to separate the analyte and surrogate mixture from the water sample. Once this extraction is complete, the solvent is usually concentrated to increase the analyte's concentration for better detection in subsequent analysis. This step is crucial because it improves the chances of detecting low levels of the analyte in the instrumental analysis, making it more effective. Concentration can be done through evaporation or other techniques to decrease the volume while retaining the target substances.
Examples & Analogies
Think of concentrating orange juice. When you squeeze fresh oranges, you end up with a lot of juice, but it's very watery. If you reduce the water content (concentrate it), you end up with a much more flavorful orange juice. Similarly, concentrating a sample helps to amplify the presence of the target analytes, making them easier to detect.
Calibration and Response Measurement
Chapter 3 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Once you get a response, you need a number; you need a concentration number, for that to get that number we use a calibration.
Detailed Explanation
Calibration is the process of determining the relationship between the instrumental response (like a signal produced by the analyte) and its known concentration. By injecting standard solutions of known concentrations into the instrument and measuring their responses, a calibration curve is created. This allows for the determination of unknown concentrations in samples by comparing their responses to this curve.
Examples & Analogies
Consider a school exam where the grading system is based on correct answers. If 10 correct answers give 90 points and 5 correct answers yield 45 points, students and teachers can create a grading chart (a calibration curve) that predicts the score based on the number of correct answers. Just like students rely on this chart, chemists rely on the calibration curve to figure out how much of a substance is present in a sample.
Understanding Recovery Rates
Chapter 4 of 4
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
So the percentage recovery is 1.67 by 100 is 1.67%, ... This recovery of the surrogate generally is expected to reflect recovery of other analytes that the surrogate represents.
Detailed Explanation
Recovery refers to the percentage of the surrogate or analyte that is retrieved after the extraction and analysis process compared to what was initially added. High recovery rates indicate effective extraction methodology, and the recovery of surrogates can often be extrapolated to predict the recovery rates of other analytes in the same sample. This is essential in evaluating the reliability of the analytical process since it helps in assessing how much of the analyte was lost, ensuring that results are accurate.
Examples & Analogies
Imagine you bake cookies and add chocolate chips. When you take the cookies out of the oven, you find that some chips are missing or left behind. If you started with 100 chips and only found 98 in your cookies, your recovery would be 98%. This percentage indicates how well you 'captured' your chips during baking, similar to how analysts capture their analytes during extraction.
Key Concepts
-
Surrogate: A compound that mimics the analyte for recovery calculations.
-
Extraction: The process of separating the analyte from its matrix.
-
Concentration: A technique for increasing the amount of analyte in a sample.
-
Calibration: The method of relating instrument response to known standards.
-
Recovery Calculations: The assessment of how much analyte was retrieved after analysis.
Examples & Applications
If you add 100 nanograms of a surrogate and recover 80 nanograms, your recovery efficiency would be 80%.
When extracting with hexane, the analyte partitioning will allow you to isolate compounds from an aqueous sample.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Recover and discover, the analyte we seek, surrogates help us, it's knowledge we reap.
Stories
Once there was a scientist named Sam, who used a surrogate named Dan. Together in the lab, they used hexane to detect the pollutants that were a bane. They concentrated until the signal was bright, calibration ensured their findings were right.
Memory Tools
Remember S.E.R.C. - Surrogate, Extraction, Recovery, Calibration.
Acronyms
R.E.C.O.V.E.R. – Recovery Efficiency Confirms Operational Validity of Environmental Results.
Flash Cards
Glossary
- Surrogate
A compound added to an analytical sample to emulate the behavior of the analyte of interest for the purpose of evaluating recovery efficiency.
- Recovery Efficiency
The ratio of the amount of analyte retrieved from a sample compared to what was initially present, typically expressed as a percentage.
- Calibration
The process of setting the relationship between instrument response and known concentrations of standards to ensure accurate measurements.
- Extraction
The process of separating analytes from a matrix using solvents to facilitate analysis.
- Concentration
Reducing the volume of a sample to increase the concentration of analytes, often performed prior to analysis.
