6.7 - Minimum Front Open Space to be Provided
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Importance of Front Open Space
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Front open space is essential for a building's design. Can anyone tell me why it's important?
It helps with ventilation and natural light, right?
Exactly! Adequate ventilation and light improve the living conditions. Another benefit is accessibility. What do you think we should consider for different street widths?
Maybe the amount of space we need to leave in front?
Correct! The space correlates with the street width. For instance, if the street is up to 7.5 meters, the front open space must be at least 1.5 meters. Can anyone repeat this rule for the next width?
For 7.5 to 18 meters, it should be 3 meters.
Good job! Let's summarize what we've learned today about front open space.
Remember, front open space is vital for ventilation and aesthetics, and it must increase with street width.
Measurement Guidelines
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now let’s dive into the exact measurements based on street width. What should we provide for a street width over 30 meters?
It should be 6 meters of open space!
Exactly right! And what do we do for streets between 18 and 30 meters?
4.5 meters!
Perfect! By understanding these requirements, we can create better building designs. Who can summarize this again?
As the street width increases, the front open space needs to increase too. Like, it goes 1.5m, 3m, 4.5m, and 6m.
That's spot on! Remembering these rules helps us adhere to building codes effectively.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
The section elaborates on the minimum front open space to be provided in building designs, correlating with the width of the street in front of the building. It details the specific measurements needed, which are essential for ensuring proper ventilation and accessibility in urban planning.
Detailed
Minimum Front Open Space to be Provided
In building planning, adequate front open space is crucial for ensuring both aesthetic appeal and functional requirements. The amount of front open space needed directly correlates with the width of the street in front of the plot.
- Width of Street and Required Front Open Space:
- For streets up to 7.5 meters, a minimum front open space of 1.5 meters must be provided.
- For streets ranging from 7.5 to 18 meters, a minimum of 3.0 meters is necessary.
- If the street width is between 18 and 30 meters, the space increases to 4.5 meters.
- For streets wider than 30 meters, the required space is 6.0 meters.
Providing adequate front open space enhances the overall urban environment, contributing to circulation, accessibility, and aesthetic values while complying with the National Building Code of India.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Minimum Front Open Space Guidelines
Chapter 1 of 2
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Width of street in front of plot in m
- Up to 7.5m: 1.5m
- 7.5 to 18: 3.0m
- 18 to 30: 4.5m
- Above 30: 6.0m
Detailed Explanation
This chunk outlines the minimum front open space requirements based on the width of the street in front of a plot. If the street is up to 7.5 meters wide, the minimum open space in front of the building should be 1.5 meters. For streets wider than 7.5 meters but up to 18 meters, the space increases to 3 meters. For streets between 18 and 30 meters, the requirement is 4.5 meters, and for streets wider than 30 meters, the minimum required space is 6 meters. This regulation ensures that buildings have enough space from the street, which can contribute to aesthetics, building safety, and accessibility.
Examples & Analogies
Imagine a cozy neighborhood. If the streets are narrow, like 7 meters wide, houses can be closer together, so a smaller front space like 1.5 meters is acceptable. But if you drive down a wider street, say 30 meters, it's more open and spacious, hence houses need a larger space of 6 meters to maintain that comfortable feeling of distance and safety from the road.
Importance of Front Open Space
Chapter 2 of 2
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The front open space is essential for several reasons.
Detailed Explanation
Having adequate front open space is important for several reasons. It allows for better air circulation and lighting for the building, contributing to a healthier living environment. Moreover, this space is crucial for the aesthetic appeal of the area, as it can contribute to the overall appearance and feel of the neighborhood. It also plays a safety role, as it provides buffer space between the road and the building, protecting residents and reducing noise pollution from the street.
Examples & Analogies
Think of the front open space like a buffer zone in a park. Just as trees and bushes along the paths create a peaceful atmosphere away from the busy streets, the front open space around buildings offers a similar comfort and safety to residents, making their homes feel like sanctuaries from outside activity.
Key Concepts
-
Front Open Space: Necessary unconstructed area in front of a building for adequate ventilation and light.
-
Street Width: The measurement which affects the required front open space; wider streets need larger open spaces.
Examples & Applications
If a plot is located on a street that is 10 meters wide, then a minimum front open space of 3 meters must be provided.
For a street wider than 18 meters, such as 25 meters, the developer must ensure a front open space of at least 4.5 meters.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
For streets up to 7.5, keep 1.5 to keep it alive.
Stories
Imagine a busy street with buildings. When it’s too crowded, if they all have enough open space, the breeze can flow and light can enter, making all happier and healthy.
Memory Tools
Remember: 1.5, 3, 4.5, and 6 (from 7.5m to over 30m) to find the front space you need to fix.
Acronyms
FOS (Front Open Space) correlates with Street Width.
Flash Cards
Glossary
- Front Open Space
The unconstructed area in front of a building, which is essential for airflow, light, and aesthetics.
- Street Width
The measurement of the street's width that determines the required front open space for adjacent plots.
