18.1.3 - Network Models
Enroll to start learning
You’ve not yet enrolled in this course. Please enroll for free to listen to audio lessons, classroom podcasts and take practice test.
Interactive Audio Lesson
Listen to a student-teacher conversation explaining the topic in a relatable way.
Introduction to Network Models
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Today's topic is Network Models. Can anyone explain what a network model is?
Isn't it a way to structure how different network protocols work?
Exactly! Network models help us understand how data is transmitted across networks. Let's dive into the first one, the OSI model. Who can tell me how many layers it has?
The OSI model has seven layers, right?
That's correct! The seven layers are Physical, Data Link, Network, Transport, Session, Presentation, and Application. A useful acronym is 'Please Do Not Teach Students Proper Application.'
What do each of those layers do?
Great question! Each layer has specific responsibilities, like the Physical layer dealing with the hardware and the Application layer facilitating user applications.
Details of the OSI Model
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Let’s discuss the functions of the OSI model layers. Can someone explain what the Data Link layer is responsible for?
It manages node-to-node data transfer and handles errors!
Exactly! And what about the Network layer?
It takes care of routing packets and addressing devices.
Correct! Each layer plays a vital role in ensuring that data can travel from one point to another seamlessly. Now, what might happen if the Network layer fails?
Data wouldn’t reach its destination?
Right again! Understanding how each layer communicates helps in diagnosing networking issues.
Comparing the OSI and TCP/IP Models
🔒 Unlock Audio Lesson
Sign up and enroll to listen to this audio lesson
Now, let's contrast the OSI model with the TCP/IP model. Who can tell me how many layers the TCP/IP model has?
The TCP/IP model has four layers.
Correct! Can anyone name the layers of the TCP/IP model?
Network Access, Internet, Transport, and Application.
Excellent! The TCP/IP framework combines some OSI layers, simplifying the model. Who can explain how this simplification is beneficial?
It makes it easier to implement and understand networking, especially for practical applications!
Exactly! Understanding both models helps in designing robust network applications.
Introduction & Overview
Read summaries of the section's main ideas at different levels of detail.
Quick Overview
Standard
In this section, we explore two primary network models: the OSI model, which consists of seven layers, and the TCP/IP model with four layers. Both models provide a structured approach to networking, enhancing communication between interconnected systems.
Detailed
Network Models
Network models are essential frameworks that illustrate how various protocols and technologies communicate over networks. In this section, we focus on two predominant models:
1. OSI Model (Open Systems Interconnection Model)
The OSI model is a theoretical framework that defines network communication in seven distinct layers:
- Physical: This layer transmits raw bitstreams over a physical medium. It includes hardware elements such as cables and switches that facilitate data transmission.
- Data Link: Responsible for node-to-node data transfer and error detection. It manages how data packets are placed on the physical layer.
- Network: This layer manages device addressing and routing of data across the network.
- Transport: Ensures complete data transmission with error handling and flow control, generally using protocols like TCP and UDP.
- Session: Maintains sessions between applications, offering functionalities like establishing, managing, and terminating connections.
- Presentation: Translates data from the application into a format that can be sent over the network. It also handles data compression and encryption.
- Application: This top layer facilitates network services to end-user applications, including coding and application protocols.
2. TCP/IP Model (Transmission Control Protocol/Internet Protocol)
Unlike the OSI model, the TCP/IP model is more pragmatic and consists of just four layers:
- Network Access: Represents the OSI’s Physical and Data Link layers. It manages how data is physically sent across the network.
- Internet: Corresponds to the OSI Network layer, handling packet forwarding, routing, and addressing.
- Transport: Similar to the OSI model, it oversees data transmission and reliability, typically using TCP and UDP.
- Application: This layer encompasses the functionalities of the OSI’s upper layers (session, presentation, and application), providing end-user services.
Both the OSI and TCP/IP models are vital for network programming as they provide guidelines and standards for implementing network communications effectively. Understanding these models is critical for developing client-server applications and exploring network protocols.
Youtube Videos
Audio Book
Dive deep into the subject with an immersive audiobook experience.
OSI Model
Chapter 1 of 2
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
• OSI Model (7 layers)
- Physical, Data Link, Network, Transport, Session, Presentation, Application
Detailed Explanation
The OSI Model, or Open Systems Interconnection Model, is a framework that divides network communication into seven distinct layers. Starting from the bottom up:
1. Physical Layer: This layer is concerned with the physical connection between devices. It includes hardware specifications such as cables, switches, and electrical signals.
