28.2 - Earthquake Magnitude
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Richter Magnitude Scale (ML)
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, let's begin with the Richter Magnitude Scale, which was developed in 1935 by Charles F. Richter. Can anyone explain why we need a scale like this?
I think we need it to measure how strong an earthquake is!
Exactly! The Richter scale quantifies the energy released at the earthquake's source. It's based on the amplitude of seismic waves recorded by a seismograph. Let's remember: Richter = R for 'recorded' waves.
How much does the measurement increase with one unit?
Great question! With each unit increase in magnitude, there's about a tenfold increase in wave amplitude and a corresponding 32 times more energy release.
What's the formula for calculating it?
Good memory! The formula is M = log(A) − log(A₀). Can anyone tell me what those variables represent?
A is the maximum amplitude of seismic waves, and A₀ is the amplitude for a standard earthquake at 100 km.
Exactly! That’s it for Richter! Remember, it’s suitable for small to medium earthquakes when M is typically under 6.8.
Moment Magnitude Scale (Mw)
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now, let’s delve into the Moment Magnitude Scale, abbreviated as Mw. What do you think makes it the most widely used scale now?
Is it because it works for large earthquakes too?
Exactly! The Moment Magnitude Scale measures seismic moment, which allows for consistent values across all sizes of earthquakes. Who can tell me the formula for Mw?
Is it M_w = log(M₀) − 10.7?
Spot on! M₀ is calculated using shear modulus, rupture area, and average displacement. This scale does not saturate, making it reliable for assessing large-scale seismic events.
What does shear modulus mean, though?
Excellent question! Shear modulus refers to the rigidity of rocks, typically around 30 GPa. It determines how much deformation can occur under stress.
So it helps assess the actual strength of the quake?
Right again! It’s vital for understanding the potential impact of large earthquakes and how we design structures accordingly.
Other Magnitude Scales
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now that we've covered the two main scales, let's discuss other magnitude scales, like Body Wave Magnitude (Mb) and Surface Wave Magnitude (Ms). Who can explain these?
Mb focuses on P-wave amplitudes, right?
Right! And Ms focuses on surface wave amplitudes, particularly Rayleigh waves. These scales serve different purposes based on the specific characteristics of earthquakes.
Why would we need different scales at all?
Good inquiry! Each scale provides specialized information depending on the seismic properties and the type of waves considered. It’s all about ensuring accurate assessments.
So, there's also Duration Magnitude that's important, right?
Absolutely! Duration Magnitude considers how long the shaking lasts, which can impact the perceived strength of the earthquake. Understanding all scales allows for more accurate mapping of effects and risks.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
The section delves into the concepts of earthquake magnitude, detailing the evolution of measurement scales from the Richter Scale to the Moment Magnitude Scale, alongside other scales such as Body Wave Magnitude and Surface Wave Magnitude. Key differences, applications, and formulas for each scale are explored to understand their relevance in earthquake engineering.
Detailed
Earthquake Magnitude
Understanding earthquake magnitude is essential for assessing seismic activity and its potential impact on structures. This section explains the primary scales used to measure an earthquake's strength:
1. Richter Magnitude Scale (ML)
- Established in 1935 by Charles F. Richter, this scale measures seismic wave amplitudes recorded by a specific type of seismograph. It operates on a logarithmic scale, where each unit increase signifies a tenfold increase in wave amplitude and approximately 32 times more energy release.
- Formula: M = log (A) − log (A₀)
- Where A is the maximum wave amplitude, and A₀ is the amplitude of a standard reference.
- The Richter scale effectively describes smaller to medium earthquakes (typically under magnitude 6.8).
2. Moment Magnitude Scale (Mw)
- Presently the most common scale used worldwide, it is based on the seismic moment (Mo) of the earthquake, providing consistent values across a range of earthquake sizes and not saturating for larger events.
- Formula: M_w = log(M₀) − 10.7
- M₀ is determined by the shear modulus, the rupture area, and average displacement.
3. Other Magnitude Scales
- Body Wave Magnitude (Mb): Focused on P-wave amplitude.
- Surface Wave Magnitude (Ms): Centers on Rayleigh waves.
- Duration Magnitude: Analyzes the duration of shaking.
Each scale offers distinct benefits and applicability, ensuring comprehensive assessment depending on the earthquake characteristics and available data.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Richter Magnitude Scale (ML)
Chapter 1 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
• Developed in 1935 by Charles F. Richter.
• Based on the amplitude of seismic waves recorded on a Wood-Anderson seismograph.
• Logarithmic scale: each unit increase corresponds to 10 times more amplitude and ~32 times more energy release.
• Formula:
M = log(A) − log(A₀)
Where:
– A = maximum amplitude of seismic waves
– A₀ = amplitude for a standard earthquake at 100 km
• Suitable for small to medium earthquakes (typically < 6.8).
