4.3. Water Jet Impinging on a Flat Plate

Now let us apply the mass conservation equation where inflow minus outflow and this case will be, Outflow = Inflow. Incompressible flow ρA1V1 = ρA2V2

The mass conservation equation tells us that the mass flow rate (mass per time) entering a system must equal the mass flow rate leaving the system if there are no changes in mass within the system. In terms of a water jet hitting a plate, the mass flow of water coming in from the jet (inflow) must equal the mass flow of water leaving the plate (outflow). In cases of incompressible flow, this relationship also incorporates the density and velocity of the fluid, denoting that the product of area and velocity at the inlet must match that at the outlet.

Think of a garden hose filling up a bucket. Water flows in from the hose (inflow), and if you have a small opening at the bottom of the bucket, water flows out (outflow). The amount flowing in must equal the amount flowing out if the bucket isn’t overflowing.

Now we have to find out what is the force acting in the x and y directions, applying Reynolds transport theorem and simplifying the results. The change of the momentum flux within the control volume is significant.

To calculate the force on the plate due to the water jet, we apply the Reynolds transport theorem, which relates the change in momentum in the control volume to the momentum flowing into and out of that volume. When the jet hits the plate, it exerts a force due to the change in momentum of the water as it comes to rest upon hitting the plate. This momentum change leads to a pressure force, which we can calculate using quantities like fluid density, jet velocity, and area of impact.

Imagine a basketball hitting a wall. The basketball has a certain speed and momentum before it hits the wall, and when it strikes the wall, it comes to a stop. The force exerted on the wall is not just due to the basketball itself but also because of how quickly it stops (the change in momentum).

Let us take an example of a water jet impinging on a flat plate that moves to the right with velocity V_c. The water jet velocity V_j is given as 20 m/s, and the plate velocity is 15 m/s. The density and area are also provided.

In this case, we need to calculate the force required to keep the plate moving at a constant velocity. As the water jet strikes the plate, it splits into two halves moving up and down, and we need to consider the mass inflow and outflow rates, as well as any change in momentum. With the known velocities of the jet and the plate, we can find the force using conservation principles and momentum equations, ensuring we account for the effective velocities and areas involved.

Imagine a flat boat on a river. If two people are pouring water from the sides of the boat, the rate at which water flows into the boat from the river must equal the rate flowing out. If one side of the boat begins to tip due to too much weight, just like the plate reacting to the water jet, the force to push it back to an upright position can be calculated by looking at how fast the water is coming in and out.

This example can be classified as two-dimensional, steady flow, turbulent, and incompressible.

Flow classification helps in simplifying the analysis of fluid behavior. In this scenario, the flow of the jet is two-dimensional, as we can analyze it in the x and y directions separately. It is considered steady because the properties of the fluid do not change over time at a given location. Turbulent flow indicates chaotic fluid movement, which is typical for high-velocity jets, while incompressible flow assumes the density of the fluid remains constant throughout the jet’s motion.

Imagine when you stir a thick soup. The chaotic movement of the spoon creates turbulence in the soup. If you consider just the top surface moving steadily, that would resemble steady flow. However, take a close look, and you would see how the flow is changing speed and direction in different spots, just like the turbulent flow in a water jet.

--
