Rayleigh’s Method for Approximate Frequency
Rayleigh’s method offers a convenient technique for estimating the fundamental frequency of a mechanical or structural system when detailed analysis is not required. The method utilizes the Rayleigh quotient, which is formulated as:
$$\omega^2 \approx \frac{{\{u\}^T [K]{u}}}{{1 \{u\}^T [M]{u}}$$
In the equation, {u} represents a trial shape function, typically derived from the system's static deflection under gravity. This approach not only simplifies frequency estimation but also serves as a useful tool for validating results obtained from software analyses. The advantages of Rayleigh's method include its applicability in hand calculations and its effectiveness in quickly assessing systems without requiring extensive computational resources.
