9.5.1 - Refraction at a spherical surface

Interactive Audio Lesson

Listen to a student-teacher conversation explaining the topic in a relatable way.

Introduction to Refraction

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Today, we'll discuss refraction, specifically at spherical surfaces. When light travels from one medium to another, it changes direction. Who can tell me how we might describe this change?

Student 1
Student 1

Isn't it related to how dense the mediums are?

Teacher
Teacher

Great point, Student_1! We describe this change using the concept of refractive index, which compares the speed of light in two different media. Can anyone remind me what that means?

Student 2
Student 2

It's like... how fast light travels in one medium compared to another?

Teacher
Teacher

Exactly! The refractive index (n) tells us how much the speed of light decreases in the medium compared to vacuum. If light moves from less dense to more dense media, it bends towards the normal. Can anyone think of an example of this?

Student 3
Student 3

Like when we see a straw in a glass of water? It looks bent from the side!

Teacher
Teacher

Precisely! That's a perfect example of refraction. Let’s move on to how we can quantify this change with some equations!

Snell's Law

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Now, using Snell's law, we can describe the relation between the angles of incidence and refraction. Who remembers what Snell's law states?

Student 4
Student 4

It’s the sine of the angles of incidence and refraction are proportional to the refractive indices!

Teacher
Teacher

Exactly, Student_4! It can be stated as n₁ * sin(i) = n₂ * sin(r). This equation allows us to determine how much light bends when it hits different media. Who can summarize what each part means?

Student 1
Student 1

n₁ is the refractive index of the first medium, and n₂ is for the second. i and r are the angles of incidence and refraction, respectively.

Teacher
Teacher

Perfect! Now, let’s consider applying this to a spherical surface by deriving relationships between distances involved—object and image distances, and radius of curvature.

Application of Refraction Principles

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Knowing how light refracts is vital when designing lenses. If an object is placed in front of a lens, how do we find the image it creates?

Student 2
Student 2

We can use the lens formula, which relates focal length, object distance, and image distance!

Teacher
Teacher

"Exactly! The thin lens formula is

Introduction & Overview

Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.

Quick Overview

This section discusses the phenomenon of refraction at spherical surfaces and introduces the relationships involving object distance, image distance, refractive indices, and radii of curvature.

Standard

The section explains refraction at a spherical surface, detailing the geometric principles that govern image formation based on Snell's law. It explores the relationships among object distance, image distance, radius of curvature, and refractive indices, providing a foundational understanding for analyzing optical systems.

Detailed

Refraction at a Spherical Surface

This section covers the fundamental principles of refraction as it occurs at a spherical surface separating two different media. Refraction refers to the change in direction of light as it passes from one medium to another with different refractive indices. The section elaborates on the geometric relationships involved in image formation, leveraging Snell's law, which states that the ratio of the sine of the angle of incidence to the sine of the angle of refraction is constant for any two media.

Key equations related to object distance (u), image distance (v), refractive indices (n₁ and n₂), and the radius of curvature (R) are derived. The relationship derived through Snell’s law provides a means to relate these distances and indices:

n₁ * sin(i) = n₂ * sin(r)

Thus, the section emphasizes the importance of understanding these concepts for applications in optics, especially in designing lenses and analyzing optical instruments.

Youtube Videos

Class 12th Physics | Refraction at a Spherical Surface | Example 9.5 | Chapter 9 | NCERT
Class 12th Physics | Refraction at a Spherical Surface | Example 9.5 | Chapter 9 | NCERT
Ray Optics & Optical Instruments | Class 12 Physics | NCERT Chapter 9 | CBSE NEET JEE | One Shot
Ray Optics & Optical Instruments | Class 12 Physics | NCERT Chapter 9 | CBSE NEET JEE | One Shot
12th class physics chapter 9 ray optics one shot revision in 10 minutes PW....
12th class physics chapter 9 ray optics one shot revision in 10 minutes PW....
Refraction at a spherical surface | ray optics class 12 | ray optics class 12 physics
Refraction at a spherical surface | ray optics class 12 | ray optics class 12 physics
Ray Optics and Optical Instruments Class 12 Physics Chapter 9 One Shot | New NCERT CBSE | NEET
Ray Optics and Optical Instruments Class 12 Physics Chapter 9 One Shot | New NCERT CBSE | NEET
Plus Two Physics - Rayoptics and Optical Instruments | Xylem Plus Two
Plus Two Physics - Rayoptics and Optical Instruments | Xylem Plus Two
Spherical Refracting Surface -Ray Optics & Optical Instruments |Class 12 Physics Ch 9| CBSE/JEE/NEET
Spherical Refracting Surface -Ray Optics & Optical Instruments |Class 12 Physics Ch 9| CBSE/JEE/NEET
Refraction at Spherical Surface | Important Derivations | Ray Optics | plustwo focus area
Refraction at Spherical Surface | Important Derivations | Ray Optics | plustwo focus area
Collimator | collimated beam #iitian #experiment #physics #science #shorts #ms #mandalstudy #ytshort
Collimator | collimated beam #iitian #experiment #physics #science #shorts #ms #mandalstudy #ytshort
Refraction at Convex Surface - Ray Optics and Optical Instruments | Class 12 Physics 2022-23
Refraction at Convex Surface - Ray Optics and Optical Instruments | Class 12 Physics 2022-23

Audio Book

Dive deep into the subject with an immersive audiobook experience.

