16.3 - Measurement of Evaporation
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
ISI Standard Pan and Floating Pan
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Building on what we discussed, the ISI Standard Pan is similar to the Class A pan but is modified for specific conditions in India. Why is it important to modify the original design?
Maybe to improve accuracy in local contexts?
Exactly! It's placed within a square enclosure that provides a more natural environment. Now, what about the Floating Pan, can anyone describe it?
The Floating Pan is placed on a water body, which makes it more representative of actual conditions.
Correct again! The Floating Pan significantly improves measurement accuracy because it's affected by the same environmental conditions as the water body itself. Remember these two methods, as they both work to overcome the and increase accuracy in evaporation measurements.
Lysimeter and Atmometer
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let's discuss some of the more specialized instruments now. Who can explain what a lysimeter is and its function?
A lysimeter measures evaporation from the soil and plants, right?
Absolutely! It's critical for understanding water loss in agricultural settings. Now, how about the atmometer?
I think it's also known as an evaporimeter, and it uses a porous surface to measure evaporation.
Spot on! Atmometers gauge evaporation from a wet surface, providing another method to measure water loss. Remember, each of these instruments serves a specific purpose in hydrology.
Summary and Importance of Evaporation Measurement
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
To wrap up, why is it important to measure evaporation accurately?
To manage our water resources better and understand environmental impacts!
Exactly! Each method we discussed plays a role in unlocking different aspects of water management. Can anyone name one method and its key limitation?
The Class A Evaporation Pan, which overestimates evaporation.
Great job! Understanding these methods helps in effective planning for agriculture, water reservoirs, and hydrology studies.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
Understanding how evaporation is measured is crucial for hydrological studies. This section discusses various instruments like the Class A evaporation pan and the lysimeter, their respective purposes, and limitations.
Detailed
Measurement of Evaporation
Evaporation measurement is pivotal in hydrology, allowing for accurate assessments of water loss in various contexts such as agriculture and reservoir management. This section outlines the primary techniques used to measure evaporation: direct and indirect methods. The Class A Evaporation Pan is widely used, consisting of a galvanized iron pan that measures evaporation through changes in water level. However, it tends to overestimate evaporation due to increased exposure. The ISI Standard Pan, common in India, modifies this approach with additional features that mimic natural conditions. The Floating Pan provides a more precise representation by resting on reservoir water surfaces.
Lysimeters are essential for measuring evaporation from soil and plants, crucial for agricultural studies, while Atmometers gauge evaporation from wet porous materials. Understanding these techniques and their limitations is fundamental for conducting accurate hydrological assessments and water resource planning.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Class A Evaporation Pan
Chapter 1 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Evaporation can be measured using direct or indirect methods.
Class A Evaporation Pan
- Standard instrument used in hydrological studies.
- Made of galvanized iron (diameter = 1207 mm, depth = 255 mm).
- Installed in an open area above ground surface.
- Daily evaporation is measured by change in water level.
Limitations:
- Evaporation from a pan is generally more than from a natural water body due to greater exposure and heating.
Detailed Explanation
The Class A Evaporation Pan is a widely recognized tool used to directly measure evaporation rates. It is constructed from galvanized iron, ensuring durability, with specific dimensions designed to standardize measurements across different studies. To utilize this pan, it is set up in a location that allows for unobstructed exposure to environmental conditions. The evaporation rate is determined by measuring changes in the water level within the pan on a daily basis. However, it's important to note that evaporation rates recorded by the pan may be higher than those from natural water bodies, primarily due to increased heat absorption and exposure in the open pan.
Examples & Analogies
Think of the Class A Evaporation Pan as a weather gauge that tells us how much water is 'escaping' into the atmosphere. Similar to how a sponge that is left out in the sun dries out faster than one in a shaded area, the pan is more exposed to heat and wind, which speeds up the evaporation process compared to a natural lake surrounded by trees that provides some shade.
ISI Standard Pan (Modified Class A Pan)
Chapter 2 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
ISI Standard Pan (Modified Class A Pan)
- Used in India; similar to Class A pan but placed within a square enclosure of bricks with grass.
Detailed Explanation
The ISI Standard Pan serves a similar purpose as the Class A pan, but it features modifications that enhance its usability in specific geographical contexts, such as India. It is enclosed within a protective square brick structure and surrounded by grass, which helps to reduce the impact of wind and potential disturbances that could affect evaporation readings. This adaptation improves the accuracy of evaporation measurements by creating conditions that more closely mimic natural environments.
