STRESS AND STRAIN
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Stress
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we’ll discuss the concept of stress, which is the restorative force per unit area when a force is applied to a solid body. Does anyone know how we can calculate stress?
Isn't it something like force divided by area?
Exactly! The formula for stress is σ = F/A, where F is the applied force and A is the cross-sectional area. Remember, the unit of stress is Pascal (Pa), which is equivalent to N/m².
What happens when we apply that force?
Good question! When a force is applied, it can cause deformation, which brings us to the next concept — strain.
Let's summarize: Stress is defined as force per area, and its unit is Pascal. Now, let's dive into strain.
Understanding Strain
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Strain is defined as the ratio of change in dimension to the original dimension. Who can tell me the formula for longitudinal strain?
It's ΔL over L, right? Where ΔL is the change in length?
Correct! Longitudinal strain is indeed ΔL/L. There are also other types of strain like shearing strain and volumetric strain. Can anyone tell me what shearing strain relates to?
Is it related to how much one part of the material slides over another part?
Yes! That’s right! Shearing strain is defined as the ratio of the displacement (Δx) between two sections to the original length (L). Great job!
To recap: Strain is ΔL/L for longitudinal strain, and there are also shearing and volumetric strains based on the types of forces applied.
Application of Stress and Strain in Engineering
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now, let's talk about how stress and strain apply in engineering and real-world applications. Why do you think understanding these concepts is essential when designing buildings or bridges?
Because if we don't consider stress and strain, the structures could fail, right?
Exactly! Engineers must ensure the materials used can withstand the stress without exceeding their elastic limits. Do you remember the different types of stress?
Tensile, compressive, and shearing stress!
Correct! Each type of stress affects the materials differently, and knowing these helps in making informed design decisions. For example, a bridge must be designed to handle not only the weight of vehicles but also any lateral forces from the wind.
To summarize, stress and strain are crucial for safety and efficiency in engineering, and understanding their various forms is key to successful design.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
The section introduces the concepts of stress as a restoring force per unit area and strain as the ratio of change in dimension to the original dimension. It categorizes stress into tensile, compressive, and shearing, while highlighting the relevance of these concepts in engineering and design.
Detailed
Stress and Strain
In mechanics, when external forces are applied to a body at static equilibrium, they lead to deformations, either noticeable or otherwise. This section explains two foundational concepts: stress and strain.
- Stress is defined as the restoring force generated in an object per unit area and can be calculated using the formula:
Stress (σ) = F/A
where F is the applied force and A is the cross-sectional area. The unit of stress is Pascal (Pa).
- Strain, on the other hand, refers to the deformation of an object relative to its original dimensions, expressed as the ratio of change in dimension to the original dimension. The type of strain varies by the kind of stress applied:
- Longitudinal Strain (s = ∆L/L): Caused by tensile or compressive stress.
- Shearing Strain (∆x/L = tanθ): Resulting from tangential forces while the object remains parallel between two sections.
- Volumetric Strain (∆V/V): Occurs due to uniform pressure applied to a solid, resulting in a change in volume without altering its shape.
Additionally, the section exemplifies stress and strain applications, emphasizing their significance in engineering and everyday structures, like buildings and bridges.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Definition of Stress
Chapter 1 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
When forces are applied on a body in such a manner that the body is still in static equilibrium, it is deformed to a small or large extent depending upon the nature of the material of the body and the magnitude of the deforming force. The restoring force per unit area is known as stress.
Detailed Explanation
When a solid object is subjected to an external force, it undergoes deformation. This deformation is countered by an internal restoring force exerted by the material, which tries to return the object to its original shape. Stress is defined as this restoring force per unit area. Thus, if we have a force (F) acting on a surface with an area (A), the stress (σ) can be calculated using the formula σ = F/A. The SI unit of stress is pascal (Pa), which is equivalent to N/m².
Examples & Analogies
Think of stress as how hard you press down with your finger on a soft sponge. The harder you press (increased force), the more the surface of the sponge deforms (more stress applied). If you stop pressing, the sponge wants to return to its original shape, similar to how materials behave under applied stress.
Types of Stress
Chapter 2 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
There are three ways in which a solid may change its dimensions when an external force acts on it. These are: tensile stress, compressive stress, and shear stress.
Detailed Explanation
When an external force is applied to a solid, it can experience different types of stress based on the direction of that force. Tensile stress occurs when forces are applied to stretch the material (like pulling a rubber band). Compressive stress happens when forces push the material, causing it to compress (like pressing down on a sponge). Shear stress is observed when forces are applied parallel to the surface, causing layers of the material to slide over each other (imagine sliding one deck of cards over another).
