19.3 - Seismic Waves
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Seismic Waves
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we're going to learn about seismic waves. Can anyone tell me what they think seismic waves are?
Aren't they the waves that happen during an earthquake?
Exactly! Seismic waves are energy waves that travel through the Earth during an earthquake. They help us understand the earthquake's characteristics. There are two main types: body waves and surface waves.
What are body waves?
Great question! Body waves travel through the Earth's interior. They include Primary waves, which can move through solids, liquids, and gases, and Secondary waves, which only move through solids.
Why can't S-waves travel through liquids?
S-waves are shear waves, and they require a medium that can resist shear stress, which liquids cannot do. Remember, P for Primary and P for Push-Pull - they compress and expand the material!
That's a good way to remember! What about the surface waves?
Surface waves travel along the Earth's surface and cause most of the damage. They include Love and Rayleigh waves. Love waves move side to side, while Rayleigh waves roll in a motion like waves on a beach!
To summarize, seismic waves are classified into body waves — P and S waves — and surface waves — Love and Rayleigh waves. P waves travel through all states of matter, S waves only through solids, while surface waves are primarily responsible for damage during an earthquake.
Characteristics of Seismic Waves
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let's delve deeper into the characteristics of these seismic waves. Why do you think P-waves are the fastest?
Maybe because they push and pull the ground quickly?
Yes! The compressional nature of P-waves allows them to travel faster through the material. Remember, fast waves mean they reach the surface first — that's why they are called primary! Now, can anyone explain what happens during S-waves?
They shake the ground side to side, right?
Correct! They cause shear motion and are slower than P-waves. They come second after P-waves in an earthquake sequence. Now, moving on to surface waves, who can tell me one significant aspect of them?
They cause the most damage?
Exactly! They can even roll like ocean waves, leading to more destructive forces. They shake buildings and infrastructure. Just remember, Love waves move horizontally while Rayleigh waves roll up and down!
So to summarize, P-waves are fast and travel through all states, S-waves are slower and only through solids, while surface waves, including Love and Rayleigh waves, do the most damage. Now you have a better understanding of how each wave functions during an earthquake.
Understanding Wave Damage
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let's explore how these seismic waves impact structures. Why do you think surface waves are more destructive?
They last longer?
That's right! Surface waves travel along the Earth's crust and can impact structures for longer periods, often causing more extensive damage than P or S waves. Can anyone recall the types of surface waves?
Love and Rayleigh waves!
Precisely! Love waves cause horizontal shaking, while Rayleigh waves create rolling motions. These motions can be particularly damaging to buildings that are not designed to withstand them. Can anyone think of examples of structures affected by these waves?
I remember seeing videos of buildings collapsing in earthquakes because of the waves!
Yes, that's what makes seismic design so essential. Engineers must consider these different waves when designing earthquake-resistant buildings to ensure they can withstand the shaking. As a summary, we discussed how surface waves, being longer-lasting and having specific motions, lead to more destruction compared to body waves. It's crucial to account for these in seismic engineering.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
Seismic waves are classified into body waves and surface waves, each with distinct characteristics. Body waves include Primary (P) waves, which travel through all states of matter, and Secondary (S) waves, which only travel through solids. Surface waves, which include Love and Rayleigh waves, travel along the Earth's surface and are responsible for much of the damage during earthquakes.
Detailed
Seismic Waves
In seismology, seismic waves are crucial for understanding earthquakes. They propagate through the Earth following an earthquake's occurrence, helping to analyze its characteristics.
Types of Seismic Waves
There are two primary categories of seismic waves:
- Body Waves: These waves travel through the Earth's interior and are divided into:
- Primary (P) Waves: These are compressional waves and the fastest seismic waves, capable of moving through solids, liquids, and gases. They exhibit a push-pull motion, leading to a change in volume.
- Secondary (S) Waves: Known as shear waves, these waves are slower than P-waves and can only travel through solids. They cause the ground to move perpendicular to the direction of wave propagation.
- Surface Waves: These waves travel along the Earth's surface and are generally responsible for most of the damage during earthquakes. They are further categorized into:
- Love Waves: These produce a side-to-side motion. They travel faster than Rayleigh waves and are particularly damaging due to their horizontal displacement.
- Rayleigh Waves: These waves cause a rolling motion that combines both vertical and horizontal movement. They often result in greater destruction than body waves due to their longer duration and surface-level impact.
Understanding these waves is essential for predicting earthquake behavior and designing resilient structures.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Body Waves
Chapter 1 of 6
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
19.3.1 Body Waves
• Travel through the Earth's interior.
Detailed Explanation
Body waves are seismic waves that move through the interior of the Earth. They are crucial for understanding how seismic energy travels within the Earth and can help us locate the source of earthquakes. There are two types of body waves: Primary (P) Waves and Secondary (S) Waves.
Examples & Analogies
Think of body waves like a sound traveling through a medium. For instance, when you speak, your voice travels through the air, which allows someone on the other side of the room to hear you. Similarly, body waves travel through different layers of the Earth.
