Equation of Motion for Linear SDOF System
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Today, we are diving into the Equation of Motion for a Single-Degree-of-Freedom (SDOF) system, which is essential in understanding how structures behave under dynamic loads. Can anyone tell me what the components of the equation are?
The equation includes mass, damping, stiffness, displacement, and the external force.
Exactly! The equation is given as mx¨(t)+cx˙(t)+kx(t)=F(t). This equation models the system's motion. Who can explain the significance of each term?
The mass 'm' represents the inertia of the system, 'c' is the damping coefficient that reflects how energy is dissipated, and 'k' is the stiffness that relates to how much the structure resists deformation.
Great job! The displacement 'x(t)' tells us the system's position over time while 'F(t)' is the applied force. Remember, understanding these terms is crucial because they set the stage for the Duhamel Integral, where we analyze how the system reacts to various forces.
So, the equation helps us understand how structures respond dynamically?
Exactly, that's the essence of structural dynamics! Let’s keep these concepts in mind as we move forward.
Derivation of Duhamel’s Integral
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Now that we understand the equation of motion, let’s talk about the derivation of Duhamel's Integral. Who can tell me what the principle of superposition is?
It's the principle that allows us to analyze the response to complex loads by breaking them down into simpler components, right?
Correct! By expressing an arbitrary force F(t) as a series of infinitesimal impulses, we can describe the entire system response. The total response is given by: x(t)=∫h(t−τ)F(τ)dτ. What do each of these components represent?
Here, h(t−τ) is the impulse response function, and it shows how the system reacts over time to the applied force F(τ).
Exactly right! This convolution integral encapsulates the impact of every past force on the current state of the system. It’s particularly powerful in earthquake engineering, where forces vary rapidly with time.
So, are we saying each infinitesimal force has a lasting effect until the present time?
Yes! That’s the essence of the Duhamel Integral. It sums up all past effects to find the current response.
Application to Earthquake Ground Motion
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Let’s shift gears and look into a practical application of Duhamel’s Integral in earthquake engineering. Instead of an external force, we often deal with ground acceleration. Can anyone recall how we modify the equation of motion?
Right! We account for the ground motion affecting the structure directly with mx¨(t)+cx˙(t)+kx(t)=−mu¨g(t).
That’s perfect! Using this modified formula, we can use Duhamel’s Integral like this: x(t)=−∫h(t−τ)mu¨g(τ)dτ. Why do you think this framework is necessary in practice?
Because real earthquake data comes as acceleration signals, and using this formulation helps engineers determine how buildings respond to these dynamic forces.
Exactly, you’ve got it! Understanding the relative displacement caused by shaking is crucial for designing resilient structures.
Introduction & Overview
Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.
Quick Overview
Standard
The Duhamel Integral allows for the analysis of the response of linear time-invariant (LTI) single-degree-of-freedom (SDOF) systems subjected to dynamic loading over time. By utilizing impulse response functions and convolution integrals, it aids in understanding the impact of time-varying forces on structural behavior during scenarios such as earthquakes.
Detailed
Duhamel Integral in Structural Dynamics
The Duhamel Integral is a crucial mathematical formulation utilized in earthquake engineering to determine the dynamic response of linear time-invariant (LTI) single-degree-of-freedom (SDOF) systems subjected to arbitrary dynamic loading. The primary equation of motion defining such a system is presented as:
$$ mx¨(t)+cx˙(t)+kx(t)=F(t) $$
where \(m\) represents the mass, \(c\) is the damping coefficient, and \(k\) signifies the stiffness of the system.
Before deriving the Duhamel Integral, we define the impulse response function \(h(t)\), which encapsulates how a system responds to a unit impulse force. The integral is derived through the principle of superposition, enabling the expression of the system's response as a convolution integral involving the input force \(F(t)\) and the impulse response function. This leads to:
$$ x(t)=\int_0^t h(t−τ)F(τ)dτ $$
A critical application of the Duhamel Integral is in assessing base excitation due to earthquake ground motion, where it transforms the input from a force as a function of time to consider ground acceleration. This integral necessitates numerical evaluation for practical implementations, employing techniques like the Trapezoidal Rule and Simpson’s Rule. While the method offers exact analytical solutions for linear systems, it acknowledges limitations, particularly in dealing with nonlinear systems or requiring zero initial conditions. The extended application to multi-degree-of-freedom (MDOF) systems through modal analysis underscores its significance in effective structural dynamics assessment.
