4.2.3 - Magnetic force on a current-carrying conductor

Interactive Audio Lesson

Listen to a student-teacher conversation explaining the topic in a relatable way.

Force on a Straight Conductor

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Today, we're going to discuss the magnetic force acting on a straight current-carrying conductor when it is placed in a magnetic field. Who can tell me the force acting on a charge in a magnetic field?

Student 1
Student 1

Isn't it the Lorentz force?

Teacher
Teacher

Exactly! For a charge q moving with velocity v in a magnetic field B, it experiences a force F given by F = q(v × B). Now, when we talk about multiple charges in a conductor, we integrate that to find the force on the conductor itself. Can anyone tell me how the current I is related to these charge carriers?

Student 2
Student 2

The current I equals the charge q moving per unit time.

Teacher
Teacher

Very good! So, if we have a conductor of length l carrying a current I, placed in a magnetic field B, what would be the total magnetic force?

Student 3
Student 3

The force would be F = Il × B.

Teacher
Teacher

Correct! The direction of the force can be determined using the right-hand rule. Remember, the force is always perpendicular to both the current and the magnetic field.

Student 4
Student 4

So, it's like a cross product?

Teacher
Teacher

Yes, that's a great way to remember it! The right-hand rule helps us visualize that. Can someone summarize what we just learned?

Student 1
Student 1

We learned the relationship F = Il × B, and how to use the right-hand rule for direction!

Application of Force on Current-Carrying Conductors

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Now let's dive into some practical applications. Consider a wire suspended in a magnetic field. If the force is equal to the weight of the wire, how would we calculate B?

Student 2
Student 2

For example, if the wire's weight is mg and we're using F = IlB, we can set mg = IlB!

Teacher
Teacher

Perfect! In such cases where the wire is in equilibrium, you can rearrange that equation to find B. Can anyone apply that to an example problem?

Student 3
Student 3

If we have a wire of mass 0.200 kg and length 1.5 m carrying 2 A of current, we can solve for B using B = mg / (Il).

Teacher
Teacher

Exactly! What value do you get for B?

Student 3
Student 3

Calculating that gives B = 0.65 T.

Teacher
Teacher

Excellent work! This application shows why understanding magnetic forces is essential in technology like motors. What are the key points we discussed today?

Student 4
Student 4

We learned how to calculate the magnetic field needed to balance a wire's weight and that F = Il × B is a core principle here.

Effect of Current Direction on Force

Unlock Audio Lesson

Signup and Enroll to the course for listening the Audio Lesson

Teacher
Teacher

Let's delve into how the direction of current affects the force exerted on a conductor. What happens if we reverse the current direction?

Student 1
Student 1

The direction of the force would reverse too!

Teacher
Teacher

Exactly! This is central to understanding motors - reversing current changes the direction of force and, consequently, rotation. Can you think of examples where this is crucial?

Student 2
Student 2

Electric motors in appliances like fans?

Teacher
Teacher

That's right! The ability to control direction through current manipulation allows for motion control in devices. Remember the right-hand rule I mentioned, how does that apply here?

Student 3
Student 3

It lets us visualize force direction based on current and magnetic field polarity.

Teacher
Teacher

Great summary! As you study further, always relate these principles to real-world applications. Review what we've learned today.

Student 4
Student 4

Force direction changes with current direction due to the right-hand rule, and it's key in motor design!

Introduction & Overview

Read a summary of the section's main ideas. Choose from Basic, Medium, or Detailed.

Quick Overview

This section discusses how a current-carrying conductor experiences a magnetic force when placed in an external magnetic field.

Standard

By extending the principles of the Lorentz force from moving charges to current-carrying conductors, this section explains the net magnetic force acting on a straight conductor. It also emphasizes the relationship between current, magnetic field, and force exerted on the conductor.

Detailed

Magnetic Force on a Current-Carrying Conductor

In this section, we explore the magnetic force exerted on a straight conductor carrying an electric current when placed in an external magnetic field. This force can be derived from the effects of the magnetic field on the charge carriers within the conductor. The key relationship is defined by the equation:

F = Il × B

where F is the force, I is the current, l is the length vector of the conductor, and B is the magnetic field. As we analyze a uniform cross-section conductor of length l, the mobile charge carriers, typically electrons, create a net current I, which interacts with the magnetic field B. The direction of the force is determined by the right-hand rule, indicating that the force is perpendicular to both the length of the conductor and the direction of the magnetic field.

