20.4 - Solving the Time Equation
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Understanding the Time Equation
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we'll explore how to derive the time equation from the two-dimensional wave equation. This is crucial because the timing of vibrations greatly affects the behavior of a membrane.
What exactly does the time equation help us find?
Great question! The time equation helps us determine how the membrane vibrates over time, particularly showing us the patterns of motions like oscillations.
Does the equation change depending on the size of the membrane?
Yes! The constants in the equation like 'a' and 'b' represent the membrane's dimensions, and they directly impact the frequency of vibrations.
Finding Frequencies
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Next, let’s derive the circular frequency, \( \omega_{mn} \). Can anyone tell me why this is important?
I think it's because it shows how quickly the membrane oscillates.
Exactly! It quantifies the frequency of the oscillations based on the tension and the dimensional properties of the membrane.
How exactly do we calculate this frequency?
We compute it with: \( \omega_{mn} = c \sqrt{\left( \frac{n \pi}{a} \right)^2 + \left( \frac{m \pi}{b} \right)^2} \). This links the speed of waves in the material to its spatial dimensions.
General Solutions
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Finally, we can combine our derived time solutions with the spatial solutions. What does this look like?
Is it something like a series of sine and cosine functions?
Exactly! The general form will be \( u(x,y,t) = [A \cos(\omega_{mn} t) + B \sin(\omega_{mn} t)] \cdot \sin\left(\frac{n \pi x}{a}\right) \cdot \sin\left(\frac{m \pi y}{b}\right) \). This shows the full behavior of the membrane.
And how do we come up with the coefficients A and B?
Those are found using the initial conditions of the problem to ensure our solution fits the specific scenario.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
This section focuses on deriving the time solution for a rectangular membrane subject to fixed boundary conditions. It introduces circular frequency and the general form of the time-dependent solution as a combination of cosine and sine functions.
Detailed
Detailed Summary
This section begins with the derivation of the time equation from the two-dimensional wave equation of a rectangular membrane, leading to a second-order ordinary differential equation. The equation is given by:
\[ \frac{d^2T}{dt^2} + c^2 \left( \frac{n^2 \pi^2}{a^2} + \frac{m^2 \pi^2}{b^2} \right) T = 0 \]
This equation can be solved by finding the characteristic solutions in the form of harmonic functions:
\[ T(t) = A \cos(\omega_{mn} t) + B \sin(\omega_{mn} t) \]
Where \( \omega_{mn} \) is defined as:
\[ \omega_{mn} = c \sqrt{\left( \frac{n \pi}{a} \right)^2 + \left( \frac{m \pi}{b} \right)^2} \]
The constants \( A \) and \( B \) will be determined using the initial conditions of the problem. The results underscore the significance of frequency modes in determining the behavior of the membrane, particularly under dynamic loading conditions.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
The Time Equation Overview
Chapter 1 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The time equation is given by:
d²T/dt² + c²((n²π²/a²) + (m²π²/b²))T = 0
Detailed Explanation
This equation describes how the time-dependent part of the vibration of a rectangular membrane behaves over time. The left side, d²T/dt², represents the acceleration of the system, while the right side combines the wave speed and spatial properties of the membrane. To find solutions, we relate this equation to physical parameters like wave speed (c) and the dimensions of the membrane (a and b).
Examples & Analogies
Think of the time equation like a swing. Just as a swing accelerates forward or backward based on how hard you push it (acceleration) and its position (how high it is), this equation helps us understand how the membrane vibrates and changes over time.
Defining Angular Frequency
Chapter 2 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Let:
ω = √(c²((n²π²/a²) + (m²π²/b²)))
Detailed Explanation
Here, we define ω (angular frequency), which represents how quickly the system oscillates. This formula shows that ω is influenced by both the speed of the wave traveling through the membrane (c) and the geometry of the rectangular membrane (defined by the dimensions a and b). The terms involving n and m correspond to the mode of vibration—higher n or m values reflect more complex patterns.
Examples & Analogies
Imagine you are tuning a guitar. Each string vibrates at a different frequency depending on its length and tension. Similar to how string length corresponds to the vibration frequency of a string, the shape and dimensions of the membrane influence its oscillation.
General Form of the Time Solution
Chapter 3 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The solution for the time component is:
T(t) = A cos(ωt) + B sin(ωt)
Detailed Explanation
The function T(t) gives the displacement of the membrane over time, expressed as the sum of a cosine and a sine function. The parameters A and B represent the amplitude of the oscillations, which are determined by initial conditions. Cosine function indicates the starting position, and sine function represents how it progresses with time. This establishes a complete description of the system in temporal terms.
Examples & Analogies
Think of how a pendulum swings back and forth. The pendulum’s position at any moment can be described by a trigonometric function, similar to T(t) which details the movement over time. It reflects the oscillations, with A and B being like the maximum height and push you give to the pendulum.
Key Concepts
-
Two-Dimensional Wave Equation: Governs the vibrations of the membrane.
-
Time Equation: Derives from the wave equation and indicates how oscillations change over time.
-
Circular Frequency: Links the wave speed and the dimensions of the membrane.
Examples & Applications
A membrane of size 2m x 1m with a wave speed of 150m/s will have specific circular frequencies for its fundamental and higher modes based on the values of n and m.
In engineering projects, knowing the time response of the membrane allows for better design choices to avoid resonance.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Time flows in wave forms, oscillate and sway, the membrane vibrates, come what may.
Acronyms
DCM - Displacement, Circular frequency, Modes
remember how these link through the wave equation!
Stories
Imagine a tight membrane stretched across a frame. As tension pulls, it begins to oscillate in time, with frequencies dictated by its dimensions.
Memory Tools
F, C, T - Frequencies Come Together in time to define how vibrations resonate.
Flash Cards
Glossary
- Wave Equation
A mathematical description of the motion of waves through a medium, in this case, a rectangular membrane.
- Circular Frequency
A measure of how many radians the system oscillates per unit of time, calculated using wave properties.
- Separation of Variables
A method of solving partial differential equations by splitting them into simpler ordinary differential equations.
