2.3.1. Dredging Techniques

Dredging is used for land reclamation, a lot of dredging, this is non-remedial dredging. Environmental remediation dredging is different because you can see one of the problems in dredging is following.

Dredging is a technique primarily used to remove sediment and debris from the bottom of water bodies. The text mentions two types of dredging: land reclamation and environmental remediation. Land reclamation involves using dredging for the purpose of creating new land from oceans, rivers, or lakes, while environmental remediation dredging is focused on cleaning contaminated sediments. One key concern with dredging is that it can create disturbances in the water, leading to the resuspension of contaminants.

Think of dredging like cleaning a very messy garden pond. When you use a net to scoop out mud and debris, you might stir up the silt and dirt, making the water cloudy. When this happens, any pollution or harmful substances that were stuck to the bottom can mix into the water, similar to dredging stirring up contaminants.

The mechanical regime uses what is called as, this is called the bucket head dredge. It is what you have seen commonly here, it is like a thing it goes in, hooks up, and comes out, it is all mechanical. It retains the solids very effectively.

The bucket head dredge is a type of mechanical dredging equipment that uses a scooping mechanism to grab sediment from the bottom of a water body. It is effective in capturing solid materials, leaving behind water that has been drained out. However, this method is prone to generate a lot of turbidity, meaning it creates murky water due to the stirring up of sediments, which can be harmful to aquatic environments.

Imagine using a big scoop to pick up wet sand from a beach. While you might successfully gather a lot of sand, as you lift it, the water around it gets clouded with sand particles. This is similar to what happens with the bucket head dredge—it’s effective at collecting solids but makes the surrounding water very dirty.

Another option is what is called as a hydraulic dredging, this one. In this, they use some kind of what we call as a screwdriver kind of thing, it is like a drill.

Hydraulic dredging employs a different mechanism, often using a drill-like tool that creates a slurry of sediment and water. Instead of scooping sediment out, it gently stirs and then pumps the resulting mixture out of the water body. This technique reduces turbidity compared to mechanical dredging, meaning less disturbance to the water column, but it creates a slurry that requires separate handling to address the contamination in that slurry.

Consider the difference between using a shovel versus a blender to handle a mixture. If you use a shovel, you might create a mess but get solid chunks. If you use a blender, you create a liquid mix that's easier to handle but also requires you to find a way to deal with the blended contents later. Hydraulic dredging is like using a blender—it’s more gentle but creates new challenges with the slurry.

When you are dredging, chemicals can release into the water okay and we discussed this. Then it can desorb, it can re-suspend and then during resuspension desorption can happen.

Dredging operations can lead to the release of harmful chemicals that were previously trapped in sediments. When sediments are disturbed, these chemicals can re-enter the water column—a process known as desorption. This can harm aquatic ecosystems by increasing the concentration of pollutants in the water, leading to potential negative effects on marine life and water quality.

Think of dredging like mixing a settled jar of salad dressing. When you shake it, the oil and vinegar that separated start to mix back together and spread throughout the jar. In the same way, when dredging disturbs sediments, the previously buried contaminants are stirred up and returned to the water, disrupting the ecosystem.

What happens to dredged material when it leaves a dredging site? So it has to go somewhere, it is not finished, you are just removing it from there and you have to put it somewhere else.

Once dredged material is removed from a water body, it must be properly managed and disposed of—often in confined disposal facilities that work like landfills. This requires careful planning to ensure that potential contaminants do not leach into the environment, meaning that the dredged material can still pose risks to the surrounding areas, including the possibility of evaporation of harmful substances.

Imagine cleaning out your house and putting unwanted items into a storage unit. Just because they are out of sight doesn’t mean the items won't cause issues later if they’re not properly handled. Similarly, dredged materials need to be carefully contained and monitored to prevent contamination from escaping back into the environment.

--