This section also discusses the special case of a wire with arbitrary shape, where the total force can be determined by integrating the local force contributions along the wire. Examples are provided to illustrate the application of these concepts, such as calculating the magnitude of the magnetic field needed to suspend a current-carrying wire. Understanding these principles is essential for various applications in electromagnetism, including the design of motors and generators.

Youtube Videos

Magnetic force on a Current carrying wire | Moving charges and magnetism | 12 Physics #cbse
Magnetic force on a Current carrying wire | Moving charges and magnetism | 12 Physics #cbse
Physics Moving Charge & Magnetism part 7 (Force on current carrying conductor) CBSE class 12
Physics Moving Charge & Magnetism part 7 (Force on current carrying conductor) CBSE class 12
Moving Charges n Magnetism 07 : Force on a Moving Charge in Magnetic Field : Magnetic Force JEE/NEET
Moving Charges n Magnetism 07 : Force on a Moving Charge in Magnetic Field : Magnetic Force JEE/NEET
12th class physics chapter 4 moving charges and magnesium one shot PW..
12th class physics chapter 4 moving charges and magnesium one shot PW..
Force on Conductor Carrying Current in Magnetic Field | Class 12 Physics Chapter 4 (2023-24)
Force on Conductor Carrying Current in Magnetic Field | Class 12 Physics Chapter 4 (2023-24)
magnetic fields lines of solenoid #shorts #class10science #scienceexperiment
magnetic fields lines of solenoid #shorts #class10science #scienceexperiment

Audio Book

Dive deep into the subject with an immersive audiobook experience.

Force on a Current-Carrying Rod

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

We can extend the analysis for force due to magnetic field on a single moving charge to a straight rod carrying current. Consider a rod of a uniform cross-sectional area A and length l. We shall assume one kind of mobile carriers as in a conductor (here electrons). Let the number density of these mobile charge carriers in it be n. Then the total number of mobile charge carriers in it is nlA. For a steady current I in this conducting rod, we may assume that each mobile carrier has an average drift velocity v.

Detailed Explanation

This first part introduces how we can think about the force experienced by a straight conductor carrying an electric current. The rod has a certain length (l) and a cross-sectional area (A). Inside this rod, there are charges (like electrons) that are free to move. We refer to the concentration of these moving charges as number density (n). When a steady current (I) flows through the rod, it means that there is a constant flow of these charges. The drift velocity (v) is the average speed at which these charge carriers are moving in the direction of the current. Together, we can calculate the force acting on the charges due to the external magnetic field.

Examples & Analogies

Imagine a water pipe: the water flowing through the pipe can be thought of like the current in a conductor. The speed of the water is like the drift velocity of the charge carriers. Just as more water pressure can push more water through the pipe faster, increasing the current increases the movement of charge carriers within the conduction rod.

Force Calculation in Magnetic Field

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

In the presence of an external magnetic field B, the force on these carriers is given by: F = (nlA)qv ····· B where q is the value of the charge on a carrier. Now nqv is the current density j and |(nq v )|A is the current I. Thus, F = IlB, where l is a vector of magnitude l, the length of the rod, and with a direction identical to the current I.

Detailed Explanation

This chunk delves into the calculation of the magnetic force acting on the current-carrying rod. When we apply a magnetic field (B), each charge (with charge q) experiences a force. By multiplying the total number of charge carriers, their charge, and the drift velocity, we arrive at the expression for the total magnetic force (F). We also explain the relation of the current density j (which is the current per unit area) to the overall current (I). This leads to the simplified equation for force owing to the magnetic field, F = IlB, where 'l' denotes the length of the rod, giving us both magnitude and direction of the force.

Examples & Analogies

Think of a boat with oars. If you apply a force against the water (analogous to the magnetic field), the more oars (current) you have, the more force you can exert. The oars represent the charge carriers, and as you row faster (increase the drift velocity), the boat moves back more powerfully against the water, just like the force, which is dependent on the amount of current flowing.

Force on a Wire with Arbitrary Shape

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

If the wire has an arbitrary shape we can calculate the Lorentz force on it by considering it as a collection of linear strips dl and summing jF = ∑Idl × B. This summation can be converted to an integral in most cases.