2. Data Link Layer: This layer provides node-to-node data transfer, handling error correction from the physical layer. It is responsible for MAC addresses.
3. Network Layer: This layer is responsible for data packet routing and forwarding. It manages device addressing and location.
4. Transport Layer: This layer ensures complete data transfer and handles error recovery and flow control. It helps establish connections and can be connection-oriented (like TCP).
5. Session Layer: This layer manages sessions between applications, facilitating the exchange of information and maintaining communication.
6. Presentation Layer: It translates data formats between the application layer and the network layer, managing data encryption and compression.
7. Application Layer: This top layer is where applications access network services. It includes protocols like HTTP and FTP.
Examples & Analogies
Think of the OSI Model like a postal service for sending letters.
- The Physical Layer would be the actual roads and vehicles used to transport letters (the physical infrastructure).
- The Data Link Layer would be similar to a local post office that ensures letters are delivered to the correct addresses (error handling).
- The Network Layer is like the postal routes that determine how letters get from one city to another (routing).
- The Transport Layer is the assurance that letters reach their destination (delivery confirmation).
- The Session Layer is akin to establishing a correspondence with someone (maintaining communication).
- The Presentation Layer is how the letters are formatted (encryption/decoding), and the Application Layer is the final recipient reading the letter.
TCP/IP Model
Chapter 2 of 2
🔒 Unlock Audio Chapter
Sign up and enroll to access the full audio experience
Chapter Content
• TCP/IP Model (4 layers)
- Network Access, Internet, Transport, Application
Detailed Explanation
The TCP/IP Model, which stands for Transmission Control Protocol/Internet Protocol, simplifies networking into four layers.
1. Network Access Layer: This layer corresponds to the combination of the physical and data link layers of the OSI model. It determines how data is physically sent over the network, including hardware like routers and switches.
2. Internet Layer: This layer applies protocols such as IP (Internet Protocol) to handle the addressing and routing of data packets across different networks.
3. Transport Layer: Like the OSI’s equivalent, this layer manages the transmission of data between hosts with protocols like TCP and UDP. TCP is reliable and connection-oriented, while UDP is faster but connectionless.
4. Application Layer: It serves as an interface for applications to communicate over the network. This is where protocols like HTTP, FTP, and SMTP operate, allowing users to interact with the content they need.
Examples & Analogies
Imagine you are hosting a party and need to prepare for guests.
- The Network Access Layer might involve setting up the venue (the actual hardware connections).
- The Internet Layer is like sending out invitations that include directions to your venue (addresses that help guests find their way).
- The Transport Layer ensures people can actually get in and out of the venue efficiently, whether through a RSVP system or just people arriving casually (data transfer).
- The Application Layer is where guests engage in activities, like enjoying food, music, or games (application-level protocols functioning for user experience).
Key Concepts
-
OSI Model: A structured framework comprising seven layers for understanding network interactions.
-
TCP/IP Model: A model with four layers, widely used in the real world to standardize data communications over the internet.
Examples & Applications
The OSI Model helps in understanding how a file is transferred from one computer to another, with each layer playing a specific role.
The TCP/IP model is the backbone of the internet, guiding how data packets are routed and transmitted across diverse networks.
Memory Aids
Interactive tools to help you remember key concepts
Rhymes
OSI layers reach new heights, from Physical to Application, they guide our bytes.
Stories
Imagine sending a letter. First, it’s in a physical envelope, then you write addresses (data link), choose a route (network), sort it (transport), and finally deliver it (application).
Memory Tools
Please Do Not Teach Students Proper Application - a mnemonic for OSI layers.
Acronyms
TCP/IP
Transport
Communication Protocol/Internet Protocol.
Flash Cards
Glossary
- OSI Model
A conceptual framework used to understand and implement networking protocols in seven layers.
- TCP/IP Model
A four-layer model that describes the structure and behavior of networking protocols.
- Physical Layer
The OSI layer that transmits raw binary data over a physical medium.
- Transport Layer
The layer responsible for reliable data transmission and flow control.
- Application Layer
The OSI layer that provides network services to applications.