Youtube Videos
![[5/8] An introduction to dynamic crowd loading | Duhamel Integral Project | DegreeTutors.com](https://img.youtube.com/vi/7EybBdpdoQs/mqdefault.jpg)
![[1/8] The Duhamel Integral | Crowd Vibration Project | DegreeTutors.com](https://img.youtube.com/vi/yOef1uu7Ask/mqdefault.jpg)
![[2/8] Duhamel Integral - Analytical Solution | Crowd Vibration Project | DegreeTutors.com](https://img.youtube.com/vi/1YwFMyCJjmI/mqdefault.jpg)
Audio Book
Dive deep into the subject with an immersive audiobook experience.
10.1 Equation of Motion for Linear SDOF System
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Consider a single-degree-of-freedom (SDOF) system subjected to an external time-varying force F(t). The general equation of motion is given by:
mx¨(t)+cx˙(t)+kx(t)=F(t)
Where:
- m = mass of the system
- c = damping coefficient
- k = stiffness of the system
- x(t) = displacement as a function of time
- F(t) = applied external force
This second-order linear differential equation with constant coefficients governs the motion of the system under arbitrary loading.
Detailed Explanation
The equation of motion for a single-degree-of-freedom (SDOF) system describes how the system behaves when subjected to an external force that varies over time. The equation is a second-order differential equation where:
- m represents the mass of the system, which defines how much inertia the system has.
- c indicates the damping coefficient, which measures how the system dissipates energy (for example, through friction).
- k is the stiffness of the system, measuring how resistant the structure is to displacement due to the applied force.
- x(t) shows the displacement of the system at any time t.
- F(t) is the external force that affects the system's motion.
The equation essentially balances these forces: the inertia (mass times acceleration), the damping (which resists motion), and the stiffness (which resists deformation) all responding to the external force.
Examples & Analogies
Imagine a swing (the SDOF system) being pushed (the external force). The more you push, the more it moves. However, if someone is hanging onto the swing (damping), it will not swing as far or as fast. The swing's ability to go higher also depends on the length of the chains (stiffness). This dynamic interaction where the swing moves back and forth in response to the pushes exemplifies how the equation of motion applies.
10.2 Impulse Response Function
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Before deriving the Duhamel Integral, we define the impulse response function h(t) as the response of the system to a unit impulse force applied at t=0:
F(t)=δ(t)
The solution x(t) for such an input is the unit impulse response, which depends on the damping condition of the system.
Detailed Explanation
The impulse response function h(t) is crucial as it characterizes how the system reacts over time when subjected to an instantaneous force (an impulse). An impulse is represented mathematically as δ(t), which means an extremely short and powerful force applied at the very start (t=0). The resulting response x(t) varies based on the system's damping condition:
- In the underdamped case, the system exhibits oscillatory behavior.
- In critically damped and overdamped cases, the system’s response varies by how quickly it returns to equilibrium without oscillating.
Examples & Analogies
Imagine someone pushing a child on a swing. If you give a hard push (impulse at t=0), the swing goes up high for a moment before coming down again. That trajectory the swing follows after that push describes the impulse response. If someone sits on the swing and gently resists the push (damping), it will return to a steady position more slowly. The impulse response will describe how high the swing went and how it came back down.
10.3 Derivation of Duhamel’s Integral
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
The system's response to a general force F(t) can be obtained using the principle of superposition and convolution. The idea is that any arbitrary force can be broken down into infinitesimally small impulses over time.
