14.2.1 - On the basis of conductivity

Interactive Audio Lesson

Listen to a student-teacher conversation explaining the topic in a relatable way.

Classification of Materials

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Today, we'll learn how we classify materials based on their conductivity. What do you think would define a metal?

Student 1
Student 1

I think metals conduct electricity very well.

Teacher
Teacher

Exactly! Metals have very low resistivity. Can anyone tell me the resistivity range for metals?

Student 2
Student 2

It’s from 10<sup>-2</sup> to 10<sup>-8</sup> Ω·m.

Teacher
Teacher

Perfect! Now, what about semiconductors? How do they differ from metals?

Student 3
Student 3

They are not as good at conducting as metals.

Teacher
Teacher

Correct! Their resistivity is between 10<sup>-5</sup> and 10<sup>6</sup> Ω·m. This means they can conduct under certain conditions. Remember, we can use the acronym 'MIS' to remember: M for Metals, I for Insulators, and S for Semiconductors.

Student 4
Student 4

What about insulators?

Teacher
Teacher

Good question! Insulators have high resistivity, from 10<sup>11</sup> to 10<sup>19</sup> Ω·m, which prevents them from conducting electricity.

Teacher
Teacher

In summary, metals conduct well, semiconductors act as middle-ground, and insulators resist the flow of electricity. Great job, everyone!

Properties of Semiconductors

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Now let’s focus on semiconductors. They can be classified into elemental and compound types. Who can name an example of each?

Student 1
Student 1

Elemental semiconductors like silicon and germanium, and compound semiconductors like GaAs and CdS!

Teacher
Teacher

Excellent! And why are we particularly interested in semiconductors?

Student 2
Student 2

They are used in electronic devices!

Teacher
Teacher

Right! Their ability to conduct electricity can be enhanced by doping. Does anyone know what doping means in this context?

Student 3
Student 3

It’s adding impurities to change their conductivity.

Teacher
Teacher

Exactly! We can think of it as 'tweaking' the semiconductor to improve its performance. Let's summarize: Elemental semiconductors conduct naturally, and we can enhance their conductivity through doping. Great teamwork, class!

Differences between Metals, Semiconductors, and Insulators

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Let's compare metals, semiconductors, and insulators. What key differences should we focus on?

Student 4
Student 4

Their resistivity and conductivity levels!

Teacher
Teacher

Correct! Metals have low resistivity and high conductivity, while insulators are the opposite. Can anyone explain what intermediate conductivity means in semiconductors?

Student 2
Student 2

It means they can either conduct or insulate, depending on conditions like temperature!

Teacher
Teacher

Great observation! They can switch between conducting and insulating states based on how they're manipulated. As an easy way to remember, think of it this way: 'Metals flow easily, insulators resist, and semiconductors can adapt!'

Student 1
Student 1

That makes it easy to remember!

Teacher
Teacher

Indeed! Always remember the pivotal roles each type plays in modern technology.

Introduction & Overview

Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.

Quick Overview

This section discusses the classification of materials based on their electrical conductivity and the characteristics of metals, semiconductors, and insulators.

Standard

The section categorizes materials as metals, semiconductors, and insulators according to their resistivity and conductivity values. It details the unique properties of semiconductors, including elemental and compound types, and introduces the significance of doping in enhancing semiconductor conductivity.

Detailed

Detailed Summary

In this section, materials are categorized based on their electrical conductivity into three main classes: metals, semiconductors, and insulators. Metals exhibit very low resistivity and high conductivity, with resistivity in the range of 10-2 to 10-8 Ω·m, and conductivity varying between 102 to 108 S/m. Semiconductors possess intermediate resistivity (10-5 to 106 Ω·m) and conductivity (105 to 10-6 S/m), allowing them to conduct electricity under certain conditions, particularly when doped with impurities. Insulators have high resistivity (1011 to 1019 Ω·m) and low conductivity (10-11 to 10-19 S/m).

Semiconductors can be further divided into elemental (like silicon and germanium) and compound semiconductors (like GaAs and CdS). The section highlights how doping, or adding impurities, can significantly influence the conductivity of semiconductors, which is vital for the functioning of various electronic devices.

