Introduction to Displacement Current
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Today, we are going to discuss an important concept known as displacement current, introduced by James Clerk Maxwell. Can anyone tell me why we need this concept?
Maybe because, when we charge a capacitor, thereβs current but no actual flow between the plates?
Exactly! When a capacitor is charging, thereβs an electric field changing between the plates, and this doesn't create a traditional current like in wires. Thus, Maxwell suggested that we consider this changing electric field as a form of currentβhence, displacement current.
Whatβs the formula for this displacement current?
"Great question! The displacement current can be expressed as:
Ampère's Circuital Law and Generalization
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Now, let's consider Ampère's circuital law. Can anyone remind us what it states?
It states that the line integral of magnetic field B around a closed loop equals the permeability times the total current through the loop.
Perfect! But there's a problem when we apply it between the plates of a charging capacitor. The magnetic field must exist, but thereβs no conduction current flowing between the plates. How can we resolve this discrepancy?
Oh! We need to add the displacement current to the equation!
"Exactly! By modifying Ampère's law to include displacement current, we can find:
Electromagnetic Waves and Their Significance
Unlock Audio Lesson
Signup and Enroll to the course for listening the Audio Lesson
Finally, letβs talk about the implications of displacement current. What do you think it leads to?
It helps explain electromagnetic waves, right?
Absolutely! The displacement current creates a situation where electric and magnetic fields can propagate as waves through space. The oscillation of these fields is what we recognize as electromagnetic waves.
And these waves travel at the speed of light?
"Exactly! That speed is determined by the values of permittivity and permeability in a vacuum, yielding the relationship:
Introduction & Overview
Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.
Quick Overview
Standard
The section discusses Maxwell's introduction of displacement current, demonstrating its necessity through the behavior of electric fields in capacitors. It explains how displacement current contributes to magnetic fields, leading to a comprehensive understanding of electromagnetic waves.
Detailed
DISPLACEMENT CURRENT
Maxwell expanded upon Ampère's circuital law to include a new type of current, termed displacement current, which arises from changing electric fields. This addition was crucial for resolving inconsistencies observed in the traditional application of Ampère's law in scenarios involving capacitors, particularly when dealing with changing electric fields.
When charging a parallel plate capacitor, the electric field between the plates varies with time, which in turn influences the surrounding magnetic field. The displacement current, defined as
$$
i_d = rac{Ρ_0}{dt} rac{dΦ_E}{dt}
$$
acts in a similar manner to conduction current. Here, $Ξ¦_E$ represents the electric flux through the surface bounded by a closed loop that surrounds the capacitor's plates.
Maxwell's generalization of the Ampère's law can then be expressed as the sum of conduction and displacement currents, demonstrating that a changing electric field can produce a magnetic field, effectively supporting the existence of electromagnetic waves. These waves propagate through space at the speed of light, revealing the interconnected nature of electricity, magnetism, and light.
This discovery was pivotal, as it not only unified the laws governing electricity and magnetism but also paved the way for understanding the generation and propagation of electromagnetic waves, which manifest in various forms such as radio waves and visible light.
Youtube Videos
