4.2. Trusses

Trusses are statically determinate when all the bar forces can be determined from the equations of statics alone. Otherwise the truss is statically indeterminate.

A truss is considered statically determinate if we can calculate the forces in all the members using only the equations of static equilibrium (like the sum of forces and moments equals zero). If it is not possible to find all the forces this way, the truss is termed statically indeterminate. In essence, the distinction lies in whether we can resolve all the forces without needing additional information beyond statics.

Think of it like solving a puzzle: if you can fit all the pieces based solely on the visual guidance (equations), it's a determinate puzzle. If you find yourself guessing because some pieces don’t seem to fit no matter how you arrange them, it becomes indeterminate.

A truss may be statically/externally determinate or indeterminate with respect to the reactions (more than 3 or 6 reactions in 2D or 3D problems respectively). A truss may be internally determinate or indeterminate.

Trusses can be externally determinate or indeterminate based on how many reaction forces exist at the supports. For a 2D truss, having more than 3 reactions means it cannot be analyzed solely through statics. Internally, if the total number of members and reactions exceeds the available equilibrium conditions, it becomes internally indeterminate. Each type of determinate/indeterminate situation affects how the forces and stability of the truss can be analyzed.

Imagine a group of friends trying to hold a large umbrella. If they have exactly the right number of friends to support the umbrella, it stands perfectly (externally determinate). But if too many friends try to hold onto it, or not enough do, it could either be unstable or overly tough to manage (indeterminate).

For 2D trusses the external equations of equilibrium which can be used to determine the reactions are (ΣF_x = 0, ΣF_y = 0, ΣM = 0). For 3D trusses the available equations are ΣF_x = 0, ΣF_y = 0, ΣF_z = 0 and ΣM_x = 0, ΣM_y = 0, ΣM_z = 0.

In truss analysis, we apply the laws of equilibrium to ensure that all forces and moments balance out. For a 2D truss, we typically use two force conditions (horizontal and vertical) and one moment condition. For 3D trusses, we extend this to three force conditions (accounting for movement in all directions) and three moment conditions. This structured approach enables engineers to determine the reactions at the supports and the forces in the truss members.

Consider balancing a seesaw. If one person pushes down on one side, someone else must push up from the other side (equilibrium of forces). If they don't balance out, the seesaw tips (indicating instability). Just like on a seesaw, trusses need balance in multiple directions for stability!

In truss analysis, there is no sign convention. A member is assumed to be under tension (or compression). If after analysis, the force is found to be negative, then this would imply that the wrong assumption was made.

In truss analysis, engineers often begin by assuming whether members are under tension (pulling apart) or compression (pushing together). After calculating forces, if the calculated force is negative, it indicates that the initial assumption was incorrect - a member thought to be in tension is actually in compression and vice versa. This process helps clarify how each member behaves under applied loads.

It’s like assuming you're pulling on a door to open it (tension) only to find it’s actually being pushed closed by the wind (compression). Adjusting our understanding of how forces act is crucial for correctly analyzing the door’s behavior.

On a free body diagram, the internal forces are represented by arrows acting on the joints, not as end forces on the element itself.

In free body diagrams, which are essential tools in structural analysis, the forces acting on each joint of a truss are depicted as arrows that show the direction and magnitude of these forces. For example, arrows pointing away denote tension, while arrows pointing towards the joint depict compression. This visual method helps engineers analyze how forces distribute throughout the structure.

Imagine you’re at the center of a group of people, each pulling or pushing on you. The directions in which they're pulling or pushing (and how hard) can be visualized through arrows pointing towards or away from you, helping us understand the overall 'tension' of the group dynamics!

--