Youtube Videos

12th Physics | Chapter 16 | Semiconductor Devices | Lecture 1 | Maharashtra Board |
12th Physics | Chapter 16 | Semiconductor Devices | Lecture 1 | Maharashtra Board |
Semiconductor Electronics Class 12 Physics | NCERT Chapter 14 | CBSE JEE NEET | One Shot
Semiconductor Electronics Class 12 Physics | NCERT Chapter 14 | CBSE JEE NEET | One Shot
Introduction of Semiconductor Electronics Materials, Devices and Simple Circuits | Class 12 Physics
Introduction of Semiconductor Electronics Materials, Devices and Simple Circuits | Class 12 Physics
Semiconductor Electronics:Materials, Devices Class 12 Physics One Shot | New NCERT Chapter 14 |CBSE
Semiconductor Electronics:Materials, Devices Class 12 Physics One Shot | New NCERT Chapter 14 |CBSE
Semiconductor|| N-Type and P-Type || 3d animated full explanation || Electronic Devices || 12 Class
Semiconductor|| N-Type and P-Type || 3d animated full explanation || Electronic Devices || 12 Class
SEMICONDUCTOR ELECTRONICS in 75 Minutes | Physics Chapter - 14 | Full Chapter Revision Class 12th
SEMICONDUCTOR ELECTRONICS in 75 Minutes | Physics Chapter - 14 | Full Chapter Revision Class 12th
Semiconductor in 14 mins 😱🔥 Ch 14 Physics Class 12 Boards 2024 | Score 95+ Physics | Zaki Bhaiyya
Semiconductor in 14 mins 😱🔥 Ch 14 Physics Class 12 Boards 2024 | Score 95+ Physics | Zaki Bhaiyya
Semiconductor Electronics : Materials, Devices and Simple Circuits |NEET |IIT-JEE | CBSE | Class -12
Semiconductor Electronics : Materials, Devices and Simple Circuits |NEET |IIT-JEE | CBSE | Class -12
SEMICONDUCTOR CLASS 12 PHYSICS FORMULA NOTES ☑☑
SEMICONDUCTOR CLASS 12 PHYSICS FORMULA NOTES ☑☑
Semiconductor Electronics: Materials, Devices & Simple Circuits Tamil | Concepts & 10 Years PYQs
Semiconductor Electronics: Materials, Devices & Simple Circuits Tamil | Concepts & 10 Years PYQs

Audio Book

Dive deep into the subject with an immersive audiobook experience.

Classification of Solids by Conductivity

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

On the basis of the relative values of electrical conductivity (s) or resistivity (r = 1/s), the solids are broadly classified as: (i) Metals: They possess very low resistivity (or high conductivity). r ~ 10–2 – 10–8 W m s ~ 102 – 108 S m–1 (ii) Semiconductors: They have resistivity or conductivity intermediate to metals and insulators. r ~ 10–5 – 106 W m s ~ 105 – 10–6 S m–1 (iii) Insulators: They have high resistivity (or low conductivity). r ~ 1011 – 1019 W m s ~ 10–11 – 10–19 S m–1.

Detailed Explanation

This chunk introduces the classification of materials based on their electrical conductivity. It explains three categories: metals, semiconductors, and insulators, along with the numerical ranges for their resistivity (r) and conductivity (s). Metals are characterized by significantly low resistivity, allowing them to conduct electricity easily. Semiconductors have a resistivity that falls between that of metals and insulators, making them versatile for electronic applications. Insulators have very high resistivity, preventing them from conducting electricity under normal conditions.

Examples & Analogies

Think of metals as highways where cars (electrons) can speed through with little resistance. Semiconductors are like dirt paths where some cars can drive, but only under certain conditions, like when the weather is right (like heat or light). Insulators are more like thick forest paths where cars can't really go at all.

