Instantaneous Power in AC Circuits

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

We have seen that a voltage v = v sinwt applied to a series RLC circuit drives a current in the circuit given by i = i sin(wt + φ) where v \(= \frac{X_L - X_C}{R}\) and φ = tan^(-1) \(\frac{X_L - X_C}{R}\).

Therefore, the instantaneous power p supplied by the source is
\[
p = vi = v \sin(wt) \, i \sin(wt + φ)\]
\[= \frac{1}{2} v i \cos φ - \frac{1}{2} v i \cos(2wt + φ)\].

Detailed Explanation

In an AC circuit with a series RLC configuration, when we apply an alternating voltage, it drives a current which is out of phase with the voltage by an angle (φ). The instantaneous power 'p' at any time is calculated by multiplying the voltage by the current at that time. In this formula, the first term represents real power and the second term represents reactive power, which averages to zero over a complete cycle.

Examples & Analogies

Think of switching on a blender. When you first turn it on, the motor may pull in a lot of current (draws power) to get going (initial push). Over time, as it steadily blends, it uses less energy efficiently compared to when it starts. Similarly, in AC circuits, there are moments of low and high energy usage as the voltage and current oscillate.

Average Power in AC Circuits

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

The average power over a cycle is given by the average of the two terms in R.H.S. of Eq. (7.29). It is only the second term which is time-dependent. Its average is zero (the positive half of the cosine cancels the negative half). Therefore,
\[
P = \frac{1}{2} v \cdot i \cdot \cos φ = \frac{V I \cos φ}{2}\].

Detailed Explanation

The average power (P) dissipated in an AC circuit can be calculated by considering only the cosine component of the power equation. This is because over a complete cycle, certain components, like the reactive component, average out to zero. The power factor, represented as cos(φ), tells us how much of the power is actually being used versus how much is just 'apparent' power.

Examples & Analogies

Imagine you have a car that runs at different speeds due to road conditions. The average speed can be thought of as the effective speed that allows you to get from point A to B. Similar to how your effective speed accounts for stop signs and traffic, the power factor accounts for how effectively the AC system uses power.

Power Factor in Different Circuit Types

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

So, the average power dissipated depends not only on the voltage and current but also on the cosine of the phase angle φ between them. The quantity cos φ is called the power factor.

Let us discuss the following cases:
1. Resistive circuit: If the circuit contains only pure R, it is called resistive. In that case φ = 0, cos φ = 1. There is maximum power dissipation.
2. Purely inductive or capacitive circuit: If the circuit contains only an inductor or capacitor, we know that the phase difference between voltage and current is π/2. Therefore, cos φ = 0, and no power is dissipated even though a current is flowing in the circuit. This current is sometimes referred to as wattless current.

Detailed Explanation

Different types of circuits affect power dissipation in various ways due to their phase relationships. In purely resistive circuits, power is fully utilized (cos φ = 1). In contrast, inductive and capacitive circuits do not use power effectively because the current and voltage are 90 degrees out of phase (cos φ = 0), resulting in zero average power despite current flowing.

Examples & Analogies

Consider a restaurant's kitchen as a resistive circuit — all chefs are actively cooking (maximum power use). Now think of an entirely empty kitchen as an inductive circuit; appliances might be on, but no one is actually cooking, leading to wasted energy (the appliances draw power without contributing to output).

Power Dissipation at Resonance

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

At resonance, X_L - X_C = 0, and φ = 0. Therefore, cos φ = 1 and P = I^2 Z = I^2 R. That is, maximum power is dissipated in a circuit (through R) at resonance.

Detailed Explanation

In a resonant circuit, the capacitive reactance and inductive reactance cancel each other out, leading to no phase difference between current and voltage. This results in maximum efficiency in power transfer, effectively using all supplied power for work rather than losing any as reactive power.

Examples & Analogies

Think of a swing: if you push it at just the right moment (resonance), it swings higher and higher. If you miss the timing (not at resonance), the swing won't gain as much energy. In electrical circuits, tuning into resonance optimizes power use effectively.

Practical Implications of Power Factor

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

For circuits used for transporting electric power, a low power factor implies large power loss in transmission. Explain.
Power factor can often be improved by the use of a capacitor of appropriate capacitance in the circuit.

Detailed Explanation

A low power factor indicates inefficiency in a system, requiring more power (current) to do a task than necessary, thus risking greater losses during transmission. By adding capacitors to the circuit, we can counteract lagging current, improve the power factor, and reduce energy losses, making the system more efficient.

Examples & Analogies

Picture filling up your car with gas; if your fuel efficiency is poor (low power factor), you need to fill the tank more often (more energy lost). By optimizing your driving habits (adding capacitors), you get more distance out of the same fill-up, reducing waste.

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Power Factor: A measure of how effectively current is converted to useful power in an AC circuit.

  • Instantaneous Power: The power at a specific instant in an AC cycle, derived from voltage and current.

  • Average Power: The power consumed over a full cycle, factoring in the phase relationship between current and voltage.

  • Effects of Circuit Types: Power dissipation varies significantly between resistive, inductive, and capacitive circuits.

  • Resonance: Occurs when inductive and capacitive reactances cancel, leading to maximum power transfer.