Examples & Analogies
Visualize a piece of clay. If you pull on it from opposite ends, you're applying tensile stress. If you push the clay down, you're applying compressive stress. If you press down on one side of the clay while keeping the other side steady, you're applying shear stress, causing the clay to distort.
Strain and Its Relation to Stress
Chapter 3 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The change in length ΔL to the original length L of the body is called longitudinal strain. Longitudinal strain is defined as ΔL/L.
Detailed Explanation
Strain is a measure of how much deformation a material undergoes in response to an applied stress. For longitudinal strain, it quantifies the change in length (ΔL) of a material compared to its original length (L). The formula for longitudinal strain is expressed as ε = ΔL / L, which is a dimensionless quantity since it’s a ratio of lengths.
Examples & Analogies
Consider stretching a rubber band. If you pull it from its original length of 10 cm to a new length of 12 cm, the change in length (ΔL) is 2 cm. The strain would be 2 cm / 10 cm = 0.2 or 20%. This indicates how much the band has deformed relative to its original size.
Shearing Stress and Strain
Chapter 4 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
When two equal and opposite deforming forces are applied parallel to the cross-sectional area of the cylinder, there is a relative displacement ∆x between opposite faces of the cylinder. The strain is known as shearing strain and is defined as the ratio of relative displacement of the faces ∆x to the length of the cylinder L.
Detailed Explanation
When forces are applied parallel to a surface, the material experiences shear stress that causes layers to slide over one another. The resulting displacement (∆x) between two faces of the object divided by the length (L) gives us shearing strain. This can be expressed as γ = ∆x / L, which typically involves small angles where the tangent can be approximated as equal to the angle in radians.
Examples & Analogies
Imagine a thick book lying flat on a table. If you push the top of the book sideways while keeping the bottom fixed, the top slides over the bottom, creating an angle with respect to the vertical. This sliding motion is similar to shear deformation, where the book's layers experience shearing stress.
Hydraulic Compression
Chapter 5 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
In this scenario, a solid sphere placed in the fluid under high pressure is compressed uniformly on all sides. The force applied by the fluid acts in a perpendicular direction at each point of the surface, leading to a decrease in its volume without any change of its geometrical shape.
Detailed Explanation
Hydraulic compression occurs when a fluid exerts pressure evenly across the surface of an object. This results in volume strain expressed as the ratio of the change in volume (ΔV) to the original volume (V). The internal restoring forces counteract this pressure, allowing the material to potentially return to its original state when the pressure is released.
Examples & Analogies
Think about a sponge submerged in water under pressure. The water compresses the sponge equally from all sides. Even though the sponge gets smaller in size, its shape remains consistent until the pressure is released, at which point the sponge can restore itself.
Key Concepts
-
Stress: The force per unit area causing deformation in a solid.
-
Strain: The measure of deformation representing the displacement between particles in a material.
-
Tensile Stress: Stress that occurs when a material is pulled or stretched.
-
Compressive Stress: Stress that occurs when a material is compressed or squished.
-
Shearing Stress: Stress that occurs when forces cause different parts of a material to move in parallel.
-
Hydraulic Stress: Stress that results from pressure exerted by a surrounding fluid.
-
Longitudinal Strain: Change in length compared to the original length due to applied force.
-
Shearing Strain: The displacement of layers relative to each other due to shear force.
-
Volume Strain: Change in volume relative to the original volume.
Examples & Applications
A rubber band stretched by a force demonstrates tensile stress, with the elongation being the strain.
When pressing a deck of cards sideways, the relative sliding shows shearing stress.
When a balloon is inflated, the external air pressure causes hydraulic stress on the skin of the balloon, leading to volume strain.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Stress is a force, per area it shows,
Stories
Imagine a brave rope, stretched tight in a tug-of-war game.
Memory Tools
Remember 'S' for Stress and 'S' for Shear - both involve forces that persevere.
Acronyms
Use the acronym 'SST' for Stress types
Tension
Shear
and Compression.
Flash Cards
Glossary
- Stress
The restoring force per unit area when an external force is applied to a solid.
- Strain
The ratio of change in dimension to its original dimension due to applied stress.
- Tensile Stress
Stress created by a force that tends to stretch or elongate a material.
- Compressive Stress
Stress that results from forces that tend to compress or shorten a material.
- Shearing Stress
Stress resulting from applied forces that slide one part of a material parallel to another.
- Hydraulic Stress
Stress exerted on an object submerged in a fluid, applying pressure at all points.
- Longitudinal Strain
Strain due to change in length, calculated as the change in length divided by the original length.
- Shearing Strain
Strain that occurs when forces cause two adjacent parts of a material to slide relative to one another.
- Volume Strain
Strain that involves a change in volume relative to the original volume.
