Properties of an Ellipse
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
The properties of an ellipse are explored in this section, detailing how the sum of the distances from two fixed points (foci) is constant, along with key elements like the major and minor axes and the concept of eccentricity, which describes the roundness of the ellipse.
Detailed
Properties of an Ellipse
An ellipse is a conic section formed when a plane intersects a cone at a specific angle. It can be defined geometrically as the locus of all points for which the sum of the distances from two fixed points, known as the foci, is constant. In this section, we explore the following key properties:
Key Properties
- Foci: There are two fixed points known as foci (singular: focus) that define the ellipse. The sum of the distances from any point on the ellipse to the two foci is constant and equals the length of the major axis.
- Major and Minor Axes: The major axis is the longest diameter of the ellipse, passing through both foci and the center. The minor axis is the shortest diameter, perpendicular to the major axis at the center, intersecting the ellipse at its widest points in the vertical direction.
- Eccentricity: The eccentricity (denoted by 'e') is a measure of how
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Foci of an Ellipse
Chapter 1 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
An ellipse consists of two fixed points known as foci.
Detailed Explanation
The foci of an ellipse are crucial as they help define the shape of the ellipse itself. An ellipse is defined as the set of points where the sum of the distances from any point on the ellipse to the two foci is constant. This constant distance is the key characteristic that differentiates an ellipse from other conic sections.
Examples & Analogies
Think of a racetrack. The two foci can be imagined as two points on the inside of the oval track. No matter where you are on the track, the total distance you run to those two points remains the same. This helps illustrate how distances to the foci work in an ellipse.
Major and Minor Axes
Chapter 2 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
An ellipse has two primary axes: the major axis, which is the longest diameter, and the minor axis, which is the shortest diameter.
Detailed Explanation
The major axis runs through both foci and is the longest line you can draw across the ellipse. Conversely, the minor axis is perpendicular to the major axis and is the shortest line across the ellipse. The lengths of these axes provide important information about the size and shape of the ellipse, with the length of the major axis being larger than that of the minor axis.
Examples & Analogies
Imagine if you were to stretch a rubber band in the shape of an ellipse. The longest stretch (major axis) would be from one end of the rubber band to the other across the widest part of the ellipse, while the shortest stretch (minor axis) would be from top to bottom at the narrowest part.
Eccentricity of an Ellipse
Chapter 3 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The eccentricity of an ellipse is a measure of how much it deviates from being circular.
Detailed Explanation
Eccentricity (often denoted as 'e') helps classify the shape of conics, with circles having an eccentricity of 0 and ellipses having a value between 0 and 1. The closer the eccentricity is to 0, the more circular the ellipse appears. Conversely, as the eccentricity approaches 1, the ellipse becomes more stretched out. This measure is defined mathematically as the ratio of the distance from the center to the foci, divided by half the length of the major axis.
Examples & Analogies
Consider two shapes: a perfect circle (like a round pizza) and a somewhat oval pizza. The circle has no 'stretch' or 'elongation', while the oval pizza does. If you think of the eccentricity as a measure of how 'elongated' the pizza shape is, the more oval it becomes, the larger the value of the eccentricity.