Types of Semiconductors

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Our interest in this chapter is in the study of semiconductors which could be: (i) Elemental semiconductors: Si and Ge (ii) Compound semiconductors: Examples are: • Inorganic: CdS, GaAs, CdSe, InP, etc. • Organic: anthracene, doped pthalocyanines, etc. • Organic polymers: polypyrrole, polyaniline, polythiophene, etc.

Detailed Explanation

This chunk delves deeper into semiconductors, identifying two main types: elemental semiconductors, like silicon (Si) and germanium (Ge), and compound semiconductors, which are made from more than one element. The examples provided include both inorganic and organic semiconductors, highlighting the diversity in semiconductor materials. These materials have unique properties that allow for various electronic applications, from simple diodes to complex integrated circuits.

Examples & Analogies

Imagine elemental semiconductors like single-family homes (Si and Ge), simple and straightforward. In contrast, compound semiconductors are like apartment complexes (like CdS and GaAs), where multiple families (elements) share resources. Each type of structure serves its purpose in the neighborhood of technology, providing different capabilities based on their construction.

Doping and Its Effects on Semiconductors

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Most of the currently available semiconductor devices are based on elemental semiconductors Si or Ge and compound inorganic semiconductors. However, after 1990, a few semiconductor devices using organic semiconductors and semiconducting polymers have been developed signalling the birth of a futuristic technology of polymer-electronics and molecular-electronics.

Detailed Explanation

This chunk discusses the practical applications of the aforementioned semiconductor materials and the emergence of new technologies through doping. Doping involves adding impurities to intrinsic semiconductors to enhance their electrical properties. This process creates two main semiconductor types: p-type (positive carrier) and n-type (negative carrier), allowing for improved conductivity and functionality. The mention of organic semiconductors illustrates the ongoing advancement in the semiconductor field, paving the way for future electronic innovations.

Examples & Analogies

Think about how adding sugar to coffee changes its flavor — that’s similar to doping in semiconductors! Just as a touch of sugar improves the coffee's sweetness, adding certain elements to semiconductors enhances their ability to conduct electricity, leading to new types of technologies that could change how we use electronics.

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Conductivity: The ability to conduct electric current, varies from metals to insulators.

  • Resistivity: The opposition to the flow of electric current, inversely related to conductivity.

  • Doping: Introducing impurities into semiconductors to enhance their conductivity.

Examples & Real-Life Applications

See how the concepts apply in real-world scenarios to understand their practical implications.

Examples

  • Silicon (Si) and Germanium (Ge) are the most common elemental semiconductors used in electronic devices.

  • Doping silicon with phosphorus (a pentavalent atom) creates an n-type semiconductor, while doping it with boron (a trivalent atom) creates a p-type semiconductor.

Memory Aids

Use mnemonics, acronyms, or visual cues to help remember key information more easily.

🎵 Rhymes Time

  • Metals conduct with ease, semiconductors please; Insulators hold tight, keeping currents out of sight.

📖 Fascinating Stories

  • Imagine a race where metals sprint ahead, semiconductors jog at a steady pace, while insulators sit quietly in the corner, refusing to participate.

🧠 Other Memory Gems

  • M.I.S. – Metals, Insulators, Semiconductors: Remember the conductivity classes in order.

🎯 Super Acronyms

Remember 'MICE' for Metals, Insulators, Conductors, and Elemental semiconductors.

Flash Cards

Review key concepts with flashcards.

Glossary of Terms

Review the Definitions for terms.

  • Term: Metals

    Definition:

    Materials with very low resistivity and high conductivity, typically in the range of 10-2 to 10-8 Ω·m.

  • Term: Semiconductors

    Definition:

    Materials with intermediate resistivity, ranging from 10-5 to 106 Ω·m, that can conduct electricity under certain conditions.

  • Term: Insulators

    Definition:

    Materials with very high resistivity, exceeding 1011 Ω·m, that do not conduct electricity.

  • Term: Conductivity

    Definition:

    The ability of a material to conduct electric current, often denoted by σ.

  • Term: Resistivity

    Definition:

    A measure of how strongly a material opposes the flow of electric current, usually denoted by ρ.

  • Term: Doping

    Definition:

    The process of intentionally adding impurities to a semiconductor to change its electrical properties.
