3.3 - ELECTRIC CURRENTS IN CONDUCTORS
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Electric Currents
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we will discuss electric currents in conductors. What do you think happens when an electric field is applied to a conductor?
The electrons will start moving, right?
Exactly! Electrons will drift towards the positive terminal. Let's remember this concept with the phrase: 'Electrons love positivity!'
What happens when there's no electric field?
Great question! Without an electric field, electrons move randomly due to thermal motion, resulting in no net current.
So, they just bounce around?
That's right! They collide with fixed ions, changing direction but averaging out to no net flow.
Current Flow Mechanism
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now, how do we establish a current flow within a conductor?
By applying an electric field?
Exactly! The electric field accelerates the free electrons in the conductor towards the positive end.
But how does that create current?
The movement of charge per unit time constitutes current. Think of the analogy: just as water flows through a pipe under pressure, electrons flow through a conductor under an electric field.
Does the temperature affect this flow?
Yes! Higher temperatures increase thermal motion, but the drift velocity in the presence of an electric field becomes the net flow we observe as current.
Collisions and Drift Velocity
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let's now talk about what happens when electrons collide with ions in a conductor.
Do they lose energy or momentum?
Great observation! They lose energy momentarily but continue drifting towards the positive terminal due to the electric field. This behavior is described by 'drift velocity.'
So, there is a steady average speed of electrons?
Yes! The average drift velocity is independent of time, and it results in a net transport of charge that creates current.
How do we calculate drift speed?
The drift speed can be calculated using the formula: v_d = I / (n * A * q), where n is the charge carrier density, A is the cross-sectional area, and q is the charge.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
In this section, we explore how electric currents are established in solid conductors, emphasizing the role of electric fields in causing free electrons to drift. We also examine the thermal motion of electrons and how collisions with fixed ions in the conductor affect the flow of current.
Detailed
Electric Currents in Conductors
In solids like metals, electric currents emerge when an electric field is applied. Free electrons in metals move toward the positive end of the electric field, resulting in current flow. Initially, in the absence of an electric field, electrons move randomly due to thermal motion, leading to no net current. When an electric field influences the electrons, they begin to drift in a specific direction, creating a current. Collisions with fixed ions can randomize the direction of their motion, but the net movement remains toward the positive terminal of the electric field. This concept establishes the basis for understanding steady currents in conductors, leading us towards key laws like Ohm's Law in subsequent sections.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Movement of Electric Charges
Chapter 1 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
An electric charge will experience a force if an electric field is applied. If it is free to move, it will thus move contributing to a current. In nature, free charged particles do exist like in upper strata of atmosphere called the ionosphere. However, in atoms and molecules, the negatively charged electrons and the positively charged nuclei are bound to each other and are thus not free to move.
Detailed Explanation
When an electric charge is placed in an electric field, it experiences a force that can cause it to move. If the charged particle is free, like electrons in a conductor, it contributes to an electric current. However, in most materials, such as atoms and molecules, electrons are bound to their nuclei and cannot move freely. Hence, the ability of a material to conduct electricity depends on the availability of free charges.
Examples & Analogies
Consider a crowded room where people (analogous to electrons) are trying to move around. If the lights turn on (an electric field is applied), people might start moving towards the exit, but if the room is filled with obstacles (the nuclei), their movement is limited.
Conductors vs. Insulators
Chapter 2 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
In some materials, the electrons will still be bound, i.e., they will not accelerate even if an electric field is applied. In other materials, notably metals, some of the electrons are practically free to move within the bulk material. These materials, generally called conductors, develop electric currents in them when an electric field is applied.
Detailed Explanation
Different materials behave differently when subjected to an electric field. Conductors, such as metals, have electrons that can move freely, allowing electrical currents to flow. On the other hand, insulators, like rubber and glass, have bound electrons that do not conduct electricity well because they cannot move freely in response to an electric field.
Examples & Analogies
Think of conductors like a highway where cars (electrons) can move freely, allowing traffic (current) to flow smoothly. In contrast, an insulator is like a parking lot where cars are blocked or parked and cannot move easily, preventing any flow.
Effect of Electric Field on Electrons
Chapter 3 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Consider first the case when no electric field is present. The electrons will be moving due to thermal motion during which they collide with the fixed ions. An electron colliding with an ion emerges with the same speed as before the collision. However, the direction of its velocity after the collision is completely random.
Detailed Explanation
In the absence of an electric field, the motion of electrons in a conductor is random due to thermal energy. While they may collide with fixed ions and bounce off, their overall movement does not result in a net flow of electric current, as directions cancel each other out, leading to no average directional motion.
Examples & Analogies
Imagine a box full of ping pong balls shaking randomly. Even though they bounce around a lot, if you look from above, you wouldn't see any particular direction of movement—most of their movement cancels out, just like electrons without an electric field.
Creating Current with Electric Field
Chapter 4 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Let us now see what happens to such a piece of conductor if an electric field is applied. Suppose we now take two thin circular discs of a metallic cylinder. An electric field will be created and is directed from the positive towards the negative charge. The electrons will be accelerated due to this field towards +Q.
Detailed Explanation
When an electric field is applied to a conductor, it creates a force that accelerates free electrons in the direction opposite to the field (since electrons are negatively charged). This acceleration results in a net flow of electrons, constituting an electric current as the electrons move to neutralize positive charges.
Examples & Analogies
Think about a water slide. When you push water down the slide (applying an electric field), the water flows downwards (the movement of electrons due to the electric field), creating a current of water much like how electrons move to form an electric current.
Steady Electric Current Conditions
Chapter 5 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The current thus will stop after a while unless the charges +Q and –Q are continuously replenished. We can also imagine a mechanism where the ends of the cylinder are supplied with fresh charges to make up for any charges neutralised by electrons moving inside the conductor.
Detailed Explanation
For a continuous current to flow in a conductor, there needs to be a constant supply of charge, as electrons will neutralize the fixed charges in the conductor quickly. This is typically achieved through sources such as batteries, which provide a steady influx of charges to maintain the current.
Examples & Analogies
It's like a water tank with a continuous inflow. If you open a tap (apply an electric field), water flows out (electrons move), but if there's no water coming in to replace what’s leaving, the flow will eventually stop.
Key Concepts
-
Electric Field: An area around charged particles where they exert forces on other charges.
-
Conductors: Materials that allow free flow of electric charges (e.g., metals).
-
Drift Velocity: The average velocity of charge carriers in a conductor under the influence of an electric field.
Examples & Applications
When an electric field is applied to a metallic wire, the free electrons in the metal drift toward the positive terminal, creating an electric current.
The drift speed of electrons in a copper wire carrying a 3 A current can be calculated using its cross-sectional area and the number of free electrons per volume.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
In conductors where charges flow, an electric field makes them go!
Stories
Imagine a race: electrons are the racers, drifting towards the finish line when the electric field is turned on, highlighting their journey through the conductor.
Memory Tools
C.E.D: Current causes Electrons to Drift in a conductor.
Acronyms
E.C.C - Electric Current Conductor
Remembering the flow of charge in conductors.
Flash Cards
Glossary
- Electric Current
The flow of electric charge through a conductor.
- Drift Velocity
The average velocity of charge carriers in a conductor due to an electric field.
- Thermal Motion
The random motion of particles due to thermal energy.
- Free Electrons
Electrons in a conductor that are not bound to any atom and can move freely.
