7.6.1 - Phasor-diagram solution

Interactive Audio Lesson

Listen to a student-teacher conversation explaining the topic in a relatable way.

Introduction to Phasors

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Today, we will learn about phasors and how they help us analyze AC circuits effectively. Can anyone tell me what a phasor is?

Student 1
Student 1

Is it a vector that shows the magnitude and phase of an AC quantity?

Teacher
Teacher

Exactly! A phasor is a rotating vector that represents sinusoidally varying quantities. It's crucial for understanding the relationships between current and voltage in circuits.

Student 2
Student 2

Why do we need phasors instead of just looking at the waveforms?

Teacher
Teacher

Great question! Phasors simplify the equations and relationships by converting them into a form that can be easily manipulated mathematically.

Phase Relationships in Series RLC Circuit

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

In a series RLC circuit, we have voltage across a resistor, inductor, and capacitor. Let's draw the phasor diagram together. Who can tell me the relationship between these voltages?

Student 3
Student 3

I think the voltage across the resistor is in phase with the current.

Student 4
Student 4

And the voltage across the inductor lags the current by 90 degrees!

Teacher
Teacher

Correct! And the voltage across the capacitor leads the current by the same angle. These relationships are crucial to understanding how the circuit functions.

Student 1
Student 1

How do these phase differences affect the overall current in the circuit?

Teacher
Teacher

Great follow-up! The phasor diagram shows us how to combine these voltages to find the total voltage and thus the impedance of the circuit.

Understanding Impedance

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Let's talk about impedance, which is the total opposition to current in an AC circuit. Does anyone know how we calculate it?

Student 2
Student 2

Is it something like the resistance plus reactance?

Teacher
Teacher

Exactly! Impedance combines both resistance and reactance. We define it mathematically as Z = √(R² + (X_L - X_C)²).

Student 3
Student 3

So, it’s similar to the Pythagorean theorem?

Teacher
Teacher

Spot on! This relationship helps us analyze the circuit's behavior under different frequencies and shows us how to find the total current.

Calculating the Phase Angle

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Now, let's discuss how to calculate the phase angle. Who remembers the equation for it?

Student 4
Student 4

Is it tan(φ) = (X_L - X_C)/R?

Teacher
Teacher

That's correct! This equation tells us how the reactance of the inductor and capacitor affects the phase relation with resistance. Why is this significant?

Student 1
Student 1

It shows whether the current leads or lags the voltage?

Teacher
Teacher

Exactly! Understanding the phase angle is crucial for AC circuit analysis and helps you design more efficient systems.

Summary and Recap

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Today we've learned about phasors, the phase relationships between currents and voltages in AC circuits, how to calculate impedance, and the importance of phase angles. Can anyone summarize what they learned?

Student 2
Student 2

Phasors help visualize the relationships between different voltages and current in an AC circuit, and we can use them to calculate impedance!

Student 3
Student 3

And we also learned how the phase angle can tell us whether the current leads or lags the voltage.

Teacher
Teacher

Exactly! Remember, a solid understanding of these concepts enables you to tackle more complex AC circuit problems in the future.

Introduction & Overview

Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.

Quick Overview

This section explains the use of phasors in analyzing the current and voltage relationships in AC circuits, particularly within a series RLC circuit.

Standard

It explores how phasors represent the alternating current and voltages in a series RLC circuit, demonstrates how to construct phasor diagrams, and introduces key concepts like impedance and phase angles to understand the behavior of such circuits.

Detailed

Detailed Summary

In this section on phasor-diagram solutions for AC circuits, we explore how phasors can simplify the analysis of current and voltage relationships in a series RLC circuit. Each component, including resistors, inductors, and capacitors, reacts differently to alternating current, leading to phase differences that are crucial for circuit analysis.

Key Concepts Explained

  1. Phasors: A phasor is a rotating vector that represents sinusoidally varying quantities in an AC circuit. The angle of rotation corresponds to the phase of the sinusoid.
  2. Phase Relationships: In a series RLC circuit, the phasor diagram illustrates the relationships between the voltage across the inductor, the resistor, the capacitor, and the source voltage. The current phasor is in phase with the voltage across the resistor, while it lags behind the voltage across the inductor and leads ahead of that across the capacitor.
  3. Impedance: The total opposition to current flow in the AC circuit is called impedance (Z), which combines resistance (R) and reactance from the inductor (
    X_L) and capacitor (
    X_C):
    Z =
    √(R² + (X_L - X_C)²)
  4. Phase Angle: The phase angle (
    φ) between the current and voltage can be determined from the relationships of the voltages across these elements, given by:
    tan(φ) = (X_L - X_C)/R

By constructing the phasor diagram, we can tap into these relationships to understand how current behaves in an alternating current setup, thus laying foundations for advanced AC circuit analysis. This simplification helps highlight how circuits respond to changing conditions, making phasors a powerful tool for electrical engineers.