Examples & Analogies
Imagine the ISI Standard Pan as a cozy jar with a lid that keeps warm soup from cooling too quickly. Just like the jar provides insulation, the brick and grass enclosure shields the evaporation pan from extreme weather effects, giving a more controlled environment for measuring how much water is evaporating.
Floating Pan
Chapter 3 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Floating Pan
- Placed directly on the water surface of a reservoir.
- More accurate representation of actual conditions.
Detailed Explanation
The Floating Pan is a specialized measurement tool that is designed to float on the surface of a reservoir's water. This positioning allows it to measure evaporation in conditions that directly reflect the localized environment surrounding the water body. Because it is not affected by the heating and wind exposure that may occur with standard pans, the Floating Pan provides a more accurate measurement of evaporation rates, which is crucial for effective water resource management.
Examples & Analogies
Consider the Floating Pan like a boat bobbing on the water's surface. Just as a boat moves with the waves and reflects the water's conditions, the Floating Pan measures the evaporation as if it were part of the natural reservoir, providing insights that align more closely with real-life circumstances.
Lysimeter
Chapter 4 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Lysimeter
- Measures evaporation from soil and plants (evapotranspiration).
- Used for agricultural and watershed hydrology studies.
Detailed Explanation
A Lysimeter is an instrument used to measure the amount of water lost from soil and plants through evaporation and transpiration (the process of water movement through a plant and its evaporation from aerial parts). It is especially useful in agricultural and hydrology studies, providing valuable information for understanding and managing water usage in cropping systems and watershed areas. By isolating a specific volume of soil and surrounding it with a controlled environment, researchers can accurately assess how much water is lost over a given period.
Examples & Analogies
Think of a Lysimeter as a science experiment in your backyard where you can see how much water a plant drinks each day. Just as you might measure how much lemonade evaporates from a cup left out on a hot day, the Lysimeter collects data on how much moisture plants use from the soil through their leaves, helping farmers know how much water they need to provide for healthy crop growth.
Atmometer
Chapter 5 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Atmometer
- Also called an evaporimeter.
- Measures evaporation from a wet porous surface (porous cup or disc).
Detailed Explanation
The Atmometer, or evaporimeter, is an instrument designed to measure the rate of evaporation from a saturated porous surface. This device functions by allowing water to evaporate through a material like a sponge or disc that simulates the effect of soil or plant leaves. The rate at which water is lost from this porous material provides insights into the surrounding environmental conditions, such as temperature and humidity, making it useful for both agricultural and meteorological applications.
Examples & Analogies
Imagine the Atmometer as a sponge sitting on a windowsill on a warm day. Just like the sponge soaks up water and eventually dries out, the Atmometer helps us track how quickly water evaporates into the air from wet surfaces. By understanding this evaporation rate, we can tell how different weather conditions might affect local water availability.
Key Concepts
-
Evaporation Measurement: Techniques used to determine how much water is lost in the form of vapor from various bodies.
-
Direct Methods: Measurement techniques that assess evaporation directly from water bodies.
-
Indirect Methods: Techniques that estimate evaporation based on various parameters without direct measurement.
Examples & Applications
Class A Evaporation Pan is often utilized across various regions, but adjustments for local conditions improve accuracy.
Lysimeters are commonly employed in agricultural research to gauge crop water needs.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
For measuring water lost, the pans are a must; Class A's not always right, but helps in our quest.
Stories
Imagine a garden with plants thirsty and lean, a lysimeter measures how much water they've seen, while an atmometer watches the raindrops too, capturing every drop that’s vaporized from dew.
Memory Tools
Remember the acronym 'CLEF' for evaporation measurement: Class A Pan, Lysimeter, Evaporimeter (Atmometer), Floating Pan.
Acronyms
Use 'PALS' to recall
for Pan (Class A)
for Atmometer
for Lysimeter and S for the Surface (Floating Pan).
Flash Cards
Glossary
- Class A Evaporation Pan
A standard instrument used to measure evaporation, often overestimating actual evaporation due to its exposure.
- Lysimeter
An instrument that measures evaporation from soil and plants, providing insights into agricultural water loss.
- Atmometer
Also known as an evaporimeter, it's a device that measures evaporation from a wet porous surface.
- Floating Pan
A method of measuring evaporation that floats on a water surface for more accurate readings.
- ISI Standard Pan
A modified version of the Class A Pan used specifically in India for better local accuracy.