Detailed Explanation

In this section, we discuss how when we have a wire that is not straight but has a complex shape, we can still calculate the magnetic force acting on it. We break down the wire into tiny segments (dl) and consider the force acting on each segment individually. By summing up these contributions across the entire wire using the Lorentz force equation, we can understand how the overall force on the wire is determined. This method of summing forces is also often simplified using integral calculus, hence making calculations easier for complex shapes.

Examples & Analogies

Imagine a winding river. Even though the river bends and turns (like our arbitrarily shaped wire), we can imagine breaking it into small sections. By observing how water flows and reacts at each section, we can predict how the overall flow behaves. Much like calculating the force acting on each little segment of wire to see how they all combine to give the total force.

Examples of Magnetic Force on Conductors

Unlock Audio Book

Signup and Enroll to the course for listening the Audio Book

Example 4.1: A straight wire of mass 200 g and length 1.5 m carries a current of 2 A. It is suspended in mid-air by a uniform horizontal magnetic field B. What is the magnitude of the magnetic field? Example 4.2: If the magnetic field is parallel to the positive y-axis and the charged particle is moving along the positive x-axis, which way would the Lorentz force be for (a) an electron (negative charge), (b) a proton (positive charge).

Detailed Explanation

Examples provided illustrate how to apply the concepts we just discussed. In Example 4.1, we're asked to find the strength of the magnetic field needed to suspend a current-carrying wire. The logic involves balancing forces—the upward magnetic force must equal the downward gravitational force acting on the wire. Example 4.2 helps visualize how charges behave in magnetic fields, emphasizing the direction of the Lorentz force based on charge type and motion direction (using the right-hand rule to find the force direction). These examples reinforce understanding through practical visualization of magnetic force concepts.

Examples & Analogies

For Example 4.1, think of balancing a seesaw. The weight on one side (gravitational force) must be lifted by the other side (magnetic force from the field) for it to stay level. In Example 4.2, consider how a roller-coaster propels passengers around a loop; the direction of motion (like current direction) and the influence of magnetic forces must work in tandem to ensure they don’t fall out, drawing an analogy to how charged particles react in fields.

Definitions & Key Concepts

Learn essential terms and foundational ideas that form the basis of the topic.

Key Concepts

  • Magnetic Force: The force acting on a current-carrying conductor in a magnetic field.

  • Lorentz Force: The overall force on a charged particle due to electric and magnetic fields.

  • Right-Hand Rule: A method for determining the direction of the magnetic force.

Examples & Real-Life Applications

See how the concepts apply in real-world scenarios to understand their practical implications.

Examples

  • A wire carrying a current of 3 A in a magnetic field of 0.5 T experiences a force of 15 N.

  • A horizontal wire carrying 4 A in a magnetic field of 0.2 T at an angle of 90° experiences a maximum force.

  • In an electric motor, a current-carrying wire within a magnetic field rotates due to magnetic forces.

Memory Aids

Use mnemonics, acronyms, or visual cues to help remember key information more easily.

🎵 Rhymes Time

  • To remember the force on a wire in the flow, IlB will show where the currents go.

📖 Fascinating Stories

  • Imagine a race where a wire carries a current. As it moves through a magnetic field, it feels forces pushing it in different ways, showcasing how current verses force interact.

🧠 Other Memory Gems

  • For magnetic force: I = Current, l = Length, B = Magnetic field. Remember 'ILB' to keep them in line.

🎯 Super Acronyms

ILF

  • Current (I)
  • Length (l)
  • Field (B) = Force on a wire.

Flash Cards

Review key concepts with flashcards.

Glossary of Terms

Review the Definitions for terms.

  • Term: Current (I)

    Definition:

    The flow of electric charge, measured in amperes (A).

  • Term: Magnetic Field (B)

    Definition:

    A vector field around magnetic materials and electric currents, influencing other charges and currents.

  • Term: Lorentz Force

    Definition:

    The combination of electric and magnetic forces on a charged particle.

  • Term: RightHand Rule

    Definition:

    A mnemonic for determining the direction of the magnetic force, current, and magnetic field.

  • Term: Force on a Conductor

    Definition:

    The magnetic force experienced by a conductor carrying an electric current in a magnetic field.