Youtube Videos

Phasor diagram (& its applications) | Alternating currents | Physics | Khan Academy
Phasor diagram (& its applications) | Alternating currents | Physics | Khan Academy
Alternating Current Class 12 Physics Chapter 7 One Shot | New NCERT syllabus CBSE | Full chapter
Alternating Current Class 12 Physics Chapter 7 One Shot | New NCERT syllabus CBSE | Full chapter
AC circuit containing Resistor | Alternating Current |waveform & Phasor diagram | 12 Physics #cbse
AC circuit containing Resistor | Alternating Current |waveform & Phasor diagram | 12 Physics #cbse
Phasor and phasor diagram // Class 12 Physics // Chapter 7 Alternating current
Phasor and phasor diagram // Class 12 Physics // Chapter 7 Alternating current
Alternating Current Class 12 Physics | NCERT Chapter 7 | CBSE NEET JEE | One Shot
Alternating Current Class 12 Physics | NCERT Chapter 7 | CBSE NEET JEE | One Shot
Alternating Current Class 12 | Chapter 7 | Physics | Part 1 | 2022-23
Alternating Current Class 12 | Chapter 7 | Physics | Part 1 | 2022-23
12th class physics chapter 6 EMI electromagnetic induction in 10 minutes one shot revision PW ....
12th class physics chapter 6 EMI electromagnetic induction in 10 minutes one shot revision PW ....
Class 12 |7.6: Phasors and Phasor diagram ( Argand diagram )
Class 12 |7.6: Phasors and Phasor diagram ( Argand diagram )
Half wave rectifier | semiconductor | 12th physics | #physics #animation #semiconductor
Half wave rectifier | semiconductor | 12th physics | #physics #animation #semiconductor
Alternating Current04: Phasor Diagram, Phase in Ac, Phase difference in Ac by Abhishek sahu
Alternating Current04: Phasor Diagram, Phase in Ac, Phase difference in Ac by Abhishek sahu

Audio Book

Dive deep into the subject with an immersive audiobook experience.

Phasor Representation of Circuit Elements

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

From the circuit shown in Fig. 7.10, we see that the resistor, inductor and capacitor are in series. Therefore, the ac current in each element is the same at any time, having the same amplitude and phase. Let it be i = i sin(wt + f) (7.21) where f is the phase difference between the voltage across the source and the current in the circuit.

Detailed Explanation

In a series circuit containing a resistor, inductor, and capacitor, the current flowing through each component is the same, meaning that all three share the same amplitude and phase. We can express this current in a phasor format, which allows us to include a phase difference (denoted as 'f') relative to the source voltage. The use of phasors simplifies the analysis of alternating current circuits by representing sinusoidal functions as rotating vectors.

Examples & Analogies

Think of a group of friends at a party (the current) moving together in the same direction (through the resistive, inductive, and capacitive components) at the same speed (current flow). Occasionally, one friend might move ahead or lag behind slightly (the phase difference), but overall, they are in sync.

Constructing a Phasor Diagram

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

On the basis of what we have learnt in the previous sections, we shall construct a phasor diagram for the present case. Let I be the phasor representing the current in the circuit as given by Eq. (7.21). Further, let V, V , V, and V represent the voltage across the inductor, resistor, capacitor and the source, respectively. From previous section, we know that V is parallel to I, V is p/2 behind I and V is p/2 ahead of I.

Detailed Explanation

By constructing a phasor diagram, we represent the voltages across the circuit elements: the resistor (VR), the inductor (VL), and the capacitor (VC), along with the total voltage (V). The current phasor (I) is used as a reference, and the relationships between them include the fact that VL leads the current by 90 degrees (π/2) while VC lags the current by 90 degrees. This visualization helps us see how different voltage and current components interact in a circuit.

Examples & Analogies

Imagine a tug-of-war game with a rope: the team that's pulling the hardest (current) is the reference. The two opposing teams (voltage across the inductor and the capacitor) pull at angles. The team pulling forward (inductor) and the one resting (capacitor) will show how they influence the outcome of the game (the total voltage). This is how we visualize the dynamics of voltage and current in AC circuits with a phasor diagram.

Relationship Between Phasors

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

The length of these phasors or the amplitude of V , V and V are: R, C, L v = i R, v = i X ,v =i X (7.22) Rm m Cm m Lm m

Detailed Explanation

In the phasor diagram, each voltage phasor's length is proportional to the current flowing through the circuit multiplied by the respective resistance or reactance of the components. For the resistor, the voltage is simply the current multiplied by the resistance (Ohm's Law). The reactance for the inductor (XL) and the capacitor (XC) defines how much they oppose current change in their respective ways.