Using the superposition of the effects of these impulses, the total response is given by:
t
x(t)=∫h(t−τ)F(τ)dτ
0
This is the Duhamel Integral, where:
- x(t) is the displacement response at time t
- h(t−τ) is the impulse response function
- F(τ) is the force at time τ
- τ is a dummy time variable.
Detailed Explanation
Duhamel’s Integral is derived from the principle of superposition, which states that the response of a system to multiple stimuli can be calculated by summing the responses to each stimulus. Applying this to any general force F(t), we can consider the force as consisting of many small impulses that occur over time. Each of these impulses produces a reaction in the system. The total response x(t) at any time can then be calculated by integrating the effects of all past impulses—this integration yields the Duhamel Integral:
x(t) = ∫h(t−τ)F(τ)dτ.
Here, h(t−τ) indicates that the effect of a force applied at an earlier time τ affects the system's response at the current time t—capturing the delayed response essence that is common in dynamic systems.
Examples & Analogies
Think of throwing pebbles into a pond. Each pebble creates ripples (responses) that spread out from the point of impact. If you throw multiple pebbles at different times, the total effect in the water will be the sum of all the ripples caused by each pebble. Duhamel's Integral allows us to sum up these effects mathematically to predict the water's movement (the system's response) at any time after the last pebble was thrown.
10.4 Physical Interpretation
Unlock Audio Book
Signup and Enroll to the course for listening the Audio Book
Duhamel’s integral expresses the total system response as the weighted accumulation of the impulse responses over time. Each infinitesimal force F(τ)dτ applied at an earlier time τ causes a delayed response that persists until time t, and the integral sums up these effects.
Detailed Explanation
Duhamel’s Integral provides a deep understanding of how a system accumulates responses to forces over time. It tells us that every small force applied earlier influences the system's behavior later. Each of these tiny forces (F(τ)dτ) has an associated impulse response (h(t−τ)), meaning that the effect lingers and contributes to the total displacement at time t. This concept is particularly useful in contexts like earthquake engineering, where ground motions do not impact structures instantaneously but rather create a series of delayed effects that must be accounted for in analysis.
Examples & Analogies
Consider a tree swaying in the wind. When the wind blows (the force), it doesn't just affect the tree instantly; rather, the movement of the branches takes time to respond to each gust. As each wind gust hits the tree at different times, it creates a cumulative effect on how far the tree bends and sways. Duhamel's Integral helps us capture that compounding influence of all past wind gusts on the tree's position at any moment.
Definitions & Key Concepts
Learn essential terms and foundational ideas that form the basis of the topic.
Key Concepts
-
Duhamel Integral: A vital mathematical tool used in evaluating structural responses.
-
Impulse Response Function: Essential for understanding how past inputs affect current output in dynamic systems.
-
Convolution Integral: The fundamental operation that embodies the relationship between input force and structural response.
Examples & Real-Life Applications
See how the concepts apply in real-world scenarios to understand their practical implications.
Examples
-
Using Duhamel's Integral to evaluate the displacement of a bridge due to an earthquake recorded as ground acceleration.
-
Applying numerical methods to estimate the response of a building after an earthquake, allowing engineers to predict its behavior.
Memory Aids
Use mnemonics, acronyms, or visual cues to help remember key information more easily.
🎵 Rhymes Time
-
For impulse force so fine, h(t) shows how systems align.
📖 Fascinating Stories
-
Imagine a bridge standing tall; it shakes when quakes call. Duhamel helps it know just how to sway, so it holds firm and stays.
🧠 Other Memory Gems
-
Remember: I - Input, R - Response, C - Convolution for the integral to thrive.
🎯 Super Acronyms
DAMP
- Duhamel’s Analytical Model for Physics
Flash Cards
Review key concepts with flashcards.
Glossary of Terms
Review the Definitions for terms.
-
Term: Duhamel Integral
Definition:
A mathematical formulation used to determine the response of linear time-invariant systems to arbitrary dynamic loading.
-
Term: SingleDegreeofFreedom (SDOF) System
Definition:
A structural model that can be described by a single mass, providing a simplified analysis of dynamics.
-
Term: Impulse Response Function
