6.1 - Dispersion of Light
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Dispersion
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Good morning, everyone! Today we're discussing a fascinating phenomenon called dispersion. Can anyone tell me what dispersion means?
Is it when something spreads out or separates?
Exactly! Dispersion refers to the splitting of white light into its constituent colors. This occurs when light passes through a prism. Can someone name the colors that result from this process?
I remember! It’s VIBGYOR — Violet, Indigo, Blue, Green, Yellow, Orange, and Red!
Right! The acronym VIBGYOR helps us remember those colors easily. Now, why do you think the colors separate when passing through the prism?
Is it because they bend differently?
Precisely! Different colors have different wavelengths and thus bend at different angles during refraction. Let’s explore that next!
Understanding the Visible Spectrum
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now that we've covered the colors of the spectrum, let's talk about what the visible spectrum is. How do you think the wavelengths of these colors compare?
I think they range from violet to red, right?
Exactly! The wavelengths range from about 400 nm for violet to 700 nm for red. This difference in wavelengths is why they refract differently. Who can summarize why violet bends the most?
Violet light has a shorter wavelength and, thus, a higher speed in the medium.
Great job! The refractive index varies for each color due to their different wavelengths. We’ll see how this knowledge was explored in Newton’s experiment next.
Newton's Experiment and Recombination
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Sir Isaac Newton conducted a pivotal experiment with light and prisms in the 17th century. What do you think he discovered?
He found out that white light is made up of various colors!
Exactly. He showed that when the colors were passed through a second prism, they recombined to form white light. Does anyone know why this recombination is important?
It shows that white light includes all colors!
Yes! This experiment was crucial for understanding the nature of light. Let’s summarize what we learned about dispersion today.
We learned that dispersion occurs in prisms, and colors bend differently based on wavelength!
Well done! Remember, dispersion leads to the beautiful spectrum we see in phenomena like rainbows too!
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
The dispersion of light occurs when white light passes through a prism, resulting in the separation of light into seven distinct colors: Violet, Indigo, Blue, Green, Yellow, Orange, and Red (VIBGYOR). This phenomenon is due to varying degrees of bending (refraction) of different wavelengths of light.
Detailed
Dispersion of Light
Dispersion is the process through which white light is split into its constituent colors when passed through a transparent medium such as a prism. This effect occurs because different colors, or wavelengths of light, travel at different speeds in various media, thus bending (refracting) at distinct angles. The seven colors produced can be remembered using the acronym VIBGYOR, which stands for:
- Violet
- Indigo
- Blue
- Green
- Yellow
- Orange
- Red
The visible spectrum covers wavelengths from approximately 400 nm (violet) to 700 nm (red), with violet light bending the most and red bending the least. This unique dispersion phenomenon serves as a fundamental principle in understanding light behavior, laying the groundwork for various scientific applications and artistic interpretations, such as rainbows and color mixing.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Definition of Dispersion
Chapter 1 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
● Dispersion is the phenomenon of splitting white light into its seven constituent colors when it passes through a prism.
Detailed Explanation
Dispersion refers to the process where white light is separated into several distinct colors as it travels through a prism. This occurs primarily due to the different speeds at which different colors travel in the prism material, causing them to bend at varying angles.
Examples & Analogies
Think of dispersion like a group of friends walking through a narrow door at a party. Depending on their size, some friends might squeeze through faster while others take a little longer. By the time they exit, they're spread out into different positions, similar to how light colors spread out after passing through a prism.
The Seven Colors of VIBGYOR
Chapter 2 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
● The seven colors are Violet, Indigo, Blue, Green, Yellow, Orange, Red (VIBGYOR).
Detailed Explanation
The acronym VIBGYOR stands for the seven base colors that white light separates into during dispersion. These colors, in the order of their appearance, are Violet, Indigo, Blue, Green, Yellow, Orange, and Red. Each of these colors has a distinctive wavelength and plays a role in the visible spectrum.
Examples & Analogies
You can visualize these colors as a rainbow. Just like how rainbows appear in the sky comprised of these specific colors after rain, dispersion creates a similar color band when light passes through a prism.
Refraction and Bending of Light
Chapter 3 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
● This happens because different colors bend at different angles during refraction.
Detailed Explanation
Refraction is the bending of light as it passes from one medium to another. When white light enters a prism, each color within the light spectrum travels at a different speed in the prism material (like glass). As a result, they bend at different angles. Higher frequency colors like violet bend more than lower frequency colors like red, which leads to the creation of a spectrum.
Examples & Analogies
Imagine a group of people walking from a smooth pavement onto a muddy field. Some people might struggle more and slow down, causing them to scatter at different angles as they walk onto the field. Similarly, different colors of light slow down and bend differently when they enter the prism.
Key Concepts
-
Dispersion: The splitting of white light into its constituent colors when passed through a prism.
-
Spectrum: The band of colors produced by the dispersion of light, represented by VIBGYOR.
-
Refraction: The bending of light that causes different colors to separate based on their wavelengths.
Examples & Applications
When white light passes through a prism, it separates into the colors of the rainbow.
Creating a rainbow after rain involves dispersion of sunlight through water droplets.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Prism shining bright, bending the light, colors of the rainbow take flight!
Stories
Once upon a time, a little beam of light moved through a magical prism, splitting into seven colorful friends who danced in the sky as a rainbow.
Memory Tools
VIBGYOR: Very Intelligent Boys Go Yonder Observing Rainbows.
Acronyms
VIBGYOR stands for Violet, Indigo, Blue, Green, Yellow, Orange, and Red.
Flash Cards
Glossary
- Dispersion
The phenomenon of splitting white light into its constituent colors when it passes through a prism.
- Spectrum
The band of colors produced due to the dispersion of white light.
- Refraction
The bending of light as it passes from one medium into another.
- Wavelength
The distance between successive crests of a wave, commonly used to characterize different colors of light.
- Refractive Index
A measure of how much the speed of light is reduced inside a medium compared to its speed in a vacuum.