Primary (P) Waves
Chapter 2 of 6
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
(a) Primary (P) Waves
• Compressional, fastest seismic waves.
• Can travel through solids, liquids, and gases.
Detailed Explanation
Primary waves, or P-waves, are the fastest type of seismic waves. They move by compressing and expanding the material they travel through, similar to how sound waves move through the air. Because they can pass through solids, liquids, and gases, they are detected first by seismographs, making them the first waves recorded during an earthquake.
Examples & Analogies
Imagine squeezing a slinky toy. When you compress it and then release, the coils move in a wave-like pattern. This is similar to how P-waves compress and expand the Earth's materials.
Secondary (S) Waves
Chapter 3 of 6
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
(b) Secondary (S) Waves
• Shear waves, slower than P-waves.
• Travel only through solids.
Detailed Explanation
Secondary waves, or S-waves, are slower than P-waves and move by causing shear or side-to-side motion in the materials they pass through. Unlike P-waves, S-waves can only travel through solids, which is why they arrive at seismographic stations after P-waves.
Examples & Analogies
Think about the motion of a jump rope being shaken side-to-side. This motion represents how S-waves cause the ground to shake from side to side. However, if we try to shake a fluid like water in a cup, you wouldn't see the same kind of side-to-side motion because the liquid cannot be sheared like a solid.
Surface Waves
Chapter 4 of 6
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
19.3.2 Surface Waves
• Travel along Earth’s surface; responsible for most damage.
Detailed Explanation
Surface waves travel along the Earth's surface and have a longer wavelength than body waves. They are responsible for most of the destruction during an earthquake as they cause the ground to shake in a complex motion. There are two main types of surface waves: Love Waves and Rayleigh Waves.
Examples & Analogies
Consider how waves appear in a pool. When you throw a stone, the ripples travel outward along the surface. Similarly, surface waves generate rolling motions that can cause significant shaking during an earthquake.
Love Waves
Chapter 5 of 6
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
(a) Love Waves
• Horizontal shear motion, side-to-side.
Detailed Explanation
Love waves are a type of surface wave that moves the ground side to side horizontally. They are faster than Rayleigh Waves but generally cause less vertical movement. This side-to-side motion can lead to significant damage to structures, especially those that are not well anchored.
Examples & Analogies
Think of Love waves as a group of people swaying side to side while holding hands. The movement creates a lateral shaking effect, similarly to how buildings might shake when Love waves pass underneath them.
Rayleigh Waves
Chapter 6 of 6
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
(b) Rayleigh Waves
• Rolling motion, both vertical and horizontal.
• Typically cause more destruction than body waves.
Detailed Explanation
Rayleigh waves are another type of surface wave characterized by their rolling motion, which combines both vertical and horizontal movements. This type of motion can create complex shaking patterns, leading to significant damage to structures during severe earthquakes.
Examples & Analogies
Imagine rolling waves on a beach. As the waves approach the shore, they rise and fall. This motion is similar to how Rayleigh waves make the ground move in a rolling fashion, which can be more destructive due to its complexity.
Key Concepts
-
Body Waves: Seismic waves that travel through the Earth's interior, including P and S waves.
-
P Waves: The fastest seismic waves that can move through solids, liquids, and gases, causing compressional movement.
-
S Waves: Slower than P waves, these waves cause shear motion and can only travel through solids.
-
Surface Waves: Travel along the Earth's surface and are responsible for much of the damage during earthquakes.
-
Love Waves: A type of surface wave with a horizontal side-to-side motion.
-
Rayleigh Waves: A type of surface wave causing a rolling motion that combines vertical and horizontal movements.
Examples & Applications
P waves can be felt as a quick jolt of pressure during an earthquake.
S waves can cause buildings to twist, leading to structural failure.
Rayleigh waves are responsible for the gentle rolling motion felt during an earthquake, which can cause significant damage over time.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Primary waves go fast and far, they push and pull like a shooting star.
Stories
Imagine a quiet pond. When you drop a stone, ripples create waves. The first ripples you see are P waves, pushing and pulling water. S waves follow, shaking side-to-side like swaying branches, while Love waves roll like waves on the shore, and Rayleigh waves dance underfoot, causing buildings to shudder.
Memory Tools
P-S-L-R: Remember P waves are Primary, S waves are Secondary, Love waves shake side-to-side, and Rayleigh waves roll.
Acronyms
BPS for Body Waves
Remember Body (B)
Primary (P)
Secondary (S) — they travel inside the Earth.
Flash Cards
Glossary
- Seismic Waves
Energy waves produced by earthquakes, travelling through the Earth.
- Body Waves
Seismic waves that travel through the Earth's interior.
- Primary (P) Waves
Fastest seismic waves that travel through solids, liquids, and gases, exhibiting compressional motion.
- Secondary (S) Waves
Slower seismic waves that only travel through solids and cause shear motion.
- Surface Waves
Seismic waves that travel along the Earth's surface, causing most earthquake damage.
- Love Waves
A type of surface wave characterized by horizontal shear motion.
- Rayleigh Waves
A type of surface wave that causes a rolling motion in both vertical and horizontal directions.