Examples & Analogies

Consider a water pipe system: the resistance (R) is like the narrowing of the pipe (the water flow resistance), while the reactances (XL and XC) can be considered as the flexible pipes that can either expand or contract based on how much water is flowing. Each segment directly affects how much water can flow through the system at any given time.

Voltage Equation for the Circuit

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

The voltage Equation (7.20) for the circuit can be written as v + v + v = v L R C

Detailed Explanation

This equation states that the total voltage (V) supplied to the circuit is equal to the sum of the voltages across each component. It reflects Kirchhoff’s voltage law, where all voltages in a closed loop must add up to zero. This relationship is crucial for analyzing and solving circuits with multiple components.

Examples & Analogies

Think of it like a team project: the total effort (voltage) is equal to the sum of contributions (individual voltages) from each team member (resistor, inductor, capacitor). Just as each person's input is necessary to complete the project, each voltage adds up to meet the overall supply.

Phasor Relationships and Impedance

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Substituting the values of v , v , and v from Eq. (7.22) into the above equation, we have v2 =(i R)2 +(i X - i X )2. By analogy to the resistance in a circuit, we introduce the impedance Z in an ac circuit.

Detailed Explanation

By applying the Pythagorean theorem, we relate the total voltage to the resistance and reactances in the circuit, forming an impedance triangle. Impedance (Z) combines resistance (R) and the net reactance (the difference between inductive and capacitive reactance) into a single value that describes how much the circuit resists the flow of AC current.

Examples & Analogies

If we visualize the circuit's impedance as the total thickness of a layered wall, each material (resistor, inductor, capacitor) contributes to the wall's overall thickness. The thicker the wall, the harder it is for the water (current) to push through, just like how higher impedance restricts current flow.

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Phasors: A phasor is a rotating vector that represents sinusoidally varying quantities in an AC circuit. The angle of rotation corresponds to the phase of the sinusoid.

  • Phase Relationships: In a series RLC circuit, the phasor diagram illustrates the relationships between the voltage across the inductor, the resistor, the capacitor, and the source voltage. The current phasor is in phase with the voltage across the resistor, while it lags behind the voltage across the inductor and leads ahead of that across the capacitor.

  • Impedance: The total opposition to current flow in the AC circuit is called impedance (Z), which combines resistance (R) and reactance from the inductor (

  • X_L) and capacitor (

  • X_C):

  • Z =

  • √(R² + (X_L - X_C)²)

  • Phase Angle: The phase angle (

  • φ) between the current and voltage can be determined from the relationships of the voltages across these elements, given by:

  • tan(φ) = (X_L - X_C)/R

  • By constructing the phasor diagram, we can tap into these relationships to understand how current behaves in an alternating current setup, thus laying foundations for advanced AC circuit analysis. This simplification helps highlight how circuits respond to changing conditions, making phasors a powerful tool for electrical engineers.

Examples & Real-Life Applications

See how the concepts apply in real-world scenarios to understand their practical implications.

Examples

  • In a series RLC circuit, if we apply a voltage of 220 V, we can determine the current and its phase using the impedance calculated from the individual R, L, and C values.

  • For an inductor with a reactance of 8 ohms and a resistor of 4 ohms, the total impedance can be calculated and the phase angle can then be derived.

Memory Aids

Use mnemonics, acronyms, or visual cues to help remember key information more easily.

🎵 Rhymes Time

  • Phasors spin like the clock, watch them tick, currents and voltages, they paint the trick.

📖 Fascinating Stories

  • Imagine a dancer (phasor) moving in a circle, showing different poses (voltages) while spinning at a constant speed (frequency).

🧠 Other Memory Gems

  • Remember: 'Z for Zero Lag!' - Impedance helps show us how much we lag behind!

🎯 Super Acronyms

P.V.R.C. - Phasors, Voltage, Reactance, Current are the keys to solving AC circuits.

Flash Cards

Review key concepts with flashcards.

Glossary of Terms

Review the Definitions for terms.

  • Term: Phasor

    Definition:

    A rotating vector that represents sinusoidally varying quantities in AC circuits.

  • Term: Impedance

    Definition:

    The total opposition to current flow in AC circuits, combining resistance and reactance.

  • Term: Reactance

    Definition:

    The opposition to current flow caused by inductors and capacitors in AC circuits.

  • Term: Phase Angle

    Definition:

    The angle that indicates the phase difference between the current and voltage.
