1.3.1 - Newton's Law of Viscosity
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Viscosity
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Welcome, class! Today we will explore viscosity, an essential property of fluids. Can anyone tell me what viscosity means?
Is it how thick or sticky a fluid is?
Exactly! Viscosity measures a fluid's resistance to flow. Thicker fluids have higher viscosity. We use the symbol 'μ' for dynamic viscosity. Let's use a memory aid: 'VISCOSITY' can remind us of 'Very Important: Sticky, Colorful, Oil, Slime, Ice, and Water Together, Yummy!'
So how does viscosity affect fluid flow?
Great question! Higher viscosity means that more shear stress is needed to move the fluid. This is the foundation of Newton's Law of Viscosity.
Newton's Law of Viscosity
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now, let's discuss Newton's Law. It states that shear stress is proportional to the velocity gradient. Can anyone recall the formula?
Is it τ = μ (du/dy)?
Correct! What do each of the symbols represent?
τ is shear stress, μ is dynamic viscosity, and du/dy is the velocity gradient!
Excellent! Remember, this relationship helps us analyze how layers of fluid move relative to one another. An important memory aid is to think of ‘Shoe-on-sandpaper’ - the more pressure you exert, the more difficult it becomes to slide your shoe!
Applications of Viscosity
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Can anyone think of real-world applications of viscosity?
Like in lubrication for engines?
Exactly! Viscosity is crucial in selecting lubricants. It's also important in food production, paints, and much more. Understanding viscosity helps engineers design systems that involve fluid flow.
Good to know! Does that mean we always measure or calculate viscosity in engineering?
Yes! And remember: the Poiseuille Law, which relates to laminar flow, depends on viscosity too. A mnemonic for this could be 'Pipe on a smooth road' for smooth fluids.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
This section explains Newton's Law of Viscosity, which establishes a direct relationship between shear stress and velocity gradient for fluid motion. It delves into concepts such as dynamic viscosity, laminar flow, and related equations, providing a foundation for understanding fluid behavior under different conditions.
Detailed
Detailed Summary of Newton's Law of Viscosity
Newton's Law of Viscosity states that the shear stress between adjacent fluid layers is proportional to the rate at which they slide past each other, commonly expressed mathematically as:
$$ \tau = \mu \frac{du}{dy} $$
Where:
- $\tau$ is the shear stress,
- $\mu$ is the dynamic viscosity,
- $\frac{du}{dy}$ is the velocity gradient.
Dynamic viscosity ($\mu$) characterizes the frictional forces within the fluid. A high viscosity corresponds to a thicker fluid (like honey), while a low viscosity denotes a thinner fluid (like water). This section is crucial as it lays the groundwork for understanding how fluids behave under various conditions, highlighting concepts such as capillarity, pressure distribution, and the force exerted by static fluids. Thus, it enables students to analyze fluid movement in engineering applications and real-world scenarios effectively.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
Introduction to Newton's Law of Viscosity
Chapter 1 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Newton's laws of viscosities establish the relationship between shear stress and the velocity gradient.
Detailed Explanation
Newton's law of viscosity describes how a fluid's viscosity operates. It tells us that the force (shear stress) required to move one layer of fluid over another is proportional to the rate at which the layers slide past each other (velocity gradient). The law can be mathematically expressed as:
$$ \tau = \mu \frac{du}{dy} $$
Where:
- \( \tau \) (tau) is the shear stress,
- \( \mu \) (mu) is the dynamic viscosity,
- \( {du}/{dy} \) is the velocity gradient, which measures how quickly the speed of the fluid changes with respect to distance. This relationship is fundamental when analyzing fluid behavior under different conditions, especially in engineering applications.
Examples & Analogies
Imagine spreading honey on a piece of toast. If you apply a small force, the honey moves slowly due to its high viscosity. If you try to spread water with the same effort, it flows much faster because it has a lower viscosity. This behavior illustrates Newton's law of viscosity: different fluids have different responses to applied shear stress based on their viscosity.
Dynamic Viscosity
Chapter 2 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
Dynamic viscosity (μ) is a measure of a fluid's resistance to flow or deformation.
Detailed Explanation
Dynamic viscosity is an essential property of fluids that quantifies how resistant a fluid is to flow when subjected to shear stress. It signifies how thick or thin a fluid is. A high dynamic viscosity means the fluid is thick, such as oil or honey, while a low value indicates a thin fluid, like water or alcohol. Viscosity can change with temperature—heating a fluid generally reduces its viscosity, allowing it to flow more freely. This relationship is important in various applications, from lubrication to chemical processing.
Examples & Analogies
Think about a pipe. When you pour thick syrup into a pipe, it flows much slower compared to pouring water. The syrup's high viscosity causes it to resist flow more than water does. In practical terms, using a thicker lubricant in machinery can help reduce wear, but it may also require more energy to pump through the system.
Shear Stress and Velocity Gradient
Chapter 3 of 3
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
This relationship established by Newton allows us to derive other fluid properties, such as capillary height in terms of the diameter of the capillary tube.
Detailed Explanation
The relationship established by Newton's law of viscosity helps derive important phenomena in fluid mechanics, particularly for systems involving small diameters, like capillary tubes. Capillarity describes how liquid rises or falls in a narrow passage due to adhesive forces between liquid molecules and the walls of the tube. The formula for capillary rise is derived from balancing the weight of the liquid column with the surface tension acting along the liquid's perimeter. The height (h) to which a liquid rises in a capillary tube can be represented by:
$$ h = \frac{2\sigma \cos(\theta)}{\rho g r} $$
Where:
- \( \sigma \) is the surface tension,
- \( \theta \) is the contact angle,
- \( \rho \) is the fluid's density,
- \( g \) is acceleration due to gravity,
- \( r \) is the radius of the capillary tube.
Examples & Analogies
Visualize how a paper towel absorbs water. The water moves up through the towel's fibers, demonstrating capillary action. This occurs because the adhesive forces between the water and the fibers (wall) are stronger than the cohesive forces between the water molecules, allowing it to rise in the towel, similar to how it would rise in a capillary tube.
Key Concepts
-
Dynamic Viscosity: The characteristic that defines a fluid's internal resistance to flow.
-
Shear Stress: Represents the force per area that causes fluid layers to slide against one another.
-
Velocity Gradient: Key to understanding how viscosity influences fluid motion.
Examples & Applications
Cooking oil has a higher viscosity than water, meaning it flows slower.
Thick syrup has a significant viscosity affecting how it flows out of a container.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
Viscosity, oh so thick, Fluid's resistance is the trick!
Stories
Imagine a race between water and honey. The honey struggles to flow, revealing its high viscosity while water dances gracefully. This shows how viscosity affects fluid behavior.
Memory Tools
Think of VISCOSITY as Very Important: Sticky, Colorful, Oil, Slime, Ice, and Water Together, Yummy!
Acronyms
Remember 'VS' for 'Viscosity signifies' understanding fluid behavior!
Flash Cards
Glossary
- Viscosity
A measure of a fluid's resistance to flow or deformation.
- Dynamic Viscosity (μ)
The coefficient of viscosity for a fluid, quantifying its internal resistance to flow.
- Shear Stress (τ)
The stress component that produces or tends to produce a shearing motion.
- Velocity Gradient (du/dy)
The rate of change of velocity with respect to the distance between fluid layers.
- Laminar Flow
A type of fluid flow where the fluid moves in parallel layers, with no disruption between them.
