1.5 - COULOMB’S LAW
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Coulomb's Law
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today, we will explore Coulomb's Law, which describes the electrostatic force between two point charges. Can anyone tell me what a charge is?
A charge is a property of matter that causes it to experience a force in an electric field, right?
Exactly! And according to Coulomb's Law, the force between two charges can be calculated. This relationship states that the force F is directly proportional to the product of the magnitudes of the charges and inversely proportional to the square of the distance between them. We use this equation: F = k * (q1 * q2) / r^2. Does anyone remember what k stands for?
K is Coulomb's constant, right? It helps us measure the strength of the electric force between the charges.
Great! So, if we increase either of the charges or decrease the distance between them, what happens to the force?
The force increases because they are directly proportional.
Correct! And conversely, if we increase the distance, the force decreases. This is the inverse square relationship.
Understanding Electric Force
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now that we have a formula for Coulomb's Law, let's discuss what happens in real-life situations. Can someone give me an example of when we've observed electric forces?
When we rub a balloon on our hair, it sticks to the ceiling!
Exactly! Rubbing transfers charges, and the electric force between the charged balloon and the ceiling allows it to stay up. Now, what if we had two positively charged balloons? What would happen?
They would repel each other since like charges repel.
Right! This is a crucial point about electric forces: like charges repel, while unlike charges attract. Let's recap the mathematical representation once again.
Applications of Coulomb's Law
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now let's apply what we’ve learned. If we have two charges, q1 = 2 × 10^-6 C and q2 = 3 × 10^-6 C, separated by a distance of 0.5 m, how do we calculate the force between them?
We can plug it into Coulomb’s Law, right? F = k * (q1 * q2) / r^2.
Yes! What would that give us, using k = 9 × 10^9 N m²/C²?
... F would be approximately 0.108 N.
Correct! This allows us to quantitatively understand the electric forces acting between charges. Let’s summarize our key points about Coulomb’s Law.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
This section details Coulomb's Law, highlighting its mathematical formulation and experimental origins. It emphasizes the concepts of electric forces acting between point charges and discusses the law's significance in electrostatics.
Detailed
Coulomb's Law
Coulomb's Law is a fundamental principle in electrostatics that quantifies the force between two point charges. It states that the magnitude of the electrostatic force (F) between two charges, denoted as q1 and q2, is directly proportional to the product of the absolute values of the charges and inversely proportional to the square of the distance (r) between them:
$$ F = k \frac{q_1 q_2}{r^2} $$
Here, k is Coulomb's constant, approximately equal to $9 \times 10^9 \text{N m}^2 / \text{C}^2$ in SI units. This section also touches upon Coulomb's methods of measurements using a torsion balance, further illustrates the law's empirical foundations, and outlines its application in defining electric charge.
Notably, the directional nature of electric forces differentiates them into attractive or repulsive based on the signs of the charges involved. Furthermore, Coulomb's Law extends beyond mere numerical calculation; it encapsulates a foundational understanding of how electric forces behave in a vacuum and is crucial for exploring more complex electric interactions in future chapters.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Introduction to Coulomb's Law
Chapter 1 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Coulomb’s law is a quantitative statement about the force between two point charges. When the linear size of charged bodies are much smaller than the distance separating them, the size may be ignored and the charged bodies are treated as point charges.
Detailed Explanation
Coulomb's law defines how the force between two electric charges behaves. It tells us that if we have two small charges (like tiny dots) spaced apart, we can treat them as point charges, although they may be physically larger than a single point. This simplification allows us to use mathematics to determine how strong the force between them will be based on their charges and the distance separating them.
Examples & Analogies
Imagine two small magnets that are so tiny we can't see them, like really powerful pin magnets. When they are close together, they either attract or repel each other, depending on which poles face one another. Using Coulomb's law is like using a recipe that gives you the correct amount of force you will feel when you try to pull them apart or push them together.
Coulomb's Law Formula
Chapter 2 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Coulomb measured the force between two point charges and found that it varied inversely as the square of the distance between the charges and was directly proportional to the product of the magnitude of the two charges and acted along the line joining the two charges. Thus, if two point charges q1, q2 are separated by a distance r in vacuum, the magnitude of the force (F) between them is given by F = k * (q1 * q2) / r².
