19.5 - Earthquake Magnitude and Intensity
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Understanding Earthquake Magnitude
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Welcome everyone! Today, we're diving into the concept of earthquake magnitude. Can anyone tell me what they think 'magnitude' refers to when we talk about earthquakes?
Isn't it something to do with how big the earthquake is?
Exactly, Student_1! Magnitude quantifies how much energy is released at the earthquake’s source. What are some scales used to measure that energy?
I think there's something called the Richter Scale?
And the Moment Magnitude Scale too, right?
Correct! The Richter Scale was one of the first scales used, but the Moment Magnitude Scale is now more accurate. Remember: **'Magnitude = Measure of Energy'.**
Magnitude Scales
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let’s talk about these scales more. What do you think the difference is between the Richter Scale and the Moment Magnitude Scale?
I think the Richter Scale is simpler but not as accurate for large quakes.
Exactly, Student_4! The Richter Scale can underestimate larger earthquakes. The Moment Magnitude Scale, however, considers the seismic moment, which makes it more accurate overall.
So, for very large earthquakes, we should prefer the Moment Magnitude Scale?
Yes, that's correct! Keep in mind: **'Moment Magnitude = More Accurate'.**
Understanding Intensity
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Moving on to intensity. How do you think we can measure the effects of an earthquake on people and buildings?
Is that what the Modified Mercalli Intensity Scale does?
Exactly! The Modified Mercalli Intensity Scale qualitatively evaluates the impact of an earthquake, ranging from I, which is 'not felt', to XII, which indicates 'total destruction'.
So, intensity is different from magnitude! It varies based on location and how strong the ground shakes, right?
Correct, Student_3! Remember: **'Intensity = Impact on People and Structures'.**
Practical Significance
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let’s connect this back to why magnitude and intensity are important. Why do you think engineers need to know these measurements?
To make buildings that can withstand earthquakes?
Exactly! By understanding both the energy released and the effects on structures, engineers can design buildings that can better survive seismic events.
So it helps in urban planning too?
Yes! Knowledge of both magnitude and intensity aids in developing safer cities. Remember this: **'Design with Data: Magnitude and Intensity'.**
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
In this section, we explore earthquake magnitude, which quantifies the energy released during an earthquake, and intensity, which qualitatively assesses its effects on people and structures. Key scales such as the Richter Scale and the Modified Mercalli Intensity Scale are discussed, along with their significance in understanding earthquake impact.
Detailed
Earthquake Magnitude and Intensity
In the study of seismology, two critical concepts are earthquake magnitude and intensity. Magnitude quantifies the energy released at the source of the earthquake, primarily measured using the Richter Scale and the Moment Magnitude Scale (Mw). The Richter Scale, log-based, is effective for large earthquakes, while the Moment Magnitude Scale is more accurate and widely used today, accommodating various types of seismic actions.
On the other hand, Intensity gauges the qualitative effects of an earthquake on individuals, structures, and the Earth's surface. The Modified Mercalli Intensity (MMI) Scale ranges from I (not felt) to XII (total destruction) and varies based on distance from the epicenter and local site conditions. Understanding these two aspects—magnitude and intensity—is crucial for engineers and urban planners to design structures that can withstand seismic activities.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Magnitude
Chapter 1 of 2
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Quantifies the energy released at the source.
- Richter Scale (ML): Logarithmic; not effective for very large earthquakes.
- Moment Magnitude Scale (Mw): Based on seismic moment; more accurate and widely used.
Detailed Explanation
Magnitude is a way of measuring the energy released by an earthquake at its source. There are two main scales used for measuring magnitude:
- Richter Scale (ML): This scale measures magnitude on a logarithmic scale, which means that each whole number increase on the scale represents a tenfold increase in measured amplitude. However, it is less effective for very large earthquakes, where other scales are preferred.
- Moment Magnitude Scale (Mw): This is the more modern and widely used scale, as it is based on the seismic moment of a quake, making it more accurate for all sizes of earthquakes. It takes into account the area of the fault that slipped, the amount of slip, and the rigidity of the rocks involved.
Examples & Analogies
Think of measuring the volume of water using two different containers. The Richter Scale is like using a small cup that can only handle small amounts of water accurately. If you pour in too much, it overflows, similar to how the Richter scale can underestimate large earthquakes. On the other hand, the Moment Magnitude Scale is like using a bucket that can accurately measure any amount of water—small or large—without overflowing.
Intensity
Chapter 2 of 2
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Qualitative measure of effects on people, structures, and the Earth's surface.
- Modified Mercalli Intensity (MMI) Scale: Ranges from I (not felt) to XII (total destruction).
- Varies with distance from epicenter and local site conditions.
Detailed Explanation
Intensity assesses the effects of an earthquake rather than the energy released. It looks at how people feel the shaking, the damage done to buildings, and the changes to the landscape. The Modified Mercalli Intensity (MMI) Scale is commonly used for this purpose, ranging from I, where the earthquake is not felt, to XII, which indicates total destruction. Intensity can vary widely depending on the earthquake's distance from the epicenter (the point on the Earth's surface directly above where the earthquake originates) and local conditions, such as soil type and structure behavior.
This means that an earthquake could be measured the same in terms of magnitude but have very different effects in different locations based on these factors.
Examples & Analogies
Imagine a rock thrown into a calm pond. The splash created near the rock is much bigger than the ripples felt at the edge of the pond. Similarly, people close to the epicenter of an earthquake may experience intense shaking and damage, while those farther away feel less or even none at all, depending on where they are located and the ground conditions.
Key Concepts
-
Magnitude: A measure of energy released during an earthquake.
-
Intensity: Assessment of earthquake effects on people and structures.
-
Richter Scale: A logarithmic measure of earthquake magnitude.
-
Moment Magnitude Scale: A more accurate measure of earthquake magnitude.
-
Modified Mercalli Intensity Scale: Measures the severity of an earthquake's effects.
Examples & Applications
An earthquake measuring 6.0 on the Richter scale indicates significant energy release, while a 9.0 indicates much more severe potential for damage.
The Modified Mercalli Scale rating of VIII means 'Severe damage; many buildings destroyed', reflecting the intensity of the earthquake.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Richter provides a simple measure, but Moment’s scale gives a broader treasure.
Stories
Imagine a village where a small 2.0 quake barely rattles the windows, while a 9.0 shakes buildings down, showing the difference between magnitude and intensity.
Memory Tools
Remember 'MICE': Magnitude is for energy scale, Intensity shows how we wail, considering ground conditions and people's tale!
Acronyms
MIG
Magnitude Indicates Ground shaking.
Flash Cards
Glossary
- Magnitude
A quantitative measure of the energy released at the source of an earthquake.
- Intensity
A qualitative measure of the effects of an earthquake on people, structures, and the Earth's surface.
- Richter Scale
A logarithmic scale used to measure the magnitude of earthquakes.
- Moment Magnitude Scale (Mw)
A scale that measures the total energy released during an earthquake, more accurate than the Richter scale.
- Modified Mercalli Intensity (MMI) Scale
A scale that measures the intensity of an earthquake based on its effects.