Detailed Explanation
The Richter Magnitude Scale was introduced in 1935 to provide a systematic way of measuring the energy produced by earthquakes. It uses a device called a seismograph to measure the seismic waves generated by an earthquake. The scale is logarithmic, meaning that for each whole number increase in the Richter scale, the amplitude of the earthquake waves increases by a factor of 10, and the energy released increases by about 32 times. For example, a 5.0 magnitude earthquake will produce waves that are ten times larger than those of a 4.0 magnitude quake.
The formula used to calculate the magnitude includes the maximum amplitude of the seismic wave and a standard amplitude reference for earthquakes occurring 100 kilometers away. However, it is most effective for smaller to medium-sized earthquakes, typically those below a magnitude of 6.8, beyond which its readings may not be as reliable.
Examples & Analogies
Think of the Richter Scale like a sound volume scale for music. If you increase the volume from 4 to 5, it’s 10 times louder. If you increase it from 5 to 6, it’s again 10 times louder than last level. Similarly, each step in magnitude is like turning up the music, with significant changes in impact.
Moment Magnitude Scale (Mw)
Chapter 2 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
• Currently the most widely used magnitude scale.
• Based on seismic moment (Mo):
M = log(M₀) − 10.7
Where:
– M₀ = µ·A·D
– µ = shear modulus of rocks (~30 GPa)
– A = rupture area
– D = average displacement
• Provides consistent values across a wide range of earthquake sizes.
• Does not saturate like the Richter scale for large earthquakes.
Detailed Explanation
The Moment Magnitude Scale (Mw) has become the go-to method for measuring earthquake magnitudes today because it accounts for the actual physical properties of the earthquake. It is based on the seismic moment, which considers the area of the fault that slipped, the average distance it slipped, and the stiffness of rocks involved. This scale provides a more accurate measure of the earthquake's size, especially for larger quakes, where the Richter scale may reach its limits (saturate). Its logarithmic formula gives a more reliable value across various earthquake sizes.
Examples & Analogies
Imagine measuring the size of a water balloon. The Moment Magnitude Scale measures not just how big the balloon looks from outside (like Richter) but also how much water fills it and how much pressure is inside. This way, you get a complete picture—just like when we measure earthquakes using Mw.
Other Magnitude Scales
Chapter 3 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
• Body Wave Magnitude (Mb): Based on P-wave amplitude.
• Surface Wave Magnitude (Ms): Based on Rayleigh surface waves.
• Duration Magnitude: Based on the duration of shaking.
Each scale serves different purposes and may be used based on the nature of the seismic event and available data.
Detailed Explanation
There are multiple scales used to measure earthquake magnitude, each suited to different types of seismic waves. The Body Wave Magnitude (Mb) uses the amplitude of P-waves, or primary waves, which are the fastest seismic waves. The Surface Wave Magnitude (Ms) looks at Rayleigh waves, which travel along the earth's surface and are responsible for much of the shaking. Additionally, the Duration Magnitude takes into account how long the shaking lasts. Depending on the location and type of earthquake, certain scales may be more appropriate than others.
Examples & Analogies
Think of each magnitude scale as different tools for measuring a lumber's thickness. Just like you would use a caliper for precision measurements or a ruler for quick estimates, scientists choose different scales based on what they want to measure from an earthquake.
Key Concepts
-
Earthquake Magnitude: A measure of the energy released during an earthquake, quantified using different scales.
-
Richter Scale: A historical scale measuring amplitude, effective for small to medium earthquakes.
-
Moment Magnitude Scale: The modern standard for measuring all sizes of earthquakes based on seismic moment.
-
Body Wave and Surface Wave Magnitudes: Specialized scales measuring different types of seismic waves.
Examples & Applications
An earthquake registering 5.0 on the Richter scale typically causes minor damage, while a magnitude of 7.0 can lead to severe structural failures.
A local earthquake with a magnitude of 6.0 might feel weaker in a city built with strong structures than in rural areas with poorly constructed buildings.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Richter measures waves with might, each number up means more in sight!
Stories
Imagine a scientist, Richter, standing by a seismograph, watching waves dance. Each swing of the wave tells a story of energy released, growing tenfold with each notch of the scale.
Memory Tools
Remember 'M's in Moment for 'Magnitude' since Moment Magnitude scales consistently measure all sizes.
Acronyms
R.M.M. = 'Recording Magnitude of Motion'
Helps remember Richter and Moment Magnitude serves as the main scales for measuring.
Flash Cards
Glossary
- Richter Scale
A logarithmic scale measuring the amplitude of seismic waves to determine the energy released by an earthquake.
- Moment Magnitude Scale
The most widely used scale that measures an earthquake's magnitude based on seismic moment, suitable for all sizes of earthquakes.
- Seismic Moment
A measure of the total energy released during an earthquake, calculated using the shear modulus, rupture area, and average displacement.
- Amplitude
The maximum extent of a wave's oscillation, essential in measuring the strength of seismic waves.
- Body Wave Magnitude (Mb)
A scale that measures the amplitude of P-waves to determine an earthquake's magnitude.
- Surface Wave Magnitude (Ms)
A scale that measures the amplitude of surface waves to assess earthquake magnitude.
- Duration Magnitude
A measure of an earthquake's magnitude based on the length of shaking.