Detailed Explanation
The formula given by Coulomb's law shows two important relationships: the force between the two charges increases when the charges themselves increase (hence, directly proportional), and it decreases rapidly if we increase the distance between them (inversely proportional to the square of the distance). The constant 'k' depends on the medium between the charges; in a vacuum, it holds a specific value.
Examples & Analogies
Think about how gravity works—when you jump, the Earth pulls you down. But what if you step further away from the Earth? You would feel less pull. Just like that, when two electric charges are closer together, they feel a stronger 'push or pull' on each other, while that force weakens as you separate them further.
How Coulomb Derived the Law
Chapter 3 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Coulomb used a torsion balance for measuring the force between two charged metallic spheres. He varied the distance for a fixed pair of charges and measured the force for different separations. He then varied the charges in pairs, keeping the distance fixed for each pair. By comparing forces, Coulomb arrived at the relationship of force determined by charges and distance.
Detailed Explanation
Coulomb's method involved experimentation and measurement of forces acting on small metal spheres with different charges. By making careful adjustments to the distance between these charged spheres and recording the forces at play, he was able to derive a consistent relationship which we now call Coulomb's law. This process embodies the scientific method of hypothesizing, experimenting, and concluding.
Examples & Analogies
Imagine you are testing how strong a magnet is by pulling various metallic objects at different distances. You'd notice that as the object gets closer, it sticks faster and harder. That's similar to what Coulomb did but with charged metal instead. Each pull gives him a clue about how electric charge works.
Using the Constant k
Chapter 4 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Coulomb’s law can now provide a definition for a unit of charge. In SI units, the unit of charge is called a coulomb, denoted by the symbol C. In terms of this definition, one coulomb is defined as the charge giving a force of 9 × 109 N when separated by 1 m in a vacuum.
Detailed Explanation
The constant 'k' in Coulomb’s law lends itself to defining what a 'coulomb' is in practical terms. It allows calculations to be standardized so that we can use the formula across different scenarios, allowing us to quantify electric charge effectively.
Examples & Analogies
Think of 'k' as the measuring stick for electric charges. Just as a thermometer tells you how hot or cold it is, 'k' tells you the strength of the electric forces between charges. Therefore, when you hear about a coulomb, think of it as an amount of electric charge that creates a specific degree of influence over distance without having to guess.
Electric Field from Coulomb's Law
Chapter 5 of 5
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
The unit of electric field E is given by E = F/q, where F is the force experienced by a test charge 'q'. It can be expressed in vector form based on the position vectors of point charges.
Detailed Explanation
An electric field can be thought of as the effect of a charge in a given space. Using Coulomb’s law, we can compute how strong that field is based on the forces acting on the charges we place within it. This is fundamental in understanding how charges interact in broader contexts, like circuits or fields.
Examples & Analogies
Picture a light bulb illuminating a room. The electric field is like the light it radiates. You may place your hand in an electric field and feel a force, just the way you would have shadows grow bigger or smaller based on your position in relation to a light source. Just as light dissipates with distance, electric fields diminish with distance from the charge.
Key Concepts
-
Electrostatic Force: The force experienced between two charged objects due to their charges.
-
Proportional Relationships: The force varies directly with the product of the charges and inversely with the square of the distance between them.
-
Sign of Charges: Like charges repel and unlike charges attract.
-
Coulomb's Constant: This constant allows the computation of the magnitude of force in electric interactions.
Examples & Applications
Example of calculating the force between two charges using Coulomb's Law.
Real-life applications such as balloon sticking to a ceiling after rubbing with hair.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Coulomb's Law is the tool to find, the force between charges, close or far behind.
Stories
Imagine two balloons charged with static electricity. When they come near each other, they push away, showing how Coulomb's Law works in action.
Memory Tools
F = q1 * q2 over r squared. Remember it as the Formula for Force on a chair.
Acronyms
C-L-A-R
for Charge
for Law
for Attraction/Repulsion
for Relationship.
Flash Cards
Glossary
- Coulomb's Law
A law stating that the electrostatic force between two charges is directly proportional to the product of their charges and inversely proportional to the square of the distance between them.
- Electric Charge
A fundamental property of matter that produces electric effects; can be positive or negative.
- Electrostatic Force
The force between charged objects due to their electric charges.
- Point Charge
A charged particle that is so small that its size is negligible compared to the distance between it and other charges.
- Coulomb's Constant
The proportionality constant in Coulomb's Law, approximately equal to 9 × 10^9 N m²/C².
