11.5.2. Natural Equilibrium

Now let us understand the principles the how the concept is conceived. As we discussed that there will be a gravity force which will act the CG of the floating object and there will be the force which is a buoyant force will act as the CG of the displaced liquid that what will be the center of buoyancy. So these two force components act at two different location.

In fluid mechanics, natural equilibrium occurs when a floating object is supported by two forces: the gravitational force pulling it down and the buoyant force pushing it up. The center of gravity (CG) is where the weight of the object is concentrated, while the center of buoyancy is the centroid of the volume of fluid displaced by the object. When these two points align vertically, the object is in natural equilibrium. This means if the object is disturbed slightly, it will remain in its position without capsizing.

Think of a teeter-totter on a playground, which can be balanced if both children are of equal weight and sit at equal distances from the center. If one child shifts slightly, the teeter-totter will return to balance because the forces are equal. Similarly, a floating object finds its balance between gravity and buoyancy.

If I tilt it, a floating object to a angle of delta theta, then there will be a new waterlines will come it. That means the shape will change it like the for example, for this case, the will tilting this part. So new waterlines will come it. And because of that, the buoyancy, the center of buoyancy will change it from B to Î’.'

When a floating object is tilted, the waterline around it changes, which shifts the center of buoyancy from its original position. This change affects the stability of the object. The buoyant force remains directed upward through the new center of buoyancy, but the position where this force acts is different than when the object is upright. The angle of tilt (delta theta) can either stabilize the object or lead it toward capsizing, depending on the relationship between the metacenter and the center of gravity.

Imagine a can of soda floating in a pool. When the can is upright, it floats steadily. If someone presses down one side, the can tilts, and the waterline changes. Now, the soda can might feel like it could capsized, similar to how a ship can become unstable if tilted too much.

Now let us discuss about this three equilibrium concepts. Natural equilibrium, stable equilibrium, and unstable equilibrium. So you can understand it if somebody wants to design a ship he has to find out the ship should have stable equilibrium conditions.

Designing floating objects, like ships, involves understanding three types of equilibrium. The metacenter (M) is crucial here; it's the point where the buoyancy force acts when tilted. If the metacenter is above the center of gravity (G), the vessel is stable. If G is above M, the ship is unstable and risks capsizing. A natural equilibrium exists when both points coincide, meaning the object maintains its position regardless of disturbances.

Consider a ball resting in a bowl: if you displace it slightly, it rolls back to the center (stable equilibrium). Now imagine it balancing on a dome: a little push sends it rolling off (unstable). Ships aim to be like the bowl, returning to the center after being disturbed.

Now how to compute this the metacentric height? Let you have a floating object like this, okay? And you consider the unit width of this ones which is a perpendicular to this surface that is what unit width is there.

To find the metacentric height, which determines the stability of a floating object, you consider its geometry and the buoyant force acting on it. The metacentric height (MG) can be calculated by analyzing the moment of the fluid displaced as the object tilts. By graphically and mathematically determining the distances between the center of gravity, center of buoyancy, and the metacenter, engineers can decide if the vessel will return to upright after a tilt.

Think of how you would balance a ruler on your finger. If you place your finger under the center of the ruler, it stays balanced. If you move your finger closer to one end, the ruler tips over. Similarly, understanding where to position weights on a ship is crucial to keeping it steady.

--