Introduction to Refraction at a Spherical Surface

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Figure 9.15 shows the geometry of formation of image I of an object O on the principal axis of a spherical surface with centre of curvature C, and radius of curvature R. The rays are incident from a medium of refractive index n₁ to another of refractive index n₂. As before, we take the aperture (or the lateral size) of the surface to be small compared to other distances involved, so that small angle approximation can be made. In particular, NM will be taken to be nearly equal to the length of the perpendicular from the point N on the principal axis.

Detailed Explanation

This introductory portion sets the stage for understanding how light behaves as it passes through a spherical surface. The spherical surface has a defined curvature characterized by its radius (R) and center (C). When light rays meet this curved surface, they enter at a certain angle depending on the rays' angle of incidence and the curvature of the surface. We examine these parameters to understand how images are formed through refraction.

Examples & Analogies

Think of a basketball placed in a bright room. If you shine a flashlight on it, the way the light interacts with the surface (reflecting and bending) helps determine how bright the light spot appears and where it is. Similarly, in optics, when light hits a spherical surface, the resulting image will vary based on the angles involved.

Geometry of Refraction

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Now for DNOC, i is the exterior angle. Therefore, i = ∠NOM + ∠NCM.

MN

tan ∠NOM =
OM
MN

tan ∠NCM =
MC
MN

tan ∠NIM =
MI

Now, for DNOC, i is the exterior angle. Therefore, i = ∠NOM + ∠NCM.

Similarly,
r = ∠NCM - ∠NIM.
i.e., r =
MC
MI

Now, by Snell’s law n₁ sin i = n₂ sin r or for small angles n₁ i = n₂ r.

Detailed Explanation

This chunk focuses on understanding angles of incidence (i) and refraction (r) in relation to the spherical surface. The text demonstrates the use of trigonometric functions (tan) to relate these angles to distances on the principal axis. By applying Snell's law, we establish a formula that relates the refractive indices of the two media and the angles involved, specifically for small angles of incidence and refraction, helping us predict how light bends when it crosses the interface between two different materials.

Examples & Analogies

Imagine you are swimming and you notice how your body appears to bend at the water's surface. When you look at your reflection, the angle at which you see your image is similar to the angles described here. The different densities of air and water cause this bending of light—just like the changing media in our spherical surface example.

Deriving the Relationship Between Distances

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Substituting i and r from Eqs. (9.13) and (9.14), we get:
n₁ n₁ n₁ - n₂ = 2 n₂ (9.15)
OM MI MC
Here, OM, MI and MC represent magnitudes of distances. Applying the Cartesian sign convention,
OM = -u, MI = +v, MC = +R. Substituting these in Eq. (9.15), we get: n₁ n₂ n₂ - n₁ = 2 n₁ (9.16)
v u R.

Detailed Explanation

This derivation integrates the formula we gathered for the angles of incidence and refraction and applies the Cartesian sign convention to define how we measure distances in our optical system. By substituting these distances into the equation gives us a direct relationship between the object and image distances (u and v) with respect to the radius of curvature (R) and the refractive indices (n₁ and n₂). It succinctly captures the complete picture of refraction at a spherical surface.

Examples & Analogies

Consider a fish tank viewed from above. When you look at the fish underwater, its position seems altered due to the bending of light from the water to the air. If you measure how far the fish actually is versus where it appears, these concepts come into play. The formulas we outlined give you a way to quantify those distances as light passes from water to air at varying angles.

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Refraction: The bending of light when it passes between media.

  • Refractive Index: A ratio that indicates how much light slows in a medium.

  • Snell's Law: A formula used to relate the angles and refractive indices of two media.

  • Radius of Curvature: Critical for determining how light will bend when passing through curved surfaces.

Examples & Real-Life Applications

See how the concepts apply in real-world scenarios to understand their practical implications.

Examples

  • A straw appears bent in a glass of water due to refraction at the water-air boundary.

  • The lens of a magnifying glass works by bending light to create a magnified image of an object.

Memory Aids

Use mnemonics, acronyms, or visual cues to help remember key information more easily.

🎵 Rhymes Time

  • Light bends and sways, through mediums it plays, refracting away from the normal, brightening our days.

📖 Fascinating Stories

  • Imagine a knight crossing rivers. In the shallow water, he walks straight but in deeper areas, he bends as the ground shifts beneath him. This bending behavior is similar to light refracting as it changes medium!

🧠 Other Memory Gems

  • To recall Snell's Law: 'No Sunny Rain' means n₁ * sin(i) = n₂ * sin(r).

🎯 Super Acronyms

RI for Refractive Index helps remind you of the relationship in speed of light in media.

Flash Cards

Review key concepts with flashcards.

Glossary of Terms

Review the Definitions for terms.

  • Term: Refraction

    Definition:

    The bending of light as it passes from one medium to another due to a change in its speed.

  • Term: Refractive Index

    Definition:

    A dimensionless number that describes how fast light travels in a medium compared to vacuum.

  • Term: Snell's Law

    Definition:

    The law that describes the relationship between the angles of incidence and refraction and the refractive indices of the two media.

  • Term: Object Distance

    Definition:

    The distance from the object to the optic center of the lens or mirror.

  • Term: Image Distance

    Definition:

    The distance from the image to the optic center of the lens or mirror.

  • Term: Radius of Curvature

    Definition:

    The radius of the sphere from which a spherical lens or mirror is made.
